Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4: Fcc Statement
Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 5: Fcc Rf Radiation Exposure Statement
Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
Page 6: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 7: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Page 9: Power Safety
Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a Power Safety steady, uninterrupted power supply. If you are unsure of your local power specifications, Warning consult your service representative or local power company.
Page 10: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Page 11: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Page 12: Travel Considerations
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 13 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 14 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Page 15: Lcd Screen Care
Preface Lighting Proper lighting and a comfortable viewing angle can reduce eye strain and shoulder and neck muscle fatigue. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Page 16 Preface...
Page 17: Table Of Contents
Preface Contents Notice .................I Function/Hot Key Indicators ........1-10 FCC Statement .............II System Map: Front & Rear Views .......1-11 FCC RF Radiation Exposure Statement: ....III System Map: Right View ..........1-12 Instructions for Care and Operation ......V System Map: Left View ..........1-13 Power Safety .............VII System Map: Bottom View ..........1-14 Battery Precautions ..........
Page 18 Preface USB Printer ...............2-10 Drivers & Utilities Install Instructions: ...........2-10 What to Install ..............4-1 Parallel Printer ............2-10 Module Driver Installation ..........4-1 Driver Installation ............4-2 Power Management Manual Driver Installation ...........4-3 Overview ................3-1 Updating/Reinstalling Individual Drivers ....4-4 The Power Sources ............3-2 User Account Control (Win Vista) ......4-4 AC/DC Adapter ............3-2 Windows Security Message .........4-4...
Page 19 Preface Intel Turbo Memory Technology Driver ....4-8 Battery Low Alarm Beep: (Advanced Menu) ....5-10 Fan Control (Advanced Menu) ........5-10 BIOS Utilities Security Menu ..............5-11 Set Supervisor Password (Security Menu) ....5-11 Overview ................5-1 Set User Password (Security Menu) ......5-12 The Power-On Self Test (POST) ........5-2 Password on boot (Security Menu) ......5-12 Failing the POST ............5-3 Fixed disk boot sector (Security Menu) .......5-12...
Page 20 Preface 802.11b/g Driver Installation ........7-7 Problems & Possible Solutions ........8-7 Connecting to a Wireless Network ......7-8 Screen Resolution Error ..........8-14 PC Camera Module ............7-11 Interface (Ports & Jacks) PC Camera Driver Installation .........7-11 PC Camera Audio Setup ...........7-12 Overview ...............A-1 3.5G Module ..............7-18 Ports and Jacks ..............A-2 3G Watcher Application ..........7-20...
Page 21 Preface Enabling TV Display ..........B-12 Windows XP Information DVD Regional Codes ...........D-2 Specifications Windows XP Start Menu & Control Panel ....D-3 Processor Types ............C-1 Audio Features ..............D-4 Core Logic ..............C-2 Function/Hot Key Indicators ........D-5 LCD ................C-2 Video Features ..............D-6 Security .................
Page 22 Preface Driver Installation ............D-22 Set Capture File ............D-39 Manual Driver Installation........... D-23 Reducing Video File Size ...........D-40 Updating/Reinstalling Individual Drivers ....D-24 Eliminating Screen Flicker .........D-41 Driver Installation Procedure........D-24 3.5G Module ...............D-43 Found New Hardware Wizard ........D-24 3G Watcher Application Installation ......D-43 Chipset ................D-25 Fingerprint Reader Module .........D-44 Audio ................D-25...
Page 23: Quick Start Guide
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 24: Advanced Users
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “Drivers & Utilities” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Page 25: Model Differences
Quick Start Guide Model Differences This notebook series includes two different design types, however only one design is pictured in this manual. Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the appropriate drivers.
Page 26: System Software
Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the following operating systems are sup- ported: Operating System &...
Page 27: System Startup
Quick Start Guide System Startup 1. Remove all packing materials, and place the computer on a stable surface. 2. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. 3. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Page 28: System Map: Lcd Panel Open
Quick Start Guide System Map: LCD Panel Open Figure 1 - 2 LCD Panel Open 1. Optional Built-In PC Wireless Device Camera Operation Aboard 2. LCD Aircraft 3. Hot Key Buttons 4. Power Button The use of any portable elec- tronic transmission devices 5.
Page 29: Led Indicators
Quick Start Guide LED Indicators The LED indicators on the computer display helpful information about the current status of the computer. Icon Color Description Icon Color Description Green The Computer is On Orange The Battery is Charging Blinking Blinking The Battery has Reached Critically Low The Computer is In Sleep Mode Green Orange...
Page 30: Hot Key Buttons
Quick Start Guide Hot Key Buttons These buttons give instant access to the default Internet browser and e-mail program, and to a user-defined ap- plication, with one quick button press. Hot Key Function Activate the Default E-Mail Browser Activate the Default Internet Program Toggle *Silent Mode (for power saving) Table 1 - 3 - Hot Key Buttons *When enabled, Silent Mode will reduce fan noise and save power consumption.
Page 31: Keyboard
Quick Start Guide Keyboard The keyboard has a numerical keypad for easy numeric data input, and features func- Other Keyboards tion keys to allow you to change operational features instantly. See Table 1 - 4, on page 1 - 10 for full function key combination details.
Page 32: Function/Hot Key Indicators
Quick Start Guide Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators (see the table below) are available when the hot key utility is installed (see “Hot Key”...
Page 33: System Map: Front & Rear Views
Quick Start Guide System Map: Front & Rear Views Figure 1 - 4 Front View 1. Headphone-Out Jack 2. Microphone-In Jack 1 2 3 3. *S/PDIF-Out Jack 4. Mini-IEEE 1394 Port 5. LED Indicators 6. Vent/Fan Intake/ Outlet 7. DVI-Out Port 8.
Page 34: System Map: Right View
Quick Start Guide System Map: Right View Figure 1 - 5 Right View 1. Express Card Slot 2. 7-in-1 Card Reader 3. 2 * USB 2.0 Ports 4. RJ-45 LAN Jack 5. RJ-11 Phone Jack ExpressCard Slot The ExpressCard Slot accepts either ExpressCard/34 or ExpressCard/54 formats. 7-in-1 Card Reader The card reader allows you to use the most popular digital storage card formats: MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick) /...
Page 35: System Map: Left View
Quick Start Guide System Map: Left View Figure 1 - 6 Left View 1. Optional Device Drive Bay (for CD/DVD Device, see page Changing DVD Regional Codes CD/DVD Emergency Eject If you need to manually eject a CD/DVD Go to the Control Panel and double-click (e.g.
Page 36: System Map: Bottom View
Quick Start Guide System Map: Bottom View Figure 1 - 7 Bottom View 1. Vent/Fan Intake/Out- 2. Battery 3. Battery Release Latch 4. Component Bay Cover 5. 3.5G USIM Card Cover Battery Information Always completely discharge, then fully charge, a new battery before using it. Completely discharge and charge the battery at least once every 30 days or after about 20 partial dis- charges.
