Summary of Contents for Clevo M81P

  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
  • Page 4 Preface Regulations: (Federal Communications Commission) This transmitter complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 5: Fcc Rf Radiation Exposure Statement

    Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device was tested for typical laptop operations with the device contacted directly to the human body to the back side of the notebook computer.
  • Page 6 Preface MAX SAR Test Table Max SAR Test Table Band Position SAR 1g (W/kg) GSM850 Body(0 cm Gap) 0.071 GSM1900 Body(0 cm Gap) 0.031 WCDMA Band V Body(0 cm Gap) 0.032 WCDMA Band II Body(0 cm Gap) 0.043 Table I - 1 - Operating Systems Supported...

  • Page 7: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 8: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 9 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 10: Power Safety

    Preface Power Safety The computer has specific power requirements: •Only use a power adapter approved for use with this computer. •Your AC/DC adapter may be designed for international travel but it still requires a steady, Power Safety uninterrupted power supply. If you are unsure of your local power specifications, consult Warning your service representative or local power company.

  • Page 11: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 12 Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 13: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 14 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.

  • Page 15: Developing Good Work Habits

    Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.

  • Page 16: Lcd Screen Care

    Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...

  • Page 17: Chapter 1: Quick Start Guide

    Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide.You may also find the notes marked with a of interest to you.

  • Page 18: System Software

    Quick Start Guide Not Included Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals. Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers on the CD supplied.

  • Page 19: System Start-Up

    Quick Start Guide System Startup Remove all packing materials, and place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.

  • Page 20: System Map: Lcd Panel Open

    Quick Start Guide System Map: LCD Panel Open Figure 1 - 2 LCD Panel Open Built-In PC Camera Wireless Device Operation Aboard Speakers Aircraft Power Button Keyboard The use of any portable elec- tronic transmission devices Built-In Microphone aboard aircraft is usually pro- Touchpad &...
  • Page 21 Quick Start Guide Keyboard The keyboard has a numerical keypad for easy numeric data input, and features function keys to allow you to change operational features instantly. See Table 1 - 2, on page 1 - 6 for details on the function keys. Special Characters Some software applications allow the number-keys to be used with Alt to pro-...

  • Page 22: Function/Hot Key Indicators

    Quick Start Guide Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. Keys Function Keys Function Fn + ~ Play/Pause (in Audio/Video Programs) Fn + F7 Display Toggle 3.75G Module Power Brightness Decrease/...

  • Page 23: System Map: Front & Rear Views

    Quick Start Guide System Map: Front & Rear Views Figure 1 - 4 Front & Rear Views LED Power & Communication Indicators 7-in-1 Card Reader Microphone-In Jack Headphone-Out Jack Battery 7-in-1 Card Reader The card reader allows you to use the most popular digital storage card formats: MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick) / MS Pro (Memory Stick Pro) / MS Duo (requires PC adapter) / Mini SD (requires PC adapter) / RS MMC (requires PC adapter)

  • Page 24: Led Indicators

    Quick Start Guide LED Indicators Icon Color Description Orange DC Power is Plugged In Green The Computer is On Blinking Green The Computer is in Sleep Mode Orange The Battery is Charging Green The Battery is Fully Charged Blinking Orange The Battery Has Reached Critically Low Power Status Green Hard Disk Activity...

  • Page 25: System Map: Left & Right Views

    Quick Start Guide System Map: Left & Right Views Figure 1 - 5 Left & Right Views Security Lock Slot DC-In Jack RJ-45 LAN Jack 2 * USB 2.0 Ports External Monitor Port Hard Disk Drive Vent/Fan Intake/ Outlet Overheating External Optical (CD/DVD) Device Drives To prevent your computer from To install applications and drivers etc.

  • Page 26: System Map: Bottom View

    Quick Start Guide System Map: Bottom View Figure 1 - 6 Bottom View Battery 3.75G/HSPA Module USIM Vent/Fan Intake/ Card Outlet Hard Disk Bay The 3.75G/HSPA module’s USIM card location is located under the bat- tery compartment. See page 1 - 11 for instructions on installing the 3.75G/HSPA USIM card.

  • Page 27: G/Hspa Module Usim Card Installation

    Quick Start Guide 3.75G/HSPA Module USIM Card Installation If you have included an optional 3.75G/HSPA module in your purchase option, follow the instructions below to install the USIM card (which will be provided by your service provider), and then run the Mobile Partner ap- plication.

  • Page 28: Windows 7 Start Menu & Control Panel

    Quick Start Guide Windows 7 Start Menu & Control Panel Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are ac- cessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.

