Spacelabs BleaseSirius Technical Manual page 23

Figure 1 Key
A Monitor shelf
B Ventilator
C Vaporizer
D Cylinder/pipeline gauges
E Pneumatic unit - (behind gauge panel)
F Handle
G Oxygen fl ush
H Common gas outlet (or option A.C.G.O.)
I Drawer
J Frame
K Brake Pedal
L Absorber
M Bag Arm Link Pipe
N Adjustable Bag Arm
O Main On/Off Switch
P Suction Controller
Q Flow Control Valves with Hypoxic Guard
R Flowblock Assembly
S Auxiliary Flowmeter
Technical Description
23
