  • Page 3 Preface Notebook Computer M815P Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the M815P series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. VIII...

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 Schematic Diagrams......... B-1 Overview ..................1-1 System Block Diagram ..............B-2 System Specifications ..............1-2 Pineview CPU 1/4 ................B-3 External Locator - Top View with LCD Panel Open ......1-4 Pineview CPU 2/4 ................B-4 External Locator - Front & Right side Views .........1-5 Pineview CPU 3/4 ................B-5 External Locator - Left Side &...
  • Page 12 Preface...

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the M815P series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about driv- ers (e.g.

  • Page 14: System Specifications

    Introduction System Specifications Storage Communication Processor One Changeable 2.5" 9.5 mm (h) SATA 10Mb/100Mb Base-T Ethernet LAN Intel® Atom® Processor N450 (Serial) Hard Disk Drive 802.11b/g/n Wireless LAN Half Mini-Card 1.67 GHz, 512KB On-die L2 Cache & Note: It is recommended that HDDs of a Module (Factory Option) 667MHz FSB, 5.5W - BGA Package, 45nm speed of 5400 RPM are used.
  • Page 15 Introduction Power Full Range AC/DC Adapter AC Input: 100 - 240V, 50 - 60Hz DC Output: 19V, 1.57A / 1.58A (30 Watts) Battery Polymer Battery Pack, 26.27WH Environmental Spec Temperature ° ° Operating: C - 35 Non-Operating: -20°C - 60°C Relative Humidity Operating: 20% - 80%...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Optional Built-In PC Camera 2. LCD 3. Speakers 4. Power Button 5. Keyboard 6. Built-In Microphone 7. Touchpad & Buttons 1 - 4 External Locator - Top View with LCD Panel Open...

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right side Views Figure 2 Front Views 1. LED Power & Communication Indicators 2. 7-in-1 Card Reader 3. Microphone-In Jack 4. Headphone-Out Jack Figure 3 Right Side Views 5. Hard Disk Drive 6. Vent/Fan Intake/ Outlet 7.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DC-In Jack 2. RJ-45 LAN Jack 3. 2 * USB 2.0 Ports 4. External Monitor Port Figure 5 Rear View 5. Battery 1 - 6 External Locator - Left Side & Rear View...

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Vent/Fan Intake/ Outlet 3. Hard Disk Bay  Overheating To prevent your com- puter from overheating make sure nothing blocks the vent/fan in- takes while the com- puter is in use.

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. Card Reader Socket 2. Audio Codec 3. Intel Atom CPU 4. North Bridge 5. Memory Slots DDR2 SO-DIMM 6. Mini-Card Connector (WLAN Module) 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. JMC261 2. South Bridge 3. SILEGO SLG8SP510T 4. KBC ITE IT8512E Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. USB Port 2. Microphone Cable Connector 3. BT Cable Connector 4. Keyboard Cable Connector 5. TouchPad Cable Connector 6. CPU Fan Cable Connector 7. Speaker Connector 8. Power FFC Connector 9.

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. HDD Connector Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the M815P series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Bluetooth Module: 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery 1. Turn the computer off, and turn it over. Figure 1 2. Slide the latch in the direction of the arrow. Battery Removal 3. Slide the latch in the direction of the arrow, and hold it in place. 4.

  • Page 30: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Figure 2 (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in HDD Assembly Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 31 Disassembly 5. Remove screws from the hard disk assembly. Figure 3 6. Separate the hard disk from the case. HDD Assembly 7. Insert the new hard disk into the case and pay careful attention to the disk’s orientation in the case. Removal (cont’d.) 8.

  • Page 32: Removing The Keyboard

    Disassembly Removing the Keyboard 1. Turn off the computer, and remove the battery (page 2 - Figure 4 2. Press the three keyboard latches at the top of the keyboard to elevate the keyboard from its normal posi- Keyboard Removal tion (you may need to use a small screwdriver to do this).

