Digital Equipment RZ26 Installation Manual

Installing in the digital ba42 expansion box
Hide thumbs

Advertisement

Quick Links

Download this manual
Installing the RZ26 Hard Disk Drive in the BA42 Expansion Box
EK–BA42A–AD. A01
January 1993
Dear BA42 Expansion Box Customer:
This document describes how to install the RZ26 hard disk drive in your BA42
storage expansion box and provides the RZ26 drive hardware specifications.
The RZ26 drive installation differs from the hard disk drive installation
described in the BA42 Storage Expansion Box Installation Guide because of a
new internal SCSI ID switch cable adapter.
Insert this document into your BA42 Storage Expansion Box Installation Guide
(in the hard disk drive section of Chapter 2) for future reference.
© Digital Equipment Corporation 1993. All rights reserved.
The following are trademarks of Digital Equipment Corporation:
VAXstation, VMS, and the Digital logo.
S2144
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the RZ26 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Digital Equipment RZ26

Summary of Contents for Digital Equipment RZ26

  • Page 1 January 1993 Dear BA42 Expansion Box Customer: This document describes how to install the RZ26 hard disk drive in your BA42 storage expansion box and provides the RZ26 drive hardware specifications. The RZ26 drive installation differs from the hard disk drive installation described in the BA42 Storage Expansion Box Installation Guide because of a new internal SCSI ID switch cable adapter.

  • Page 2: Installation Overview

    1 Installation Overview The following list is an overview of the tasks involved in installing the RZ26 hard disk drive in the BA42 expansion box: 1. Check the contents of the shipment. 2. Check your system configuration. 3. Set the SCSI ID switches.
  • Page 3 3 Checking Your System Configuration Before you begin the RZ26 drive installation, put your system in console mode and enter the SHOW CONFIG command. (If you need instructions, see the system’s installation guide or user’s guide.) Make a note of which SCSI IDs are already being used.
  • Page 4 Figure 1 Removing the SCSI Switch Cover Press the bottom of cover. Then lift the cover away from the box. SCSI switch cover WSEBAM25...
  • Page 5 If you have one hard disk drive installed in your expansion box, the right three SCSI ID switches on the back of the box determine the SCSI ID switch setting for that drive. If you are installing a second hard disk drive in your expansion box, the left three SCSI ID switches on the back of the box determine the SCSI ID switch setting.
  • Page 6 Down Down 4 Installing the RZ26 Hard Disk Drive Here are the steps you follow to install the RZ26 drive. The sections following the list describe each step. 1. Remove the cover from the BA42 box. 2. Attach the adapter cable to the RZ26 drive.
  • Page 7 Step One: Remove the cover from the expansion box. Follow these steps to remove the expansion box cover: 1. Loosen the two cover-release screws on the back of the expansion box. 2. Grasp each side of the cover and pull it toward you as shown in Figure 2. Figure 2 Removing the Expansion Box Cover Cover-release screws WSEBAI20...
  • Page 8 Step Two: Attach the adapter cable to the RZ26 drive. Figure 3 shows where to attach the adapter cable to the RZ26 hard disk drive. The silver dot faces up as you insert the adapter cable onto the first three SCSI pins.
  • Page 9 SCSI ID switch cable Power cable MLO-010154 The SCSI ID adapter cable that came with your RZ26 drive attaches to either the 24-pin connector or the 6-pin connector on one end, and to the RZ26 drive on the other end.
  • Page 10 Step Four: Attach the SCSI ID adapter cable. Figure 5 shows how to attach the SCSI ID adapter cable to the RZ5x 24-pin SCSI ID cable connector. Figure 5 Attaching the SCSI ID Adapter Cable to a 24-Pin Cable Connector Silver dot MLO-010155...
  • Page 11 Figure 6 shows how to attach the SCSI ID adapter cable to the RZ2x 6-pin SCSI ID cable connector. Make sure both silver dots are facing the same way, and the plastic latch snaps to secure the connection. Figure 6 Attaching the SCSI ID Adapter Cable to a 6-Pin Cable Connector Silver dots MLO-010156...
  • Page 12 Step Five: Attach the SCSI and power cables. Figure 7 shows where to attach the SCSI and power cables to the RZ26 drive. Figure 7 Attaching the SCSI and Power Cables MLO-010252 Step Six: Insert the drive in the expansion box.
  • Page 13 Step Seven: Tighten the captive screw on the drive bracket. Tighten the captive screw, as shown, to hold the drive in place. WSEBAI88...
  • Page 14 Step Eight: Replace the cover and tighten the cover-release screws. Position the cover over the SCSI ID switches on the back of your expansion box by inserting the notch on the bottom of the cover into the opening below the switches.
  • Page 15 Put your system in console mode and enter the SHOW CONFIG command. (If you need instructions, see the system’s installation guide or user’s guide.) If the RZ26 drive does not appear in your configuration display, check the On/Off switch on the expansion box.
  • Page 16 6 RZ26 Hard Disk Drive Hardware Specifications Table 2 RZ26 Weight and Dimensions Weight Height Width Depth 0.9 kg 4.13 cm 10.2 cm 14.6 cm (1.9 lb) (1.625 in) (4.00 in) (5.75 in) Table 3 RZ26 Drive Formatted Storage Capacity...
