Parts List
1 W010/MR Air head 60cc
2 W560 Head washers 8,5 x 15 x 8
3 W530/12 Head-nut high-set m8
4 W003 Spark plug ngk b10 eg
5 W631/01MR Copper head gasket 42,2 x 62,4 x 0,1
5 W631/02MR Copper head gasket 42,2 x 62,4 x 0,2
6 W620/MR O-ring head viton
7 W020/1MRC Cylinder 60cc complete
8 W470 Exhaust stud bolt m7 x 32
9 W610/1MRC02 Cylinder basis gasket 0,2
9 W610/1MRC03 Cylinder basis gasket 0,3
9 W610/1MRC04 Cylinder basis gasket 0,4
9 W610/1MRC05 Cylinder basis gasket 0,5
10 W461/1VLC Cylinder stud bolt m8 x 142
11 W2050/MR Inlet manifold phbg 18
11 W2050/BR Inlet manifold phbn 14
12 W825/1MR Carburettor clamp d.23-35mm
13 V.TCE6X16 Socket-head screw m6 x 16
14 W820/BR Dellorto carburettor phbn 14ms
14 W820/MR Dellorto carburettor phbg 18b
15 W981400 Connector
16 W540/RVA Exhaust fix. High set nut
17 W565 Exhaust washer d.8 x 12 x 1,5
18 W750/1MR Exhaust manifold mr/t 60cc
19 W670/MR Exhaust gasket
20 WA063 Head control template mini rok
21 WA064 Carburettor gap control template
32A W050/MRC Complete crankcase 60cc with bearing
33 V.TCE6X40 Socket head screw m6 x 40
34 V.TCE6X45 Socket-head screw m6 x 45
35 W075/1 Crankcase dowel 10 x 10,5 x 6,5
36 W10267 Copper gasket d. 8 x 12 x 1
37 W800 Depression pipe fitting m8 hexagonal
38 W300/MR Insert 6204 c4
39 W310 Oil seal fpj 20 x 35 x 7 double lip
40 W940/ROK Starter 50589
41 W019 Cylindrical pin 6x18
42 W924 Roller case bk0808
43 W916/ROK Starter driving gear 50589
Via d ei S oprini, 1 6 – 2 5080 P REVALLE ( Brescia) I TALY-­‐Tel. + 39 0 30 6 804601 – F ax + 39 0 30 6 804698

OTK KART GROUP srl

44 W910/ROK
45 V.TCE6X20
46 W960/RKT
47 V.TCE6X30
48 V.TCE6X65
49 W972/MR
50 W970/MR
51 W975/MR
64 W240/MR01A
64 W240/MR03A
64 W240/MR06A
64 W240/MR09A
64 W240/MR11A
64B W260/MR95L
64B W260/MR00L
64B W260/MR05l
65 W280/MR
66 W270/MRA
67 W140/MR
68 W122
69 W220
70 W290/MR
71 W200/1MR
72 W230/MR
73 W522/10
74 W160/MR
75 W121
76 W150/MR
77B W190/MR
78C W130/1MR
79 W510/14
80 W1753/MR
81 W1766/1ROK
82 W1751/1KFC
83 W1708
84 W1727
85 W1726/1
86 W523/08
87 W1773/MR2
Starter driving gear cover
Socket-head screw m6 x 20
Transmission starter support
Socket-head screw m6 x 30
Socket head screw m6 x 65
O.r.4200 starter support
Starter support d.50
Starter support spacer
Complete piston 41,88
Complete piston 41,91
Complete piston 41,93
Complete piston 41,95
Complete piston 41,98
Piston ring 41,95
Piston ring 42,00
Piston ring 42,05
Circlip d.12,00
Piston pin mini rok
Magn.s.h. Crankshaft 60cc
Ignition key 2,5 x 3,7 x 10
Silver-plated cage d.18 x 24 x 15
Piston cage 12 x 16 x 15,5
Crankshaft crankpin d.18 x 40,6
Conrod engine 60cc
Flathead screw m5 x 10
Nylon crankshaft stuffer
Dragging sprocket key 3 x 3,7 x 10
H.crankshaft sprocket side 60cc
Complete conrod 60cc
Complete crankshaft mini rok
Socket-head screw m6 x 14
Starting driven gear z 62
Cylindrical pin 6 x 10
Clutch rotor kf with pin
Belleville washer d.16,3 x 31,5 x 1,5
Clutch body fix nut m16 x 1 thr.
Washer 2,0 mm mini-kf
Flathead screw m5 x 8
Bare clutch housing mini
Rev. 30/09/15