  • Page 29: Video Features

    Quick Start Guide Video Features You can configure display options from the Display (Control Panel) and Screen Resolution in Windows. To access Display (Control Panel) and Screen Resolution in Windows: Click Start and click Control Panel. Click Display (icon) - In the Appearances and Personalization category. Click Adjust Screen Resolution/Adjust resolution.

  • Page 30: Screen Resolution & Intel Gma Control Panel

    Quick Start Guide Screen Resolution & Intel GMA Control Panel Figure 1 - 9 - Screen Resolution & Intel GMA Driver for Mobile Control Panel 1 - 14 - Video Features...

  • Page 31: Power Options

    Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 12) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
  • Page 32 Quick Start Guide 1 - 16...
  • Page 33 3.75G/HSPA Module Chapter 2: 3.75G/HSPA Module 3.75G/HSPA Module If you have included an optional 3.75G/HSPA (High Speed Packet Access) module in your purchase option, you will have the appropriate application (Mobile Partner) provided for your particular module. Follow the instructions on page 1 - 11 to install the USIM card (supplied by your service provider), and then install the application...
  • Page 34 3.75G/HSPA Module Before installing the application, make sure that the 3.75G/HSPA module is ON (installing the driver with the module off will not allow the software to detect the module hardware correctly). Use the Fn + key combination (see “Function/Hot 3.75G/HSPA Key Indicators”...

  • Page 35: Mobile Partner Application Installation

    3.75G/HSPA Module Mobile Partner With the 3.75G/HSPA module and USIM card (supplied by your service provider) Wireless Device installed you may then install the Mobile Partner application. The Mobile Partner Operation Aboard application allows you to directly access your HSPA internet service from the com- Aircraft puter.

  • Page 36: Mobile Partner Application

    3.75G/HSPA Module Mobile Partner Application You will need to contact your service provider to obtain the exact details of how ex- actly to configure the settings on this page. Mobile Partner Help Profile Management To get help on Mobile Partner configuration Power on the 3.75G/HSPA module using the Fn + key combination.
  • Page 37 3.75G/HSPA Module Connecting to the Service Provider Power on the 3.75G/HSPA module using the Fn + key combination. Access the Mobile Partner application from the Start menu (Start > Programs/ All Programs > Mobile Partner), or by double-clicking the Mobile Partner icon on the desktop The software will run and you can select the Profile Name from the menu.
  • Page 38 3.75G/HSPA Module When the connection is successful you can move the cursor over the network icon in the taskbar to display the connection information. Figure 2 - 4 Connected Taskbar Notification You can then access the internet, download e-mail etc. as per any internet connection.
  • Page 39 3.75G/HSPA Module To disconnect click the Disconnect icon, or right click the taskbar icon and select Disconnect. Figure 2 - 5 Disconnect 10. The program will disconnect from the service provider. 11. The module will still be on, and you will need to press the Fn + combination to turn it off.
  • Page 40 3.75G/HSPA Module 12. If you click the Mobile Partner close icon a message will be displayed asking you to click OK to confirm the program exit and to terminate the connection. Figure 2 - 6 Exit Prompt 13. Exiting the program terminates the connection, but DOES NOT turn off the 3.75G/ HSPA module, and you will need to press the Fn + key combination to turn off the module (pay careful attention to this aboard aircraft - see...

  • Page 41: Text Messaging Service

    3.75G/HSPA Module Text Messaging Service In addition to standard internet services you may also send and receive SMS text messages using the Mobile Partner program, if your service supports SMS. Reading SMS Messages An icon will blink at the bottom of the Mobile Partner interface to notify you of any new messages received.
  • Page 42 3.75G/HSPA Module 2 - 10...

  • Page 43: Appendix A: Specifications

    Specifications Appendix A: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.
  • Page 44 Specifications Processor Video Adapter Audio Intel® Atom® Processor N270 Intel NM10 Integrated Video High Definition Audio Compliant Interface 1.67 GHz, 512KB On-die L2 Cache & Compliant with Microsoft UAA (Universal Supports DirectX 9.0 557MHz FSB, 5.5W - BGA Package, Audio Architecture) Shared Memory Architecture 45nm (45 Nanometer) Process Direct Sound 3D™...
  • Page 45 Specifications Communication Power Management 10Mb/100Mb Base-T Ethernet LAN Wake On LAN Wake On USB *UMTS/HSPDA-based 3.75G/HSPA Module with Mini Card Interface (Factory Power Option) Full Range AC/DC Adapter Quad-band GSM/GPRS (850 MHz, 900 AC Input: 100 - 240V, 50 - 60Hz MHz, 1800 MHz, 1900 MHz) DC Output: 19V, 1.58A (30 Watts) UMTS WCDMA FDD (2100 MHz)
  • Page 46 Specifications A - 4...
