KTZ/KTZE Series
Submersible Dewatering Pumps
OPERATION MANUAL
INTRODUCTION
Thank you for selecting the Tsurumi KTZ or KTZE Submersible Dewatering Pumps.
This equipment should not be used for applications other than those listed in this manual. Failure to observe
this precaution may lead to a malfunction or an accident. In the event of a malfunction or an accident, the
manufacturer will not assume any liability. After reading this Operation Manual, keep it in a location that is
easily accessible, so that it can be referred to whenever information is needed while operating the equipment.
TSURUMI MANUFACTURING CO., LTD.
1. BE SURE TO READ FOR YOUR SAFETY ..................... 1
2. PUMP PART NAMES ...................................................... 4
3. PRIOR TO OPERATION ................................................ 5
4. INSTALLATION ............................................................. 6
5. ELECTRICAL WIRING .................................................... 10
6. OPERATION .................................................................... 11
7. MAINTENANCE AND INSPECTION ............................... 16
9. TROUBLESHOOTING .................................................. 22
CONTENTS
17200465/B-10220-2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KTZ Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tsurumi Pump KTZ Series

  • Page 1: Table Of Contents

    17200465/B-10220-2 KTZ/KTZE Series Submersible Dewatering Pumps OPERATION MANUAL INTRODUCTION Thank you for selecting the Tsurumi KTZ or KTZE Submersible Dewatering Pumps. This equipment should not be used for applications other than those listed in this manual. Failure to observe this precaution may lead to a malfunction or an accident. In the event of a malfunction or an accident, the manufacturer will not assume any liability.
  • Page 2: Be Sure To Read For Your Safety

    1 BE SURE TO READ FOR YOUR SAFETY Be sure to thoroughly read and understand the SAFETY PRECAUTIONS given in this section before using the equipment in order to operate the equipment correctly. The precautionary measures described in this section are intended to prevent danger or damage to you or to others.
  • Page 3 CAUTION Be sure to provide a ground wire Attach a hose securely to the hose coupling. Imperfect connection securely. Do not connect the ground wire to a gas pipe, water of hose could cause water leakage which may result in the pipe, lightening rod, or telephone ground wire.
  • Page 4 CAUTION Do not use the product for hot or When the product will not be used , as doing so warm liquid over 40 for an extended period, be sure to will damage the product, which turn off the power supply (earth may lead to electrical leakage or leakage circuit breaker, etc.).
  • Page 5: Pump Part Names

    2 PUMP PART NAMES Discharge Outlet Cabtyre Cable Hose Coupling Handle Automatic Pump Eelectrode Level Sensor Mechanical Seal Oil Lifter Oil Plug Shaft Sleeve Oil Casing Pump Casing Strainer Impeller Suction Cover Bottom Plate Note: This diagram shows the part layout of a typical KTZ model. The external appearance and the internal construction may vary slightly, depending on your particular model.
  • Page 6: Prior To Operation

    3 PRIOR TO OPERATION Check the following points after receiving the pump: Inspection Unpack the package and verify that no damage has occurred during shipment and that the bolts and nuts have not loosened. Specification Check Check the nameplate of the pump unit to verify that it is the product that you have ordered. Pay particular attention to its voltage and frequency specifications.
  • Page 7: Installation

    Specifications - Non-Automatic Pumps (50/60Hz) Max. Total Head Max. Fiow Rate Discharge Model Motor Starting Bore Output Weight Method /min) (mm) (kW) (kg) KTZ21.5 21.5 / 23.0 0.43 / 0.40 Direct-on-Line KTZ22.2 26.0 / 30.5 0.50 Direct-on-Line KTZ23.7 36.5 / 35.0 0.45 / 0.54 Direct-on-Line KTZ31.5...
  • Page 8: Preparation For Installation

    Critical Pressure CAUTION Do not use the pump in an area where the water pressure exceeds the values given below, as it may damage the pump, or cause a short or electrical shock. Model Critical Pressure KTZ(E)21.5 KTZ(E)31.5 KTZ(E)22.2 KTZ(E)32.2 KTZ(E)23.7 KTZ(E)33.7 KTZ(E)43.7 0.5MPa (5kgf/cm ) —...
  • Page 9: Precautions During Installation

    Precautions During Installation Hose clamp Hose (1) Push the hose all the way to the base of the hose Discharge connection coupling. Tighten the hose clamp to secure the hose in Hose coupling place. Note: A hose coupling designed for use with a suction hose is available separately.
  • Page 10 (4) When using a hose to provide piping to the pump, observe the following: Use the shortest possible length of discharge hose and minimize the number of bends. Verify that the end of the hose (discharge side) is lifted above the water surface. If the end of the hose is submerged in water, it may cause the water to flow back when the pump has been stopped.
  • Page 11: Electrical Wiring

