12
Flat
S crewdriver
a.
R emove
t he
p lastic
c ap
f rom
i nlet
m anifold.
b.
R emove
c arburettor
f rom
i ts
b ox.
c.
F it
t he
c lamp
p rovided
t ogether
w ith
t he
carburettor
o ver
t he
i nlet
r ubber
m anifold.
d.
I nsert
t he
c arburettor
i nto
t he
i nlet
r ubber
manifold.
13
Flat
S crewdriver
Ensure
t he
c arburettor
i s
c orrectly
s eated,
t hen
tighten
t he
c arburetor
t o
t he
i nlet
m anifold
b y
using
t he
s pecific
c lamp.
14
Screw
t he
a ir
b ox
m ount
t o
t he
c arburettor
manually.
D o
n ot
u se
a ny
t ool.
