    1588v2 timing implementation. The VSC8584 device offers a seamless integration between IEEE 1588v2 and the MACsec engine with no loss of precision. The VSC8584 also supports a ring resiliency feature that allows a 1000BASE-T connected PHY port to switch between master and slave timing without having to interrupt the 1000BASE-T link.
  • Page 5: General Description

    VSC8584 Evaluation Board General Description The evaluation board in Figure 1 provides the user a way to evaluate the VSC8584 device in multiple configurations. Four RJ-45 connectors are provided for copper media interfaces. The four SFP cages allow for evaluation of the fiber media interconnects. The MAC interface is provided via SMA connectors.
  • Page 6: External 1588 Clock Option

    3.1.7 1588 Daisy-Chain SPI Time-Stamping Connection The VSC8584 device enables daisy-chaining multiple devices to reduce the number of pins required to transmit time stamping information to system ASICs gathering IEEE 1588 time stamps. For users with two or more 8584EV boards, the following single-ended connections shown below are required from the master device to slave device: J75 pin 6 to J77 pin 6 (1588_SPI_CLK output →...
  • Page 7: Network Interface Microcontroller Card

    A “Rabbit” microcontroller card is included to facilitate a software interface to the registers on the VSC8584. The controller card has a hard coded static IP address. Refer to the label on the card for the value. This address is required by the user to initiate communications via the board and the GUI.
  • Page 8: Quick Start

    Please record and inform Microsemi of the new IP address of the board when you return so that Microsemi can connect to and reconfigure the board. Re-label the Rabbit board with the new IP.
  • Page 9: Using The Control Software

    "Connect." The display next to the IP address window should change to "Connected." If it does not, check the IP address, or your network configuration until connection with the EVB can be successfully established. Double-click on “MII Registers” and the window shown in Figure 6 should appear: VPPD-03500 VSC8584 User Guide Revision 1.0...
  • Page 10: Board Initialization And Running Pgy Scripts

    “Run” button. After execution is completed, you should see read-back values in decimal as shown in the following figure. The script syntax is command, phy address (in decimal), register address (in decimal), and register content (in either hexadecimal or decimal). VPPD-03500 VSC8584 User Guide Revision 1.0...
  • Page 11: Copper Media Operation (1000Base-T)

    A single register write and some external coax cables enables 1G Ethernet traffic to be received by the VSC8584 RJ-45 port, routed through the VSC8584 and externally via coax loopback cables through the SGMII interface and transmitted back to the traffic source on the same copper port. First configure the SerDes in SGMII mode by writing to Micro page 18’d.
  • Page 12: Fiber Media Operation (1000Base-X)

    CRC errors = ExtMII 23.7:0 4.5.3 Fiber PHY Error Counters Good RX CRC packets = Ext3MII 28.13:0 Bad RX CRC packets = Ext3MII 29.7:0 Good TX CRC packets = Ext3MII 21.13:0 Bad TX CRC packets = Ext3MII 22.7:0 VPPD-03500 VSC8584 User Guide Revision 1.0...
  • Page 13: Configuring 1588 Daisy-Chain Spi Time-Stamping

    For Slave VSC8584EV, run the same instructions listed above for Master VSC8584EV for each port 0-3. Then, run the following write only on port 0: smiwrite 0 31 4 smiwrite 0 26 0 × c0f7 smiwrite 0 31 0 VPPD-03500 VSC8584 User Guide Revision 1.0...
  • Page 14: Additional Information

    VSC8584 Evaluation Board Additional Information For any additional information or questions regarding the devices mentioned in this document, contact your local sales representative. VPPD-03500 VSC8584 User Guide Revision 1.0...