Page 37: Windows Vista Start Menu & Control Panel
Quick Start Guide Windows Vista Start Menu & Control Panel Most of the control panels, utilities and programs within Windows Vista (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 38: Video Features
Quick Start Guide Video Features You can configure display options, from the Display Settings control panel in Windows as long as the appro- priate video driver is installed. For more detailed video information see “NVIDIA Video Driver Controls” on page B - To access Display Settings in Windows: 1.
Page 39: Display Devices & Options
Quick Start Guide Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display or TV (connected to the DVI-Out port/HDMI-Out port) as your display device. Figure 1 - 9 - Display Settings & NVIDIA Control Panel NVIDIA Display Mode Description Single...
Page 40: Power Options
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 15) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
Page 41: Storage Devices, Mouse, Audio & Printer
Storage Devices, Mouse, Audio & Printer Chapter 2: Storage Devices, Mouse, Audio & Printer Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical Device • 7-in-1 Card Reader •...
Page 42: Hard Disk Drive
Storage Devices, Mouse, Audio & Printer Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.
Page 43: Optical Device
Storage Devices, Mouse, Audio & Printer Optical Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the model you purchased (see “Storage” on page C - 3). The Adjustment optical device is usually labeled “Drive D:”...
Page 44: Handling Cds Or Dvds
Storage Devices, Mouse, Audio & Printer Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed.
Page 45: Dvd Regional Codes
Storage Devices, Mouse, Audio & Printer DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...
Page 46: 7-In-1 Card Reader
Storage Devices, Mouse, Audio & Printer 7-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 47: Expresscard Slot
Storage Devices, Mouse, Audio & Printer ExpressCard Slot The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Slot Cover Cards). Make sure you keep the ExpressCard/54 is used for applications which require a larger interface slot, e.g.
Page 48: Touchpad And Buttons/Mouse
Storage Devices, Mouse, Audio & Printer TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse.
Page 49: Audio Features
Storage Devices, Mouse, Audio & Printer Audio Features You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/ Adjustment control panel (right-click the taskbar icon to bring up an audio menu).
Page 50: Adding A Printer
Storage Devices, Mouse, Audio & Printer Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options.
Page 51: Power Management
Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.
Page 52: The Power Sources
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components (see page Attach the AC/DC adapter to the DC-In jack at the rear of the computer.
Page 53: Turning On The Computer
Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Shut Down er button on the front panel. Note that you should al- When the computer is on, you can use the power button as a Sleep/Hibernate hot- ways shut your comput- er down by choosing the key button when it is pressed for less than 4 seconds (pressing and holding the power...
Page 54: Power Plans
Power Management Power Plans The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
Page 55 Power Management Each Windows Power Plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance for maximum performance when the computer is pow- ered from an AC power source.
Page 56: Power-Saving States
Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where Power Button you left off. Sleep is the default power-saving state in Windows Vista. The Power Button Earlier versions of Windows used Stand By and Hibernate as system power-saving in the Start Menu (in Classic View use the states.
Page 57: Hibernate
Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.
Page 58: Configuring The Power Buttons
Power Management Configuring the Power Buttons The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Protection It is recommended that you enable a password on wake up in order to protect your data.
Page 59: Resuming Operation
Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status To Resume Icon Color send the computer to...
Page 60: Battery Information
Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery Warning Battery Power When the battery is criti- Your computer’s battery power is dependent upon many factors, including the pro- cally low, immediately grams you are running, and peripheral devices attached.
Page 61: Conserving Battery Power
Power Management Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that Windows Mobility this may have an affect on computer performance. Center • Lower the brightness level of the LCD display. The system will decrease LCD The Windows Mobility brightness slightly to save power when it is not powered by the AC/DC adapter.
Page 62: Battery Life
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason see “Removing the Battery”...
Page 63: Proper Handling Of The Battery Pack
Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.
Page 64: Battery Faq
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 65 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 8 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 66 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Page 67: Drivers & Utilities
Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utili- ties essential to the operation or improvement of some The Device Drivers & Utilities + User’s Manual disc of the computer’s subsystems. The system takes ad- contains the drivers and utilities necessary for the vantage of some newer hardware components for proper operation of the computer.
Page 68: Driver Installation
Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc and click Install Drivers (button), or Option Driv- Drivers Installer menu below.
Page 69: Manual Driver Installation
Drivers & Utilities Manual Driver Installation Driver Page Click the Browse CD button in the Drivers Installer application and browse to the executable file in the ap- Chipset Page 4 - 5 propriate driver folder. Video Page 4 - 5 Audio Page 4 - 5 Windows Update...
Page 70: Updating/Reinstalling Individual Drivers
Drivers & Utilities Updating/Reinstalling Individual Drivers User Account Control (Win Vista) If you wish to update/reinstall individual drivers it If a User Account Control prompt appears as part of may be necessary to uninstall the original driver.To do the driver installation procedure, click Continue/Al- this go to the Control Panel in the Windows OS and low, and follow the installation procedure as directed.
Page 71: Driver Installation Procedure
Drivers & Utilities Driver Installation Procedure Modem Insert the Device Drivers & Utilities + User’s Manual 1. Click 4.Install Modem Driver > Yes. disc and click Install Drivers (button), or Option Driv- 2. Click OK. ers (button) to access the Optional driver menu. 3.
Page 72: Touchpad
Drivers & Utilities TouchPad Intel MEI Driver 1. Click 6.Install Touchpad Driver > Yes. 1. Click 9.Install Intel MEI Driver > Yes. 2. Click Next > Finish. 2. Click Next > Yes > Next. 3. Click Restart Now to restart the computer. 3.
Page 73: Optional Drivers
Drivers & Utilities Optional Drivers See the pages indicated for the driver installation pro- cedures for any modules included in your purchase op- Windows Update tion. After installing all the drivers make sure you enable Win- dows Update in order to get all the latest security up- dates etc.
Page 74: Wireless Lan
Drivers & Utilities Bluetooth Module Fingerprint Reader Module Note: The operating system is the default setting for See the install procedure in “Fingerprint Reader Bluetooth control in Windows Vista, and does not re- Module” on page 7 - quire a driver. See “Bluetooth Module”...
