5.18 Suction Controller Removal/Replacement

1. Remove rear panel (see section 5.1).
C
A
B
D

Figure 131 - Suction Controller Removal / Replacement

Detailed Repair Procedures
D
2. Remove the two M5
screws (A&B) and
the M4 screw (C).
The controller and its
bracket can be pulled
back clear of the front
molding. Disconnect the
pipe connections.
3. Remove the suction
controller from its
bracket by removing the
two 'pozi-drive' screws
(D).
169
