- Page 2 Be sure to thoroughly read and understand the SAFETY PRECAUTIONS given in this section before using the equipment in order to operate the equipment correctly. The precautionary measures described in this section are intended to prevent danger or damage to you or to others.
- Page 3 CAUTION Be sure to provide a ground wire Prevent a metallic object or dust securely. Do not connect the from sticking to the power plug. Adhesion of foreign object to the ground wire to a gas pipe, water plug could cause electrical pipe, lightening rod, or telephone ground wire.
- Page 4 CAUTION doing so will damage the product, which may lead to electrical leakage or electrical shock. Deterioration of the insulation may lead to electrical leakage, electrical shock, or fire. Failure to observe this caution could cause it to malfunction or to operate abnormally, which may lead to electrical leakage or electrical shock.
-
Page 5: Mechanical Seal
Handle Cabtyre Cable Mechanical Seal Oil Plug Impeller Pump Casing Strainer Stand Submersible pump Rated voltage Built in motor protector Rated current Serial number Rated output power Model Insulation class Max. liquid temperature Frequency Max. total head Weight without cable Min. -
Page 6: Single-Phase
Note: CAUTION CAUTION Note: CAUTION Applicable Pump Critical Use Pressure Models with output of 0.75kW or under 0.2MPa(2kgf/cm ) − discharge pressure during use Models with output 1.5kW 0.3MPa(3kgf/cm ) − discharge pressure during use Single-Phase Three-Phase Note:... - Page 7 WARNING CAUTION Using a hose Screw-on Hose Coupling Screw onto pump discharge connector Hose Bands Suction Delivery Hose Using a PVC pipe Adhesive Screw onto pump discharge connector Straight Pipe Socket 90-degree Elbow CAUTION Suspend with rope CAUTION Note:...
- Page 8 WARNING WARNING CAUTION WARNING CAUTION CAUTION Note: Single Phase L1 L2 L1-Red(Brown) G-Green (Green/Yellow) L2-White(Blue) Three Phase U-Red(Brown) G-Green (Green/Yellow) V-White(Grey) W-Black(Black)
- Page 9 Note: Power Supply: Single-Phase Power Supply: Three-Phase Protector Main Coil Ground Operating Capacitor Aux.Coil Ground Protector Motor Coil Centrifugal Switch...
- Page 10 CAUTION Note: Note: Note: WARNING CAUTION WARNING COUNTERMEASURE Example: Interchanging phases V and W...
- Page 11 U V W COUNTERMEASURE COUNTERMEASURE CAUTION WARNING Note: CAUTION...
- Page 12 WARNING Note: Interval Inspection Item Measuring the operating current To be within the rated current Daily Power supply voltage tolerance Measuring the power voltage = within ±5% of the rated voltage Measuring the insulation resistance Insulation resistance reference value = 1M minimum Monthly [NOTE] The motor must be inspected if the insulation resistance is considerably lower than the last inspection.
- Page 13 Note: Hex Key Wrench Oil Plug Packing Oil Inlet Specified Oil: Liquid Paraffin VG32 Unit : Applicable Model Specified Volume Model with 0.4 ~ 0.75kW power output 1 6 0 Model with 1.5kW power output 6 0 0 Note:...
- Page 14 WARNING Impeller Adjusting Washer Impeller Spring Washer Hex Nut Impeller Thread Protection Cap Packing Pump Casing Oil Plug Square Packing Phillips Screw Spring Washer Hex Nut Plain Washer Outer Cove Strainer Stand Square Packing Note:...
-
Page 15: Manufacturing Number
WARNING Problem Possible cause Countermeasure (1)No proper power is supplied (i.e. power (1)Contact the electric power company or an electrical outage). repair shop. (2)Open circuit in cabtyre cable or poor (2)Check whether there is an open circuit in the Pump fails to start. connection.