    5 ELECTRICAL WIRING Electrical Wiring Work WARNING • All electrical work must be performed by an authorized electrician, in compliance with local electrical equipment standards and internal wiring codes. Never allow an unauthorized person to perform electrical work because it is not only against the law, but it can also be extremely dangerous.
  • Page 12: Operation

    KTZ models (models with 22kW power output) Ground Miniature Protector 6 OPERATION Before Operation CAUTION Improper voltage and frequency of the power supply will prevent the pump from attaining its full potential, and may also lead to current leakage, electrical shock, or fire. (1) Once again, check the nameplate of the pump to verify that its voltage and frequency are correct.
  • Page 13 Direct-on-line starting To reverse the rotation, the following countermeasure must be taken. COUNTERMEASURE Interchange two of the three wires designated U, V, and W, respectively. Ground (Example) Interchanging phases V and W (2) Operate the pump for a short time (3 to 10 minutes) and perform the following checks: Operating current Using an AC ammeter (clamp), measure the current at the phases U, V, and W that are connected to the terminal board.
  • Page 14: Motor Protection System

    Motor protection system WARNING • During inspection and repair, disconnect the power supply to avoid starting the pump unintentionally. Failure to disconnect the power supply may lead to serious accidents including electrical shock, short, and injury. • During a power outage, disconnect the power supply to the pump. Unintentional operation of the pump after power resumption would be extremely dangerous to people around the pump.
  • Page 15 In the Case of Automatic Pumps Starting of a pump The pump starts when the current (micro current) continuously flows between a conductive part(Shaft, Bolt, etc.) and the electrode level sensor for more than one (1) second. Note: The electrode may not detect the water surface under conditions such as purif ed water or distillated water with which the current does not f ow because of high specif c resistance.
  • Page 16 Operating Principle of the Automatic Pumps This explains the control form by a combination of an electrode and a timer function. Please understand the performance of this pump and apply it. Water Electrode Level Sensor Pump Condition Level Electrode level sensor will submerge and the [Switch on] pump will operate by the current.
  • Page 17: Maintenance And Inspection

    7 MAINTENANCE AND INSPECTION Periodic maintenance and inspection are indispensable in maintaining the pump's performance. If the pump behaves differently from its normal operating condition, refer to the section "9. Troubleshooting" on page 23 of this manual and take appropriate measures at an early stage. It is recommended that a spare pump be prepared on hand.
  • Page 18: Replacement Parts

    Storage If the pump will not be operated for a long period of time, pull the pump up, allow it to dry, and store it indoors. Note: Be sure to perform a trial operation before reinstalling the pump. If the pump remains immersed in water, operate the pump on a regular basis (i.e. once a week) to prevent the impeller from seizing due to rust.
  • Page 19: Disassembly And Reassembly Procedure

    8 DISASSEMBLY AND REASSEMBLY PROCEDURE Prior to Disassembling and Reassembling WARNING Before disassembling and reassembling the pump, be sure that the power supply (i.e. circuit breaker) is disconnected, and remove the cabtyre cable from the terminal board. To prevent serious accidents, do not perform a conducting test during disassembly and reassembly.
  • Page 20: Disassembly Diagram

    Disassembly Diagram Example 1 - Model KTZ31.5 Part Name Part Name Part Name Hexagonal bolt Packing Impeller nut Spring washer Pump casing Suction cover packing Packing Oil seal Suction cover Oil plug Shaft sleeve Plain washer Mechanical seal Impeller adjusting washer Stud bolt Round head screw Impeller...
  • Page 21 Disassembly Procedure (7.5kW to 22kW Models) Note: 1.Before disassembling, be sure to drain the oil from the pump.      2.The construction of KTZ67.5, KTZ411, KTZ611, KTZ415, KTZ615, KTZ422, and KTZ622 are       identical, however, models KTZ422, and KTZ622 are constructed without a O-ring ( ⑰ ) . (1) Removing the bottom plate and the strainer After removing the hexagonal nut and the plain washer from the bottom, remove the bottom plate and the strainer from the pump.
  • Page 22 Disassembly Diagram Example 2 - Model KTZ47.5 Part Name Part Name Part Name Hexagonal bolt Hexagonal bolt Impeller nut Spring washer Shaft sleeve Suction cover packing Mechanical seal Pump casing Suction cover Round head screw Spring washer Plain washer Oil lifter Hexagonal bolt Hexagonal bolt O-ring...
  • Page 23: Troubleshooting

    9 TROUBLESHOOTING WARNING To prevent serious accidents, disconnect the power supply before inspecting the pump. Read this Operation Manual carefully before requesting repair. After re-inspecting the pump, if it does not operate normally, contact the dealer from whom you purchased the equipment, or the Tsurumi sales office in your area.
  • Page 24: Disposal Of Product

    The information listed below is needed for repair or for contacting Tsurumi. Product model Manufacturing number Purchase date Remarks Disposal of Product Properly dispose of the product by disassembling it, presorting the contents, and sending them to the waste material treatment site. ©...