Page 75: Bios Utilities
BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return to Set- up and restore the Set- Configuration: The Setup utility up Defaults with <F9>.
Page 76: The Power-On Self Test (Post)
BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. If there 2.CPU type is a problem that prevents the system from booting, it will display a system summary 3.Memory status...
Page 77: Failing The Post
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.
Page 78: The Setup Utility
BIOS Utilities The Setup Utility The Phoenix Setup utility tells the system how to configure itself and manage basic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen in Figure 5 - 1 on page 5 - 2 is usually present for a...
Page 79: Setup Screens
BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with menu headings. When you select a Setup menus heading, a new screen appears. Scroll through the features listed on each screen to shown in this section are make changes to Setup.
Page 80: Main Menu
BIOS Utilities Main Menu Phoenix SecureCore(tm) Setup Utility Figure 5 - 2 Main Main Advanced Security Boot Exit Main Menu Item Specific Help System Time: [22:12:05] System Date: [04/18/2008] SATA Port 1 [FUJITSU MHW2160BH-(P] <Tab>, <Shift Tab>, or SATA Port 2 [Optiarc DVD RWDVD CRX8] <Enter>...
Page 81: Sata Port 1/2/3 (Main Menu)
BIOS Utilities SATA Port 1/2/3 (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a hard disk or op- tical device drive on the computer’s SATA Ports. Use the Auto (Type:) setting to have the items configured automatically for you. System/Extended Memory: (Main Menu) This item contains information on the system memory, and is not user configurable.
Page 82: Advanced Menu
BIOS Utilities Advanced Menu Phoenix SecureCore(tm) Setup Utility Figure 5 - 3 Main A A dvanced Advanced Security Boot Exit Advanced Menu I t em Spec i f i c Hel p Installed O/S: [VISTA] SATA Mode Selection: [AHCI] Sel ec t t he oper at i ng DFOROM (Robson) Support: [Enabled] s ys t em i ns t al l ed...
Page 83: Sata Mode Selection (Advanced Menu)
BIOS Utilities SATA Mode Selection (Advanced Menu) This menu is only available if you select the Vista O/S as your operating system. You can configure SATA (Serial ATA) control to operate in either IDE (native/ SATA Mode compatible) or AHCI (Advanced Host Controller Interface) modes from this menu. Selection The SATA mode should be set to AHCI mode for this system (unless you are sure If you have installed the...
Page 84: Boot-Time Diagnostic Screen: (Advanced Menu)
BIOS Utilities Boot-time Diagnostic Screen: (Advanced Menu) Use this menu item to enable/disable the Boot-time Diagnostic Screen. Legacy OS Boot: (Advanced Menu) Enable this item to support only system boot from the Legacy OS (e.g Windows Vis- ta). If disabled the system will attempt to boot from the EFI (Extensible Firmware Interface) before the Legacy OS.
Page 85: Security Menu
BIOS Utilities Security Menu Phoenix SecureCore(tm) Setup Utility Security Menu Main Advanced Security S S e e c c u u r r i i t t y y Boot Exit changes Item Specific Help Supervisor Password Is: Clear make here affect the User Password Is: Clear access to the Setup...
Page 86: Set User Password (Security Menu)
BIOS Utilities Set User Password (Security Menu) You can set a password for user mode access to the Phoenix SecureCore Setup Utility. This will not affect access to the computer OS, (only the Setup utility) unless Password Warning you choose to set a Password on Boot (see below). Many menu items in the Phoenix If you set a boot pass- SecureCore Setup Utility cannot be modified in user mode.
Page 87: Boot Menu
BIOS Utilities Boot Menu Phoenix SecureCore(tm) Setup Utility Figure 5 - 5 Main Advanced Security Boot Exit Boot Menu Item Specific Help Boot priority order: USB FDC: Keys used to view or USB KEY: configure devices: USB HDD: Up and Down arrows IDE CD: Optiarc CDRWDVD CRX890S-(P select a device.
Page 88: Exit Menu
BIOS Utilities Exit Menu Figure 5 - 6 Phoenix SecureCore(tm) Setup Utility Main Advanced Security Boot Exit Exit Menu Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to CMOS. Discard Changes Save Changes Help...
Page 89: Upgrading The Computer
Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- Warranty Warning lined to make the desired upgrades. If you have any trouble or problems you can con- tact your service representative for further help. Before you begin you will need: Please check with your service representative...
Page 90: When Not To Upgrade
Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts.You should not perform any of these upgrades if: Power Safety Warning Before you undertake • Your system is still under warranty or a service contract upgrade proce- •...
Page 91: Removing The Battery
Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Please check with your Turn the computer off, turn it over and remove the battery. service representative Slide latch...
Page 92: Upgrading The Hard Disk Drive
Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive(s) can be taken out to accommodate other 2.5" serial (SATA) HDD System Warning hard disk drives with a height of 9.5mm (h) (see “Storage” on page C - 3).
Page 93 Upgrading The Computer Carefully (a fan and cable are attached to the under side of the cover) lift up the bay cover. Carefully disconnect the fan cable , and remove the cover Fan Cable Make sure you recon- nect the fan cable before screwing down the bay cover.
Page 94 Upgrading The Computer Pull the hard disk assembly in the direction of the arrow Figure 6 - 5 Hard Disk Pull Carefully remove the hard disk assembly in the direction of the arrow Figure 6 - 6 Hard Disk Removal 6 - 6 Upgrading the Hard Disk Drive...
Page 95 Upgrading The Computer Remove screws to separate the hard disk from the bracket. Reverse the process to install any new hard disk. Figure 6 - 7 Hard Disk Bracket Removal Upgrading the Hard Disk Drive 6 - 7...
Page 96: Upgrading The System Memory (Ram)
Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 204 pin Small Outline Dual In-line (SO- DIMM) DDR III (DDR3) type memory modules (see “Memory” on page C - The total memory size is automatically detected by the POST routine once you turn on your computer.
Page 97 Upgrading The Computer Carefully (a fan and cable are attached to the under side of the cover) lift up the bay cover. Carefully disconnect the fan cable , and remove the cover Fan Cable Make sure you recon- nect the fan cable before screwing down the bay cover.
Page 98 Upgrading The Computer The RAM module will pop-up, and you can remove it. Contact Warning Be careful not to touch the metal pins on the module’s connecting edge. Even the cleanest hands have oils which can attract particles, and degrade the module’s performance.
Page 99: Upgrading The Optical (Cd/Dvd) Device
Upgrading The Computer Upgrading the Optical (CD/DVD) Device Turn off the computer, and turn it over and remove the battery. Locate the component bay cover and remove screws Figure 6 - 12 Removing the CD/ DVD Device Upgrading the Optical (CD/DVD) Device 6 - 11...
Page 100 Upgrading The Computer Carefully (a fan and cable are attached to the under side of the cover) lift up the bay cover. Carefully disconnect the fan cable , and remove the cover Fan Cable Make sure you recon- nect the fan cable before screwing down the bay cover.
Page 101: Modules
Modules Chapter 7: Modules Overview This chapter contains the information on the various modules (some of which are optional) which may come with your computer, depending on the configuration purchased. If you are unsure please contact your service representative. The chapter includes information on the following: •...
Page 102: Bluetooth Module
