Summary of Contents for Grundig Dh 2094
- Page 1 Dh 2094 D h 2 0 9 4...
- Page 2 Dh 2094...
- Page 3 Pile Batteri Piles Pilas ü Accuset 662 Rechargeable Bat- tery 662 Accumulatore 662 Jeu d'accus 662 Akku-set 662 Dh 2094 Laddb.batteriset 662 Akku-sæt 662 Accuset 662 Netzbetrieb Mains operation Alimentaz. a rete Aliment. secteur Netvoeding Nätdrift Netdrift Servicio de red...
-
Page 4: Supply Voltage
Supply Voltage Battery, Rechargeable Battery, Mains Operation Battery/rechargeable battery condition indi- cator (plus recording indicator): Lights up when recording. Goes out when the batteries/rechargeable bat- teries are weak. Recording is still possible until the motor stops (sound signal). Battery operation with two 1.5V/LR 6/AA bat- teries (alkaline-manganese), leak-proof. -
Page 5: Controls And Sockets
Controls and Sockets Please open folder at beginning of booklet! Playback Volume Control (turn) Microphone Record Indication Lights up during recording. Record Button - Press for recording (locks in). Switch-On Lock red green Prevents accidental switching on. Sliding Switch Fast forward wind (search) Stop Start playback Start recording:... - Page 6 General Do not expose the unit and the steno-cassettes to temperatures above 55 °C. Dispose of old batteries and rechargeable bat- teries according to environmental regulations. *Accessories indicated in the text are not sup- plied with the unit. Switch-On Lock Switch-on lock red green Red visible:...
- Page 7 Recording Microphone and Recording Indication Microphone Speaking distance approx. 5cm - 10cm; decrease in the case of high ambient noise. Recording Indication (plus battery/rechargeable battery indicator) – Ligths up during recording. – Goes out when the batteries/rechargeable batteries are exhausted (page 1). Recording Every new recording automatically erases the existing recording on the tape.
-
Page 8: During Playback
Recording To listen to the last words: Release sliding switch ( playback). To listen to long text passages, keep sliding switch in rewind position: – The tape is rewound until the sliding button is released ( plaback). Resuming dictation During playback, press - record button (locks in) at desired text passage: –... - Page 9 Playback Playback Starting playback Set sliding switch to Start: Adjust desired volume (turn). Concluding playback Set sliding switch to Stop. Fast Rewind Keep sliding switch in rewind position; the tape is briefly rewound then stopped: If you wish to listen only to the last words (word repetition), release the sliding button ( playback).
-
Page 10: Care And Maintenance
Care and Maintenance The cabinet should only be cleaned with a soft cloth which picks up dust. Polishing or clea- ning agents may damage the surface. Parts contacting the tape should be checked from time to time for contamination by tape abrasion, see illustration at the end of this booklet. - Page 11 Figure to text "tape contacting parts" , page...
