12. Verify that the reading on the gas analyzer is between 0.8 – 1.2%.
13. Set the vaporizer dial to 2.5% and wait a few minutes for the vaporizer
concentration to stabilize.
14. Verify that the reading on the gas analyzer is between 2.0 – 3.0%.
15. Set the vaporizer dial to 5.0% and wait a few minutes for the vaporizer
concentration to stabilize.
16. Verify that the reading on the gas analyzer is between 4.0 – 6.0%.
17. If a Sevofl ourane vaporizer is being tested, set the vaporizer dial to 8.0%
and wait a few minutes for the vaporizer concentration to stabilize.
18. Verify that the reading on the gas analyzer is between 6.4 – 9.6%.
19. If a Desfl urane vaporizer is being tested, set the vaporizer dial to 10.0%
and wait a few minutes for the vaporizer concentration to stabilize.
20. Verify that the reading on the gas analyzer is between 8.0 – 12.0%.
21. Set the vaporizer dial to 18.0% and wait a few minutes for the vaporizer
concentration to stabilize.
22. Verify that the reading on the gas analyzer is between 14.4 – 21.6%.
23. Set the vaporizer dial to "0".
24. Set the O fl ow control valve to minimum fl ow and turn the switch to the
2
"OFF" position.

4.17 Electrical Safety Test

1. Connect the BleaseSirius anesthesia machine to an approved safety
analyzer. Verify that the leakage current is less than 300 µΑmps for
120/100 Vac and less than 500 µΑmps for 220/240 Vac
2. Connect the ground pin of the safety analyzer to an external grounding
plug. Verify that the resistence to ground is less than 0.2 Ω.