Modules Bluetooth Module The optional Bluetooth module allows you to connect your computer to Bluetooth Wireless Device enabled devices such as other computers, desktop computers, mobile phones, print- Operation Aboard ers, digital cameras, PDAs, headsets etc. using a short-range radio frequency. Aircraft The use of any portable Use the Fn + F12 key combination (see...
Page 103: Bluetooth Configuration In Windows Vista
Modules Bluetooth Configuration in Windows Vista Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Bluetooth Taskbar Make the device discoverable (to do this check your device documentation). Icon If you cannot see the To Turn the Bluetooth Module On Bluetooth icon in the...
Page 104 Modules To Add a Bluetooth Device Access the Bluetooth Devices control panel. Click Options (tab), and make sure that Allow Bluetooth devices to connect to this computer check box (Connections) has a tick inside it. Click Devices (tab), and then click Add. The Add Bluetooth Device Wizard will appear.
Page 105 Modules To Change Settings for the Bluetooth Device Access the Bluetooth Devices control panel. Click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click General, type a new name and click OK). •...
Page 106: Wireless Lan Module
Modules Wireless LAN Module If you have included an Intel® Wi-Fi Link 5100/5300 Series (802.11 a/g/n) WLAN Wireless Device module, or 3rd Party 802.11b/g WLAN module in your purchase option, make sure Operation Aboard that the Wireless LAN module is on before installing the driver. Aircraft The use of any portable Use the Fn + F11 key combination (see...
Page 107: Intel® Wi-Fi Link 5100/5300 Series (802.11 A/G/N) Driver Installation
Modules Intel® Wi-Fi Link 5100/5300 Series (802.11 a/g/n) Driver Installation 1. Make sure the module is powered on, then insert the Device Drivers & Util- ities + User’s Manual disc into the CD/DVD drive. 2. Click Option Drivers (button). 3. Click 1.Install Wireless Lan Driver > Yes. 4.
Page 108: Connecting To A Wireless Network
Modules Connecting to a Wireless Network Make sure the Wireless LAN module is turned on. Click the taskbar wireless icon , and then click Connect to a network (or right- click the icon , and then click Connect to a network). Figure 7 - 5 Taskbar Menus Click icon...
Page 109 Modules Click a network, and then click Connect. If you do not see a network you want to connect to, click Set up a connection or network (a list of options will appear allowing manual searching, and creating a new network). Figure 7 - 7 Connecting Move the cursor over the taskbar icon...
Page 110 Modules To disconnect from the wireless network you can click the taskbar wireless icon , and then select Connect or disconnect to access the network menu, and click Disconnect (or right-click the icon , and then click Disconnect from). Security Enabled Networks You should try to make sure that any network...
Page 111: Pc Camera Module
Modules PC Camera Module Before installing the driver, make sure the PC Camera is on. Use the Fn + F10 key Latest PC Camera combination (see Table 1 - 4, on page 1 - 10) to toggle power to the PC Camera Driver Information module.
Page 112: Pc Camera Audio Setup
Modules PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
Page 113 Modules Figure 7 - 10 Audio Setup for PC Camera Right-click PC Camera Module 7 - 13...
Page 114 Modules BisonCap BisonCap is a video viewer for general purpose video viewing and testing, and for capturing video files to .avi format. Pre-Allocating File Space Run the BisonCap program from the Start > Programs/All Programs > Bison- Cam menu (it is recommended that you set the capture file before the capture You may pre-allocate process - see Set Capture File below).
Page 115 Modules Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
Page 116 Modules Eliminating Screen Flicker If you find that the video screen in the BisonCap program is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the BisonCap program. Go to Options and scroll down to select Video Capture Filter..Click either 50Hz or 60Hz under Frequency in Property Page (tab).
Page 117 Modules Zoom The BisonCap program allows you to zoom the camera in and out. Run the BisonCap program. Go to Zoom and select Zoom Out/Zoom In. Figure 7 - 12 Zoom/Setting Snapshot Folder Taking Still Pictures The Snapshot folder’s default location is on the The BisonCap program allows you to take still pictures.
Page 118: G Module
Modules 3.5G Module If you have included an optional 3.5G module (see “Communication” on page A - Power Safety for specification details) in your purchase option, you will have the appropriate Warning software provided for your module. Follow the instructions below to install the USIM card (which will be provided by your service provider), and then install the Before you undertake any installation proce-...
Page 119 Modules Slide the SIMLOCK towards the hinge (in the direction of the arrow in Figure 7 - 14) in order to release the lock and lift it up. Figure 7 - 14 SIMLOCK Open Insert the USIM card as illustrated (Figure 7 - 15) and close the SIMLOCK.
Page 120: 3G Watcher Application
Modules 3G Watcher Application With the 3.5G module and USIM card (provided by your service provider) installed you may then install the 3G Watcher application. The 3.5G Watcher application al- Wireless Device Operation Aboard lows you to directly access your 3.5G internet service from the computer. Aircraft 3G Watcher Application Installation The use of any portable...
Page 121 Modules Setting Up a Carrier Profile Although the connection information is stored on the USIM card supplied by the ser- vice provider, you will need to set up the appropriate carrier profile from the 3G Watcher software. Power on the 3.5G module using the Fn + key combination.
Page 122 Modules You can then enter a new profile name or choose a profile from the drop-down list provided by the software (see the sidebars for information on the profile details). Figure 7 - 18 User Options Profile Information Profile Details Click General and/or Ad- vanced (and the sub- If you have chosen the...
Page 123 Modules Connecting to the Service Provider Power on the 3.5G module using the Fn + key combination. You can access the 3G Watcher application from the Start menu (Start > Programs/All Programs > Sierra Wireless > 3G Watcher), or by clicking the desktop icon The software will run and display the service provider name (see “Setting Up a...
Page 124 Modules When the connection is successful a taskbar notification will appear (as below). Figure 7 - 22 Connected Taskbar Notification You can then access the internet, download e-mail etc. as per any internet connection. While you are connected the taskbar icon will be green (it will be red when the program is running but not connected).
Page 125 Modules 12. If you click the 3G Watcher close icon a message will be displayed asking you to click OK to confirm the program exit. Figure 7 - 24 Exit Warning 13. Exiting the program DOES NOT turn off the 3.5G module, and you will need to press the Fn + key combination to turn off the module (pay careful attention to this aboard aircraft - see...
Page 126: Short Messaging Service
Modules Short Messaging Service In addition to standard internet services you may also send and receive SMS text messages using the 3G Watcher program, if your service supports SMS. Reading SMS Messages The SMS message indicator in the main window will notify you of any new messages received.
Page 127: Fingerprint Reader Module
Modules Fingerprint Reader Module The optional fingerprint reader Protector Suite Software provides a high level Password Warning of security for your computer. A further level of security and control is provided in the BIOS (see “Security Menu” on page 5 - 11).
Page 128: Fingerprint Reader Driver Installation