  • Page 33: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 5 The computer has one memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting RAM Module DDR2 667MHz. The main memory can be expanded up to 2GB. The SO-DIMM modules supported are 1024MB, and Removal 2048MB and DDRII Modules.

  • Page 34: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 6 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 5) and the keyboard (page 2 - Module Removal 2. Carefully disconnect cables , then remove screw from the module socket. 3.

  • Page 35: Removing The 3G Module

    Disassembly Removing the 3G Module Figure 7 3G Module Removal 1. Turn off the computer, remove the battery (page 2 - 5) and the keyboard (page 2 - 2. Carefully disconnect cables , then remove screw from the module socket. a.

  • Page 36: Removing The Bluetooth Module

    Disassembly Removing the Bluetooth Module Figure 8 Bluetooth Module 1. Turn off the computer, remove the battery (page 2 - 5) and the keyboard (page 2 - Removal 2. Remove any rubber covers, and screws (Figure 8a) from the bottom case. 3.

  • Page 37: Removing The Lcd

    Disassembly Removing the LCD Figure 9 LCD Removal 1. Turn off the computer, remove the battery (page 2 - 5), HDD (page 2 - 6), keyboard (page 2 - 8) and bluetooth module (page 2 - 12). 2. Run your finger around the middle of the frame to carefully unsnap the LCD front panel module from a.
  • Page 38 Disassembly 2 - 14...

  • Page 39: Part Lists

    Part Lists Appendix A: Part Lists This appendix breaks down the M815P series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 40: Part List Illustration Location

    Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A- 1 Part List Illustration Location Parts Bottom page A - 3 page A - 4 A - 2 Part List Illustration Location...

  • Page 41: Bottom

    Part Lists Bottom 黑色 無鉛 無鉛 無鉛 (設變USB接口) 無鉛 無鉛 無鉛 含背膠 無鉛 無鉛 Figure A - 1 非耐落 無鉛 無鉛 Bottom 無鉛 無鉛 (今皓) 無鉛 無鉛 無鉛 無鉛 無鉛 藍天7 互億 無鉛 凱碩 無鉛 無鉛 無鉛 無鉛 無鉛 海華 無鉛...

  • Page 42: Lcd

    Part Lists Figure A - 2 無鉛 無鉛 無鉛 無鉛 非耐落 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 綠色 精乘 無鉛 無鉛 無鉛 奈米膠布 無鉛 透明 精乘 無鉛 (設變)無鉛 精乘 無鉛 Ω 無鉛 無鉛 無鉛 藍色 精乘 無鉛 中性LOGO電鑄薄膜鍍亮鉻(字體連結) 無鉛...

  • Page 43: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the M815P notebook’s PCB’s. The following table indicates where to find the ap- propriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...

  • Page 44: System Block Diagram

    Schematic Diagrams System Block Diagram VDD3,VDD5 CLEVO Tigerhill- Pineview System Block Diag ram AC-IN,CHARGER DDR2 One Channel 3.3V,5V,3VS,5VS 14.31 8 MHz 1GB & 2GB Colck Generator Memory Termination SLG8SP510T DDRII SO-DIMM0 1.05VS,1.5VS,0.89_GFX 17.1mm*8.1mm*1.2mm TSSOP 64PIN 1.8V,0.9VS(VTT_MEM) Intel Pineview 45nm VCORE...
  • Page 45 Schematic Diagrams Pineview CPU 1/4 ( 1) L VD S Cloc k & Data Sig nal G ro up Z dif f = 90 Oh m ? 0% 1 . 0 5V S s ign al / s p ace : 5 / 6 mils C P U _ R S V D _ 0 1 le ng th <...

  • Page 46: Pineview Cpu 1/4

    Schematic Diagrams Pineview CPU 2/4 D M I Sign al Gro up Zd iff = 85 Ohm ? 0% sig na l / s pac e : 6 / 6 mil s U 2 F A 1 1 R E V = 1 . 1 F 2 4 len gt h <...

