Set Points and Ranges

Set points and ranges for Analog Outputs, Alarms, Fixed User Pressure, Cell Pressure and
External (line) Pressure sensor.
Adjustment
Unit
Range/Res.
ppm 0.0 to 3000.0
V
ppm 0 to 40000
W
mgm 0 to 20000
3
Pa 0.0 to 3000.0
dew point degC -120.0 to +20.0
dew point degF -184.0 to +68
lbmmscf 0 to 60000
Oven T degC -50.0 to +100.0
Oven T degF -58.0 to +212.0
Flow, ml/m 0.0 to 300.0
Pressure, Psi.G 0.0 to 3000.0
Pressure, Psi.A 14.7-3014.7
Pressure, Bar.G 0.00 to 204.08
Pressure, Bar.A 1.00 to 205.08
Pressure, MPa.G 0.01 to 20.78
Pressure, mmHg 750 to 65535
(limited)
Pressure, MPa.A 0.01 to 20.78
Pressure MPa.A 0.01 to 20.78
Michell Instruments
Default Values Register Range
0.0 to 2000.0 0-30000
0 to 40000 0 to 40000
0 to 20000 0 to 20000
0.0 to 3000.0 0 to 30000
-100.0 to 0.0 -1200 to 200
-148.0 to 32.0 -1840 to 680
0 to 60000 0 to 60000
59.9 to 60.1 -500 to 1000
139.8 to 140.2 -580 to +2120
90.0 to 110.0 0 to 3000
0.0 to 3000.0 0 to 30000
15.0-3015.0 147 to 30147
0.00 to 204.00 0 to 20408
1.00 to 205.00 1 to 20508
0.01 to 21.00 1 to 2078
750 to 65000 0 to 65535
(limited)
0.01 to 21.00 1 to 2078
0.01 to 21.00 1 to 2078
APPENDIX C
Register Type
A2 (unsigned
short/10)
A1 (unsigned
short)
A1 (unsigned
short)
A2 (unsigned
short/10)
B2 (signed
short/10)
B2 (signed
short/10)
A1 (unsigned
short)
B2 (signed
short/10)
B2 (signed
short/10)
A2 (unsigned
short/10)
A2 (unsigned
short/10)
A2 (unsigned
short/10)
A3 (unsigned
short/100)
A3 (unsigned
short/100)
A3 (unsigned
short/100)
A1 (unsigned
short)
A3 (unsigned
short/100)
A3 (unsigned
short/100)
93