Modules Fingerprint Reader Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. Help & Manual 2. Click Option Drivers. Right-click the taskbar icon 3. Click 4.Install FingerPrint Driver > Yes. to bring up the menu to 4.
Page 129: User Enrollment (Application Version 1)
Modules User Enrollment (Application Version 1) Click Start > Programs/All Programs > Protector Suite QL > User Enrollment, or double click the taskbar icon On the first run of the program you will be asked to click the button to accept the license, and then click OK.
Page 130 Modules Click the button above any of the fingers to begin the enrollment process for that finger. 10. Swipe the finger three times to enroll that finger. Fingerprint 11. Repeat the process for all the fingers you wish to enroll (see sidebar), and then Enrollment click Next.
Page 131 Modules 15. Right-click the taskbar icon to bring up the Control Center that allows you to Edit Fingerprints, Start Control Center, access the Help menu etc. You can also run the Control Center etc. from the Protector Suite QL item in the Programs/ All Programs menu.
Page 132: User Enrollment (Application Version 2)
Modules User Enrollment (Application Version 2) Click Start > Programs/All Programs > Protector Suite QL > User Enrollment, or double click the taskbar icon Click Initialize. Figure 7 - 28 Initialize Fingerprints On the first run of the program you will be asked to click the button to accept the license, and then click OK.
Page 133 Modules If you have not set a Windows password you will be prompted to do so (note: If you have not set a password Protector Suite QL cannot secure access to your computer). Click Next. You will then be prompted to enter your Windows password and click Next. Select either to use the fingerprint reader alone for authentication, or choose both the fingerprint reader and the Windows password, and then click Next.
Page 134 Modules 11. Click the button above any of the fingers to begin the enrollment process for that finger. 12. Swipe the finger five times to enroll that finger. Fingerprint 13. Repeat the process for all the fingers you wish to enroll (see sidebar), and then Enrollment click Next.
Page 135 Modules 17. Right-click the taskbar icon to bring up the Control Center that allows you to Edit Fingerprints, register applications, manage Password Bank, File Safe and access the Help menu etc. You can also run the Control Center etc. from the Protector Suite QL item in the Programs/All Programs menu.
Page 136: Fingerprint Control Center Features (Application Version 2)
Modules Fingerprint Control Center Features (Application Version 2) Application Launcher The Application Launcher allows you to register applications to be launched when assigned to a particular finger. Simply copy the application icon on to one of the reg- istered fingers and ten click OK to close the application window. Once registered the application will launch when you swipe the appropriate finger across the sensor.
Page 137: Intel Turbo Memory Module
Modules Intel Turbo Memory Module If you have included an Intel Turbo Memory (Robson) NAND flash memory card e-SATA Port module in your purchase option, then you will need to enable the option in the BIOS Support (see “Advanced Menu” on page 5 - 8 ) BEFORE installing the Windows Vista op- erating system software (do not enable this option in Windows XP or on a Windows Note that the Intel Ma-...
Page 138 Modules 6. Set the CD/DVD-ROM Drive (make sure the Microsoft Windows Vista OS disc is inserted) as the first device in the boot order from the Boot priority order menu. ReadyBoost Issue 7. Select Exit Saving Changes from the Exit menu (or press F10 and Enter) and press Enter to exit the BIOS and reboot the computer.
Page 139 Modules Intel Turbo Memory Dashboard (User Pinning Supported Only) The Intel Turbo Memory Dashboard allows you to pin an application or file to load into the Intel Turbo Memory NAND cache for performance acceleration. Help ® Run the Intel Turbo Memory Dashboard from the Programs/All Programs Click the Help icon ®...
Page 140 Modules Pinning an Application (User Pinning Supported Only) 1. The Intel ® Turbo Memory Dashboard allows you to select files and applications to accelerate and therefore open faster and display quicker. Unpinning an 2. Applications will be listed in the Applications Window on the right. Application 3.
Page 141 Modules Custom File Sets (User Pinning Supported Only) A Custom File Set allows you to group applications and files to accelerate. These sets can be moved easily in and out of the Accelerated Window which is of benefit when space is limited. You need to create the custom file set before dragging the set to the accelerated window.
Page 142 Modules Intel Turbo Memory Console (All Modules) 1. Run the Intel ® Turbo Memory Console from the Programs/All Pro- grams menu (Intel ® Turbo Memory). Windows 2. You can enable/disable Windows ReadyBoost and Windows ReadyDrive ReadyBoost from the Intel ® Turbo Memory Console. If your module supports User Pinning (i.e.
Page 143: Troubleshooting
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 144: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 145: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Page 146: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 147: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 148 Troubleshooting • Don’t over complicate things. The less you have to deal with then the easier the source of the problem may be found; Example - if your computer has many devices plugged into its ports, and a number of programs running, then it will be difficult to determine the cause of a problem.
Page 149: Problems & Possible Solutions
Troubleshooting Problems & Possible Solutions Problem Possible Cause - Solution You turned the power on Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present and but it doesn’t work. seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
Page 150 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the vents/fan intakes are not blocked. If this hot. doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 151 Troubleshooting Problem Possible Cause - Solution forget boot If you forget the password, you may have to discharge the battery of the CMOS. Contact your password. service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
Page 152 Troubleshooting Problem Possible Cause - Solution The TouchPad doesn’t The Touchpad has been disabled. Press the Touchpad toggle (Fn + F1) key combination (make work. sure you have installed the Touchpad driver. The system freezes or The system’s power saving features have timed-out. Use the AC/DC adapter, press a key on the the screen goes dark.
Page 153 Troubleshooting Problem Possible Cause - Solution The Hibernate function You have a computer with 4GB of RAM and have installed Windows Vista Service Pack 1. This has disappeared. is a known issue if your computer has 4GB of RAM and is running Windows Vista Service Pack 1.
Page 154 Troubleshooting Problem Possible Cause - Solution Nothing appears on the You have selected an external display as the default display device. The PC Camera application screen when the PC software needs to be run while the default notebook LCD is the selected display device. Camera software is run.
Page 155 Troubleshooting Problem Possible Cause - Solution Connect You have clicked the connect to a network button in the Windows Mobility Center while the network window does Wireless LAN module is powered OFF. This is a know issue and it is recommended that you do not display any available not use the Windows Mobility Center to control the WLAN module power and access.
Page 156: Screen Resolution Error
Troubleshooting Screen Resolution Error If you are experiencing either screen resolution reduction, or screen flickering after resuming from Sleep in Windows Vista only then follow the instructions below to fix this problem. This error arises in compliance with Windows Vista policy, which triggers TMM (Transient Multi-Monitor Manager) when the notebook lid (S3) is closed.