  • Page 47: Pineview Cpu 4/4

    Schematic Diagrams Pineview CPU 3/4 U 2B M _ A _ A [ 1 4: 0] M _A _A 0 A H 1 9 R E V = 1 . 1 A D 3 M _A _D QS 0 6 D D R _ A _ M A _ 0 D D R _ A _ D Q S _ 0 M _A _A 1...

  • Page 48: Pineview Cpu 4/4

    Schematic Diagrams Pineview CPU 4/4 0. 89V _GFX V COR E R EV = 1.1 C189 C193 C186 PINE _V IE W_M A2 3 A2 5 *10u_6.3V _X 5R_06 2.2u_6. 3V _X 5R_04 1u_6.3V_X 5R _04 A2 7 C209 C208 C200 C 201 B2 3...

  • Page 49: Ddrii So-Dimm - 0

    Schematic Diagrams DDRII SO-DIMM - 0 SO-DIMM 0 1 . 8 V +VTT_MEM RESISTORS J _D I MM 1 16-5 6034-4 5A V T T _M E M M_ A _ A [ 1 4 : 0 ] M_ A _ D Q [ 6 3: 0] 4 M_ A _ A 0 M_ A _ D Q 0 M_ A _ A 4...

  • Page 50: Crt, Panel

    Schematic Diagrams CRT, Panel CR T DAC Sign al Gro up PANEL PWR V D D 3 CR T_RED ,CRT_GR EEN ,CR T_B L U E E VT 5 / 2 7 VG A RG B resis to rs cols e t o Con ne cte r Zo = 50 Ohm ? 5% sig nal : 5 mils P L V D D...

  • Page 51: Clock Generator

    Schematic Diagrams Clock Generator CLOCK GENERATOR 3 . 3 V S _ G 3 . 3 V S 1 . 0 5 V S L 4 1 L 4 2 *H C B 1 60 8 K F - 12 1 T 2 5_ s h o rt * H C B 1 6 08 K F -1 21 T 2 5 _s h o rt C 2 5 6 C 2 5 7...

  • Page 52: Tigerpoint 1/4

    Schematic Diagrams Tigerpoint 1/4 U SB Sign al Gro up Zd iff = 90 Oh m ? 5% sig nal / sp ace : 5 / 6 mils U 4 B U 4 A R 2 3 B 2 2 A D 0 Tige rpoint Tigerpoint...

  • Page 53: Tigerpoint 2/4

    Schematic Diagrams Tigerpoint 2/4 S AT A Si gn al Gr o u p Zd if f = 9 2 Oh m ? 0 % si gn al / s p ace : 5 / 6 m ils Z1001 Ti ge rpo i nt A E 6 T113 RS V D03...

  • Page 54: Tigerpoint 3/4

    Schematic Diagrams Tigerpoint 3/4 3 . 3 V U 4 D L P C Sign al Grou p A A 5 Ti gerpoi nt T 1 5 GP I O 0 S M I # L D R Q 1# / G P I O2 3 B M_ B U S Y # / GP I O0 T 5 0 L P C _ A D 0...

  • Page 55: Tigerpoint 4/4

    Schematic Diagrams Tigerpoint 4/4 5V S 3.3V S 3.3V U 4F 100_04 SC S751V -40 10_06 S CS751V -40 10 /25 Ga ry 6 m A 1 0 mA Ti ge rp oi nt ? ? ? ? ? ? ? ? VS S 01 VS S 02 VS S 03...

  • Page 56: Usb Port, Ccd, Bt, Lid Sw, Tpm

    Schematic Diagrams USB Port, CCD, BT, LID SW, TPM Bluetooth USB PORT 3 . 3 V L 1 5 3. 3 V _ B T U S B V C C 0 1 *H C B 1 6 0 8K F -12 1 T 25 _ sh o rt 50 mils U 1 4 10 0mi ls...

