Page 1: Table Of Contents
NE216 Operating Instructions Electronic preset counter NE216 Contents Page General / Safety instructions System description Description Block diagram Connecting Connecting the voltage supply Assignment signal output „relay“ Assignment signal output „electronic“ Assignment signal inputs Typical connections Connecting the sensor supply... -
Page 2: Page General / Safety Instructions
NE216 General Information In the following you will find the explanations of the symbols used in this operating manual. Explanation of symbols This symbol indicates activities to be carried out. This symbol indicates supplementary technical information. This symbol is located before texts to which particular attention is to be paid to ensure proper use of the product. - Page 3 NE216 Operation not covered by the specified descriptions/parameters is improper and can lead to - fatal injuries, - serious damage to health, - property damage or - damage to the units in conjunction with the systems/machines/processes to be controlled/monitored! The overvoltages to which the units are subjected at the connection...
-
Page 4: System Description
NE216 2 System description 2.1 Description The device comprises - a 5-digit preset counter with 2 settings - an 8-digit totalizer LED display P1 Preset 1 P2 Preset 2 P1 blinks, preset P1 reached P2 blinks, preset P2 reached Control panel Key for display of functions, confirmation key... -
Page 5: Connecting
NE216 3 Connecting This section describes the terminal assignments, accompanied by an example of a typical connection. Sections 3.1 to 3.6 contain specific instructions and technical data relating to the individual terminals. Assignment Relay outputs Electronic outputs Connecting assignment Relay outputs and electronic outputs... -
Page 6: Connecting The Voltage Supply
NE216 Litz contact only by means of connector sleeves with insulating enclosures for reasons of shock protection according to EN 61010. Do not otherwise assign contacts that have been left unassigned ex factory. We recommend to screen all sensor terminal leads and to ground the shield on one side. -
Page 7: Assignment Signal Output „Electronic
NE216 Max. rating Max. voltage Max. current 150 VA/30 W 250 V The user must take care that, in case of disturbance, the contact rating of 8 A / 150 VA (W) is not exceeded. Internal spark suppressi- on by means of zinc-oxide varistor (275 V). The output relays of the instrument (1 relay or several) may in total switch 5 x per minute at the most. -
Page 8: Typical Connections
NE216 3.5 Examples of connection Sensor Contact assignment Programming Contact Counting rate: Track A Line 31 to 1 = 25 Hz +24 V Line 31 to 2 = 3 Hz Proximity switch PNP or NPN Track A Input logic: +24 V... -
Page 9: Interface Connection
NE216 3.7 Interface connection The serial interface can perform the following functions: - retrieve data - program parameters Interface parameters are: - transmission speed (baud rate), - parity bit, - number of stop bits, - address of controller for master. - Page 10 NE216 Current count After the counter has been turned on or upon selection via , „C“ appears for one second on the display. The current count is then displayed for reading. Read count PC. Clear Press key. Preset P1 Read Press key.
-
Page 11: Programming Mode
NE216 Read Press key. „SF“ appears for one second on the display. The display then jumps to the current scaling factor SF . Modify Enter scaling factor SF via The setting range from 0.0001 to 999.99 is attained by shifting the decimal point. - Page 12 NE216 Enter code Enter code via keys. Press key to confirm. The instrument switches from the operator to the programming level. Wrong code If a wrong code has been entered, „Error“ is displayed as long as remains pushed. After 15 s the instrument switches automatical- ly back to the operator level.
- Page 13 NE216 Programming field 2 The individual operation parameters for operator access are disabled or enabled here. „Stat“ appears on the display. The denominations of the chosen line „PC“ , „P1“ , „P2“ , „tot“ , „SC“ and „SF“ are displayed for one second.
- Page 14 NE216 Programming field 3 All functions and values as well as interface parameters conditioned by the machinery are programmed here. Each factory setting is marked as such by *. Line 21 Operating modes main counter 0 * Adding, final signal at P2, reset to SC Subtracting, final signal at SC;...
- Page 15 NE216 Line 34 Function control input 1 (Contact 9 ) 0 * PC - Main counter - Reset static PC - Main counter - Reset edge-triggered tot - Totalizer - Reset edge-triggered Stop (PC - Main counter and tot - Totalizer)
-
Page 16: Operating And Preset Mode
NE216 Line 44 Rapid preset recognition 0 * Standard preset recognition Rapid preset recognition P2, delay period min. 30 μs, max. 60 μs. Only in case of adding operation mode, Line 21 = 0, and counting mode 0, 3, 4, 5, under line 30. -
Page 17: Counting Modes (Input Mode)
NE216 5.2 Counting modes for main counter and totalizer (input mode) Counting input track A, Reversal track B (Up/ Down) The adding and/or subtrac- ting counting directions are automatically set when se- lecting the operating mode in programming line 21 (diagram for adding mode). -
Page 18: Output Responses (Output Mode)
NE216 5.3 Output (output mode) The behaviour of the signal outputs is defined by the following set- tings under the programming field 3: Operating mode, preset mode, reset mode, take-over of presets, output logic and output time P1, P2 as momentary... -
Page 19: Technical Data
NE216 6 Technical data Technical data - electrical ratings Voltage supply 24/48 VAC ±10 % (50/60 Hz) 85...265 VAC (50/60 Hz) 12...30 VDC, 5 % RW Power consumption 5 VA, 5 W Sensor supply 24/48 VAC: 10...26 VDC / 60 mA 85...265 VAC: 24 VDC ±20 % / 100 mA... - Page 20 NE216 Technical data - mechanical design Ambient temperature 0...+50 °C Storing temperature -20...+70 °C Relative humidity 80 % non-condensing E-connection Plug-in screw terminals Core cross-section 1.5 mm² Protection DIN EN 60529 IP 65 face with seal Operation / keypad Membrane with softkeys...
-
Page 21: Dimensions
NE216 6.1 Dimensions 6.2 Error messages Error must be fixed at the factory. Sequences are too quick, e.g. very short intervals between presets at high counting rate. Message can be cleared by pushing www.baumer.com... -
Page 22: Part Number
NE216 7 Part number NE216. AX01 Voltage supply 24/48 VAC 85...265 VAC 12...30 VDC Outputs Relay outputs Electronic outputs Interface Without interface RS485 www.baumer.com...