Page 157 Troubleshooting Double-click Task Scheduler Library > Microsoft > Windows. Click MobilePC to open the control panel. Right-click TMM and select Disable. Figure 8 - 2 - TMM Disable Close all the control panels. Screen Resolution Error 8 - 15...
Page 158 Troubleshooting 8 - 16...
Page 159: Interface (Ports & Jacks)
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the ports & jacks which allow your computer to commu- nicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...
Page 160: Ports And Jacks
Interface (Ports & Jacks) Ports and Jacks Item Description Card Reader The card reader allows you to use the following digital storage cards: MMC (MultiMedia Card) RS MMC (requires PC adapter) SD (Secure Digital) Mini SD (requires PC adapter) MS (Memory Stick) MS Duo (requires PC adapter) MS (Memory Stick Pro) DC-In Jack...
Page 161: Hdmi-Out Port
Interface (Ports & Jacks) Item Description HDMI-Out Port The HDMI-Out (High-Definition Multimedia Interface) is an audio/video connector interface for transmitting uncompressed digital streams. This allows you to connect an external monitor, TV or HDMI Flat Panel Display etc. as a display device (see “Attaching Other Displays”...
Page 162: Rj-11 Phone Jack
Interface (Ports & Jacks) Item Description RJ-11 Phone Jack This port connects to the built-in modem. You may plug the telephone line directly into this RJ-11 telephone connection. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port. RJ-45 LAN Jack This port supports LAN (Network) functions.
Page 163: Nvidia Video Driver Controls
NVIDIA Video Driver Controls Appendix B: NVIDIA Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Resolution Error NVIDIA Video Driver Installation If you are experiencing Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - screen resolution...
Page 164: Nvidia Control Panel
NVIDIA Video Driver Controls NVIDIA Control Panel More advanced video configuration options are provided in the NVIDIA Control NVIDIA Control Panel tab. Panel Open the Display Settings (see page 17) control panel. To access the Ge- Click Advanced Settings (button). Force..
Page 165 NVIDIA Video Driver Controls The NVIDIA Control Panel provides additional video configuration controls and tools which allow quick access to features such as display configuration, 3D Settings and Help menus etc. Navigating the Control Panel Navigate through the control panels in much the same way as you would a web page.
Page 166 NVIDIA Video Driver Controls The Help menus provide index and search features, and direct links to the NVIDIA website etc. Figure B - 3 Help Menus B - 4 NVIDIA Control Panel...
Page 167: Attaching Other Displays
NVIDIA Video Driver Controls Attaching Other Displays Note that you can use a DVI cable connected to the DVI-Out port, or an HDMI Display Devices (High-Definition Multimedia Interface) cable connected to the HDMI-Out port to connect an external display (if you are using an older type of monitor you can use a Besides built-in converter to convert the signal from DVI to VGA).
Page 168 NVIDIA Video Driver Controls Configuring an External Display using the NVIDIA Control Panel Alternatively you can use the NVIDIA control panel to configure any attached dis- plays. Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Go to NVIDIA Control Panel (see “NVIDIA Control Panel”...
Page 169 NVIDIA Video Driver Controls HDMI Audio Configuration As HDMI (High-Definition Multimedia Interface) carries both audio and video sig- nals you will need to configure the audio output as per the instructions below. The Playback Options settings will depend upon the video card you have installed in your purchase option. If your video card has Windows Audio Setup for HDMI hardware support for...
Page 170 NVIDIA Video Driver Controls HDMI Notes • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • If you disconnect the HDMI cable the default audio playback device will not If you are using a third revert to speakers until the computer is restarted (if you do not wish to restart the party application to play...
Page 171: Display Modes
NVIDIA Video Driver Controls Display Modes Single Display Mode Resolution Error Only one of your displays is used. If you are experiencing screen resolution prob- Clone Mode lems/screen flickering after Clone Mode simply shows an exact copy of the Primary display desktop on the other resuming from Sleep in display(s).
Page 172 NVIDIA Video Driver Controls Using New Display Detected to Enable Extended Mode Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Windows Mobility Center control panel (Mobile PC >...
Page 173 NVIDIA Video Driver Controls Using Display Settings to Enable Extended Mode Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Click Start, and click Control Panel (or point to Settings and click Control Display Settings Panel).
Page 174: Enabling Tv Display
NVIDIA Video Driver Controls Enabling TV Display To display desktop images on a TV, connect the TV to your computer by using an Detect Displays HDMI cable/DVI cable from the TV to the HDMI-Out port/DVI-Out port at the rear of the computer. To get a full range of dis- play options click “My dis- You will need to enable the TV display from the NVIDIA Control Panel as per the...
Page 175: Changing The Tv Signal Format
NVIDIA Video Driver Controls Changing the TV Signal Format When the TV is enabled as a display device, click the sub-menus under Video & Television. Click “Change the signal or HD format”. Select the TV signal format (the menu allows you to select TV format by country if you are unsure of your TV format).
Page 176 NVIDIA Video Driver Controls B - 14...
Page 177: Specifications
Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.
Page 178: Core Logic
Specifications Feature Specification Core Logic Intel(R) PM45 + ICH9M Chipset Flat Panel TFT (For One of the Following Options) 15.4" WXGA (1280 * 800) TFT LCD (Glare Type) 15.4" WXGA+ (1440 * 900) TFT LCD 15.4" WSXGA+ (1680 * 1050) TFT LCD (Glare Type) 15.4"...
Page 179: Video Adapter Options
Specifications Feature Specification Video Adapter NVIDIA GeForce 9600M GS PCI-E Video Card NVIDIA GeForce 8800M GTX PCI-E Video Card Options 256MB GDDR3 Video RAM On Board 512MB GDDR3 Video RAM On Board MS DirectX® 10.0 Compatible MS DirectX® 10.0 Compatible Supports HDCP Supports HDCP Video Card...
Page 180: Audio
Specifications Feature Specification Card Reader Embedded 7-in-1 Card Reader (MS/ MS Pro/ SD/ Mini SD/ MMC/ RS MMC/ MS Duo) Note: MS Duo/ Mini SD/ RS MMC Cards Require a PC Adapter Audio High Definition Audio Built-In Microphone 3D Stereo Enhanced Sound System 2 * Built-In Speakers Sound-Blaster PRO™...
Page 181: Communication
Specifications Feature Specification Communication Built-In 56K Fax Modem Built-In 10/100/1000Mb Base-TX Ethernet LAN Intel® WiFi Link 5300 Series (3*3 - 802.11a/g/n) Wireless LAN Mini-Card Module (Option) Intel® WiFi Link 5100 Series (1*2 - 802.11a/g/n) Wireless LAN Mini-Card Module (Option) 3rd Party 802.11b/g Wireless LAN Mini-Card Module with USB interface (Option) Bluetooth 2.0 + EDR (Enhanced Data Rate) Module (Factory Option) 1.3M or 2.0M Pixel PC Camera Module with USB interface (Factory Option) 3.5G Module:...
Page 182 Specifications Feature Specification Power Full Range AC/DC Adapter – AC in 100 - 240V, 50 - 60Hz DC Output 20V, 6A (120 Watts) Easy Changeable 8-Cell Smart Lithium-Ion 4400mAH Main Battery Environmental Temperature Relative Humidity Spec Operating: 5°C - 35°C Operating: 20% - 80% Non-Operating:...
Page 183: Windows Xp Information
Windows XP Information Appendix D: Windows XP Information This Appendix contains information (including control panel information, driver installation etc.) for users of the Windows XP OS. D - 1...
