9
1 0mm F ixed W rench
4 m m A llen W rench
Mounts t he f uel p ump.
Fix i n b etween t he s upport b racket a nd
the f uel p ump, o ne 5 mm a nd o ne
10mm s pacer.
Fix a irbox b racket a lso, b y u sing o ne
5mm a nd o ne 1 0mm s pacer a nd 6 mm
screw, w asher a nd s elf l ocking n ut..
10
Flat S crewdriver
Remove t he p lastic c ap f rom t he h ead.
S park P lug W rench
Tighten t he s park p lug i n t he e ngine h ead.
Tighten a nd l oosen t he s park p lug 2 /3 t imes t o
allow t he g asket t o s eat. T hen t ighten t he s park
plug s ecurely.
11
Insert t he c oil c able i nto t he r ubber p lug c up s o
it i s t ight ( photo 1 ).
It i s r ecommended t o s ecure t he c oil c able b y
using a p lastic t ie ( photo 2 ).
Place t he p lug c ap o n t o t he s park p lug a nd
push t he p lug c ap d own f irmly.
Via d ei S oprini, 1 6 – 2 5080 P REVALLE ( Brescia) I TALY-­‐Tel. + 39 0 30 6 804601 – F ax + 39 0 30 6 804698
OTK KART GROUP srl
1
2