  • Page 57: Hdd, Wlan, 3G Card

    Schematic Diagrams HDD, WLAN, 3G Card MINI-PCIE CARD AND Debug Port SATA HDD C lo s e to th e HD D J_ MI N I 1 C o n ne c to r. R 1 1 * 0_ 0 4 J_ H D D 1 11 , 1 6 P C I E _ W A K E #...

  • Page 58: Led, Fan, Tp, Panel Led

    Schematic Diagrams LED, Fan, TP, Panel LED FAN CONTROL V D D 3 V D D 3 3 . 3V S 3 . 3V S 5 V S _ F A N 5 V S U 1 2 R 16 2 R 1 6 1 R 1 64 R 1 63...

  • Page 59: Card Reader Jmb261

    Schematic Diagrams Card Reader JMB261 JMB261 S D _C L K R 27 7 2 2_ 0 4 3. 3V 3. 3 V V C C _C A R D R 32 F unction C ard R ea de r Pow e r S D _C L K M D IO Sing le E n d D isable D3E...

  • Page 60: Audio Codec Alc272 Qfn

    Schematic Diagrams Audio Codec ALC272 QFN 5 V S _ A U D 5 V S 5 V S _ A M P 3 . 3 V S _ A U D 3 . 3 V S L 1 9 10/ 09 Gar y L 1 8 L 1 7...

  • Page 61: Kbc-Ite It8502E-J

    Schematic Diagrams KBC-ITE IT8502E-J K B C _ A V D D L 1 6 M OD EL _ID *H C B 1 0 05 K F -1 2 1 T2 0 _ s ho rt V D D 3 V1.0 M 810P V D D 3...

  • Page 62: Ac-In, Charger

    Schematic Diagrams AC-In, Charger M71 0L c onnec tor B A T V A _ I N J _D C -J A C K 1 P L1 B T D -05 T I 1 G 2 D C -G7 2 6-I 0 3 H C B 4 5 3 2 K F -8 00 T 6 0 P R 4 1 0 _ 04...

  • Page 63: Power Sw, 1.8Vs, 3V, 5V, 3Vs, 5Vs

    Schematic Diagrams Power SW, 1.8VS, 3V, 5V, 3VS, 5VS P Q3 4 P Q 3 3 V D D 1 5 V D D 1 5 P 1 5 03 B V G P 1 5 0 3 B V G PA NE L LED ? 1A 5 V S V D D 15...

  • Page 64: Power Vdd3, Vdd5

    Schematic Diagrams Power VDD3, VDD5 V I N 1 P C 1 0 7 P C 1 09 V D D 5 1 0 0 0 p_ 5 0 V _ X7 R _0 4 0 . 0 1 u_ 5 0 V _ X7 R _0 4 I N T V C C 2 I N T V C C 2 I N T V C C 2...

  • Page 65: Power 1.8V, 0.9V, 1.2V

    Schematic Diagrams Power 1.8V, 0.9V, 1.2V V I N 3 . 3 V P R 1 00 P R 1 0 1 P D 1 1 P R 1 26 V D D Q 1 . 5 M_ 0 4 10 _ 0 6 F M0 5 4 0 -N 1 0 K _ 0 4...

  • Page 66: Power 0.89V, 1.05Vs, 1.5Vs

    Schematic Diagrams Power 0.89V, 1.05VS, 1.5VS V I N P D 1 4 P R 1 4 2 10 K _1 % _ 0 4 F M0 5 4 0 -N P C 8 2 1 . 0 5 V S _P W R GD P Q 22 A *1 5 u _ 2 5 V _ 6 .

  • Page 67: Vcore

    Schematic Diagrams VCORE 11 / 2 6 ? ? rew ork V I N D R N EM I P C 1 44 P C 1 42 P C 1 43 P C 5 1 P C 1 68 P C 6 1 P R 52 3 30 u _ 6.

  • Page 68: Power Button Board

    M TH 8 _0 D 2-3 M TH 8 _0 D 2-3 S MG N D S MGN D POWER SW FOR M815P (6-71-M815S-D01) S H _ 3 . 3 V S S H _ 3. 3 V S S H R 1...