Page 184: D - 2 Dvd Regional Codes
Windows XP Information DVD Regional Codes Changing DVD Regional Codes Go to the Control Panel and double-click System > Hardware (tab), click Device Manager, then click the + next to DVD/CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties dialogue box, and select the DVD Region (tab) to bring up the control panel to allow you to adjust the regional code.
Page 185: Windows Xp Start Menu & Control Panel
Windows XP Information Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 186: Audio Features
Windows XP Information Audio Features You can configure the audio options on your computer from the Sounds and Audio Sound Volume Devices Windows control panel. For advanced options double-click the Realtek Adjustment HD Audio Manager icon in the taskbar (or click the control panel) to bring up How high the sound vol- the Realtek Audio Configuration menus.
Page 187: Function/Hot Key Indicators
Windows XP Information Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators (see the table below) are available when the hot key utility is in- stalled (see “Hot Key”...
Page 188: Video Features
Windows XP Information Video Features You can switch display devices, and configure display options, from the Display Properties control panel in Windows as long as the appropriate video driver is installed. To access Display Properties in Windows: Click Start, point to Settings and click Control Panel (or just click Control Panel). Double-click Display (icon) - In the Appearances and Themes category.
Page 189: Display Properties & Nvidia Control Panel
Windows XP Information Display Properties & NVIDIA Control Panel Figure D - 4 - Display Properties & NVIDIA Control Panel Video Card Options Note that card types, specifications and drivers are subject to continual updates and changes. Check with your service center for the latest details on video cards supported.
Page 190: D - 8 Nvidia Video Driver Controls
Windows XP Information NVIDIA Video Driver Controls Access the NVIDIA Control Panel as indicated on page D - 6. You may make Navigating the changes to the video and display settings by clicking the appropriate menu item. Control Panel Navigate through the control panels in much the same way as you would a web page.
Page 191: Display Devices And Modes (Nvidia
Windows XP Information Display Devices and Modes (NVIDIA) Note that you can use a DVI cable connected to the DVI-Out port, or an HDMI (High-Definition Multimedia Interface) cable connected to the HDMI-Out port to Display Devices connect an external display (if you are using an older type of monitor you can use an You can use the Fn + F7 adapter to convert the signal from DVI to VGA).
Page 192: Attaching Other Displays
Windows XP Information Attaching Other Displays Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Go to the NVIDIA Control Panel. Click Display, and then click Set up multiple displays. Choose the nView display mode you wish to use. Select the displays you want to use (if your display is not shown click “My Display is not shown in the list...”...
Page 193 Windows XP Information To Enable Extended Desktop (Windows Display Properties) Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Click Start, point to Settings (or click Control Panel) and click Control Panel (if you are in Category View choose Appearance and Themes).
Page 194: Hdmi Audio Configuration
Windows XP Information HDMI Audio Configuration As HDMI (High-Definition Multimedia Interface) carries both audio and video sig- nals you will need to configure the audio output as per the instructions below. Windows Audio Setup for HDMI 1. Connect a device with HDMI support to the HDMI-Out port. 2.
Page 195 Windows XP Information HDMI Note • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • If you disconnect the HDMI cable the default audio playback device will not If you are using a third revert to speakers until the computer is restarted (if you do not wish to restart the party...
Page 196: Power Management Features
Windows XP Information Power Management Features The Power Options control panel icon in Windows (see page 3) allows you to configure power management features for your computer. You may conserve power through individual components such as the monitor or hard disk, or you may use either Stand by or Hibernate mode to conserve power throughout the system.
Page 197: System Power Options
Windows XP Information Each Windows Power Scheme will also adjust the processor performance of your machine in order to save pow- er. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the computer is powered from an AC power source.
Page 198: Stand By
Windows XP Information Stand by Stand by saves the least amount of power, but takes the shortest time to return to full operation. During Stand by the hard disk is turned off, and the CPU is made to idle at its slowest speed. All open applications are retained in memory.
Page 199: Configuring The Power Button
Windows XP Information Configuring the Power Button The power button may be set to send the computer in to either Stand by or Hibernate mode. In Stand by mode, the LED will blink green. In Hibernate mode the LED will be off (battery). If you are in a power saving mode set to save power through individual components (e.g.
Page 200: Battery Information
Windows XP Information Battery Information Please follow these simple guidelines to get the best use out of your battery. New Battery Always completely discharge, then fully charge, a new battery (see “Battery FAQ” on page D - 21). Battery Life Your computer’s battery life is dependent upon many factors, including the programs you are running, and pe- ripheral devices attached.
Page 201: Recharging The Battery With The Ac/Dc Adapter
Windows XP Information Battery life may be shortened through improper maintenance. To optimize the life and improve its perfor- mance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason “Removing the Battery”...
Page 202: Proper Handling Of The Battery Pack
Windows XP Information Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.
Page 203: Battery Faq
Windows XP Information Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer by yourself even when you see a message that indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 204: D - 22 Driver Installation
Windows XP Information Driver Installation Check the driver installation order from Table D - 4, on page D - 23 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the Drivers Installer menu below.
Page 205 Windows XP Information WinXP SP2 Driver Page # Chipset D - 25 Manual Driver Installation Click the Browse CD button in the Audio D - 25 Drivers Installer application and Video D - 25 browse to the executable file in the Modem D - 25 appropriate driver folder.
Page 206: Updating/Reinstalling Individual Drivers
Windows XP Information Updating/Reinstalling Individual Drivers If you wish to update/reinstall individual drivers it may be necessary to uninstall the original driver.To do Windows XP Service Pack 3 this go to the Control Panel in the Windows OS and Make sure you install Windows XP Service Pack 3 (or a double-click the Add/Remove Programs item.
Page 207: Audio
Windows XP Information Chipset Modem 1. Click 1.Install Chipset Driver > Yes. 1. Click 4.Install Modem Driver > Yes. 2. Click Next > Yes > Next > Next. 2. Click OK. 3. Click Finish to restart the computer. 3. The modem is now ready for configuration. Audio 1.
Page 208: Touchpad
Windows XP Information TouchPad Module Drivers 1. Click 6.Install Touchpad Driver > Yes. See the following pages for the driver installation pro- cedures for any of the optional modules included in 2. Click Next > Next > Next. your purchase configuration. 3.
Page 209: Bluetooth Module
