EN
Demineralised heating water
Demineralisation
PUROTAP expert
Demineralised heating water
makes heating systems safe
in accordance with
VDI 2035 and
SWKI BT 102-01
Minerals and salts in water circuits for technical purposes
cause corrosion and deposits. PUROTAP® expert filters the
aggressive substances out of the fill water, thereby enabling
trouble-free operation for the long term.
®
Installation
Function
Operation
Service
www.elysator.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for elysator PUROTAP expert
Summary of Contents for elysator PUROTAP expert
- Page 1 Demineralised heating water Installation Demineralisation Function PUROTAP expert ® Operation Service Demineralised heating water makes heating systems safe in accordance with VDI 2035 and SWKI BT 102-01 Minerals and salts in water circuits for technical purposes cause corrosion and deposits. PUROTAP® expert filters the aggressive substances out of the fill water, thereby enabling trouble-free operation for the long term.
-
Page 2: Table Of Contents
EN 2 Contents Protection against limescale deposits Protection against corrosion Function Specification Components Operating the combined meter Operation and safety Troubleshooting Updates may be made without notice. www.elysator.com Web version supercedes print version. -
Page 3: Protection Against Limescale Deposits
3 EN Protection against limescale deposits in the boiler and heat exchanger Demineralised water water no longer contains any substances that can settle out or be deposited in the boiler and heat exchanger. The following table shows the amount of lime accumulating in a heating system that is filled once with untreated water. -
Page 4: Function
EN 4 Function PUROTAP® expert operates with hyper filtration – a most advanced process. The flow pattern of the water inside the intricately designed tank is controlled in a way that enables the system to achieve incomparably high filtration velocities. The integral high pressure pump allows PUROTAP® expert to achieve a throughput of 20 l/min, or 1200 l/hr. -
Page 5: Components
5 EN Components Filter casing cover Handle Pressure gauge Stainless steel filter dynamic pressure, casing, maximum filter membrane operating pressure 18 bar Aeration tap for draining and replacing the Pressure booster pump membrane 230 V/16 A/8 bar Manometer for pure water output Waste water output, connection 3/4"... -
Page 6: Operating The Combined Meter
EN 6 Operating the combined meter The combined meter is battery-operated. It measures the flow rate in l/min, the total volume in litres and the concentration of dissolved minerals (electrical conductivity), either in microsiemens or TDS. In addition, a limit can be set for the maximum concentration of minerals tolerated in the demineralised water (expert outlet). -
Page 7: Operation And Safety
7 EN Operation and safety Operation Turn the single lever fitting (1) in the direction of flow = close; close the aeration tap (2). Attach the freshwater connection (3) behind the pump, at an inflow rate of at least 30 l/min; connection 3/4" external thread. -
Page 8: Troubleshooting
EN 8 Troubleshooting Little or no pure water Possible causes: - Single lever fitting not opened - Water supply rate too low; minimum = 30 l/min - Filter membrane spent No/incorrect display on combined meter Possible causes: - Battery needs replacing - Meter jammed - Meter faulty - Conductivity too high...