Windows XP Information Bluetooth Module The operating system’s Bluetooth Devices control panel is used to configure the Bluetooth settings in Windows XP, and therefore does not require a driver. Use the Fn + F12 key combination (see “Function/Hot Key Indi- cators”...
Page 210 Windows XP Information Bluetooth Local Area Connection Icon If you want to display the Local Area Connection icon for the Bluetooth connection in the taskbar, set it up as follows: Wireless Device Operation Aboard 1. Access the Network Connections control panel in Windows (Start > Settings > Aircraft Network Connections OR Start >...
Page 211: Bluetooth Configuration In Windows Xp
Windows XP Information Bluetooth Configuration in Windows XP Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Bluetooth Taskbar Make the device discoverable (to do this check your device documentation). Icon To Turn the Bluetooth Module On If you cannot see the...
Page 212: To Add A Bluetooth Device
Windows XP Information To Add a Bluetooth Device 1. Access the Bluetooth Devices control panel. 2. Click Options (tab), and make sure that Allow Bluetooth devices to connect to this computer check box (Connections) has a tick inside it. 3. Click Devices (tab), and then click Add. 4.
Page 213 Windows XP Information To Change Settings for the Bluetooth Device Access the Bluetooth Devices control panel. Click on the device you want to change and click Properties to: • Change the name of the device (click General, type a new name and click OK). •...
Page 214: D - 32 Wireless Lan Module
Windows XP Information Wireless LAN Module If you have included an Intel® Wi-Fi Link 5100/5300 Series (802.11 a/g/n) WLAN Wireless Device module, or 3rd Party 802.11b/g WLAN module in your purchase option, make sure Operation Aboard that the Wireless LAN module is on before installing the driver. Aircraft The use of any portable Use the Fn + F11 key combination (see...
Page 215: Intel Wlan Driver Installation
Windows XP Information Intel WLAN Driver Installation 1. Make sure the module is powered on, then insert the Device Drivers & Util- ities + User’s Manual disc into the CD/DVD drive. Download 2. Make sure the computer has a working internet connection. Prerequisite Files 3.
Page 216 Windows XP Information 15. Configure the settings by going to the Intel PROSet Wireless WiFi Connection Utility (Start > Pro- grams/All Programs > Intel PROSet Wireless WiFi Connection Utility), or by double-clicking the taskbar icon 16. Click to select any available network, and click Connect to establish a connection. 17.
Page 217: 802.11B/G Wlan Driver Installation
Windows XP Information 802.11b/g WLAN Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. Network 2. Click Option Drivers (button). Connection 3. Click 1.Install WLAN Driver > Yes. Use the Windows Net- 4.
Page 218: D - 36 Pc Camera Module
Windows XP Information PC Camera Module Before installing the optional PC Camera module driver use the Fn + F10 key com- Taking Still Pictures bination to toggle power to the module. The PC Camera module uses the BisonCap application to capture video files. Double-click Computer icon on the desktop, or go the Start...
Page 219: Pc Camera Driver Installation
Windows XP Information PC Camera Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. 2. Click Option Drivers (button). 3. Click 2.Install WebCam Driver > Yes. 4.
Page 220: Pc Camera Audio Setup (All Camera Modules
Windows XP Information PC Camera Audio Setup (all camera modules) If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Go to the Start menu and point to Settings (or just click Control Panel) and click Control Panel, then double- click the Sounds &...
Page 221: Bisoncap
Windows XP Information BisonCap BisonCap is a video viewer for general purpose video viewing and testing, and for capturing video files to .avi format. Pre-Allocating File Space Run the BisonCap application from the Start > Programs/All Programs > Bison- You may pre-allocate Cam menu (it is recommended that you set the capture file before the capture the file size (File >...
Page 222: Reducing Video File Size
Windows XP Information Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties) If necessary you can remove the recorded video file to a removable medium e.g.
Page 223: Eliminating Screen Flicker
Windows XP Information Eliminating Screen Flicker If you find that the video screen in the BisonCap program is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the BisonCap program. Go to Options and scroll down to select Video Capture Filter..Click either 50Hz or 60Hz under Frequency in Property Page (tab).
Page 224 Windows XP Information Zoom The BisonCap program allows you to zoom the camera in and out. 1. Run the BisonCap program. 2. Go to Zoom and select Zoom Out/Zoom In. Figure D - 23 Zoom/Setting Snapshot Folder Taking Still Pictures The BisonCap programs allows you to take still pictures.
Page 225: 3.5G Module
Windows XP Information 3.5G Module If you have included an optional 3.5G module in your purchase option follow the instructions on page 7 - 19 install the USIM card (which will be provided by your service provider), and then install the application. Before installing the application, make sure that the 3.5G module is on.
Page 226: D - 44 Fingerprint Reader Module
Windows XP Information Fingerprint Reader Module If you have included the fingerprint reader in your purchase option you will need to Help & Manual install the driver as per the instructions below. Right-click the taskbar icon Make sure you have administrator’s rights to your computer, and have a Windows to bring up the menu to password enabled for full security protection.
Page 227: User Enrollment (Application Version 1
Windows XP Information User Enrollment (Application Version 1) Click Start > Programs/All Programs > Protector Suite QL > User Enrollment, or double click the taskbar icon On the first run of the program you will be asked to click the button to accept the license, and then click OK. Click Next and select “Enrollment to the hard disk”, and click Finish.
Page 228 Windows XP Information 10. Click Finish. 11. Click any of the headings under “Learn more about:” to get more information on any topic. 12. Click Close. 13. Right-click the taskbar icon to bring up the menu that allows you to Edit Fingerprints, start Control Center, access the Help menu etc.
Page 229: User Enrollment (Application Version 2
Windows XP Information User Enrollment (Application Version 2) Click Start > Programs/All Programs > Protector Suite QL > User Enrollment, or double-click the taskbar icon Click Initialize. On the first run of the program you will be asked to click the button to accept the license, and then click OK. Click Next and select “Enrollment to the hard disk”, and click Finish.
Page 230 Windows XP Information 11. Swipe the finger five times to enroll that finger. 12. Repeat the process for all the fingers you wish to enroll (see sidebar), and then click Next > Finish. 13. Click “Help” in the Fingerprint Control Center to get more information on any topic. 14.
Page 231: Fingerprint Control Center Features (Application Version 2
Windows XP Information Fingerprint Control Center Features (Application Version 2) Application Launcher The Application Launcher allows you to register applications to be launched when assigned to a particular fin- ger. Simply copy the application icon on to one of the registered fingers and ten click OK to close the application window.
Page 232 Windows XP Information D - 50...

Clevo M860TU User Manual

Quick Start Guide

Storage Devices, Mouse, Audio & Printer

Power Management

Drivers & Utilities

BIOS Utilities

Upgrading the Computer

Modules

Troubleshooting

Interface (Ports & Jacks)

NVIDIA Video Driver Controls

Specifications

Windows XP Information

Quick Links

Related Manuals for Clevo M860TU

Summary of Contents for Clevo M860TU
