User Manual
pH Refillable Probe for Low Ionic Strength Samples: Model
PHC28101 or PHC28103
Safety information
Precautionary labels
Electrical equipment marked with this symbol may not be disposed of in European public disposal systems after
12 August of 2005. In conformity with European local and national regulations (EU Directive 2002/96/EC), European
electrical equipment users must now return old or end-of-life equipment to the Producer for disposal at no charge to
the user.
Note: For return for recycling, please contact the equipment producer or supplier for instructions on how to return end-of-life
equipment, producer-supplied electrical accessories, and all auxiliary items for proper disposal.
Specifications
Specifications
Probe type
pH range
pH resolution
Slope
Operating temperature range
Storage temperature range
Junction
Reference type
Minimum sample depth
Dimensions
Cable connection
Product overview
Read all labels and tags attached to the instrument. Personal injury or damage to the
instrument could occur if not observed. A symbol on the instrument is referenced in the
manual with a precautionary statement.
Note: Specifications are subject to change without notice.
Details
Digital combination probe with refillable double junction reference and built-in
temperature sensor
pH 0 to 14
User-selectable stabilization time and resolution—Fast: 0.1, Fast: 0.01,
Medium: 0.01, Slow: 0.01 or Slow: 0.001
-59 mV/pH (90 to 110% at 25 °C per Nernstian theoretical value)
0 to 50 °C (32 to 122 °F)
5 to 40 °C (41 to 104 °F)
Open
Ag/AgCl
15 mm (0.59 in.)
Diameter: 12 mm (0.47 in.)
Length: 175 mm (6.89 in.)
Cable length: 1 or 3 m (3.28 or 9.84 ft)
M12 digital output and connector compatible with HQd meters
The PHC281 series probe is a pH refillable probe made for difficult samples with a built-in
temperature sensor
(Figure
1 or 3 m (3.28 or 9.84 ft) cable and is intended for laboratory use. The pH refillable probe
has a high electrolyte flow rate and a large open junction ideal for difficult samples, such
as Low Ionic Strength (LIS), Ultrapure, dirty samples and samples with high solids
content. The probe is not suitable for use with organic solvents. A 59-mL bottle of 2.44 M
KCl Electrode Filling Solution is included with the probe.
1). The PHC28101 or PHC28103 probe is available with a
DOC022.52.80024
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hach PHC28101
Summary of Contents for Hach PHC28101
-
Page 1: Precautionary Labels
(Figure 1). The PHC28101 or PHC28103 probe is available with a 1 or 3 m (3.28 or 9.84 ft) cable and is intended for laboratory use. The pH refillable probe has a high electrolyte flow rate and a large open junction ideal for difficult samples, such as Low Ionic Strength (LIS), Ultrapure, dirty samples and samples with high solids content. -
Page 2: Preparation For Use
Figure 1 Probe overview 1 Probe soaker bottle 4 Protective tape and filling-hole 2 Glass bulb, reference junction and temperature sensor 5 1 or 3 meter (3.28 or 9.84 ft) cable 3 Filling-hole cap 6 Probe soaker bottle holder Preparation for use Prepare the probe for use before calibration or sample measurement. -
Page 3: Calibration Procedure
Calibration Before calibration: The probe must have the correct service-life time stamp. Set the date and time in the meter before the probe is attached. It is not necessary to recalibrate when moving a calibrated probe from one HQd meter to another if the additional meter is configured to use the same calibration options. -
Page 4: Sample Measurement
6. Push Read. 7. Repeat steps 8. Push Done to 9. Push Store to Stir gently. The 4 - 6 until the view the accept the display will show minimum number calibration calibration and go "Stabilizing" and a of calibration summary. -
Page 5: Run A Check Standard
Measurement procedure: 1. Connect the 2. For the best 3. Rinse the 4. Put the probe 5. Push Read. probe to the stabilization time, probe with in the sample and The display will meter. Make sure condition the deionized water stir gently. -
Page 6: Advanced Operation
6. Push Read. The display will show "Stabilizing" and a progress bar as the reading stabilizes. The display shows the value of the check standard and either Check Standard Passed or Check Standard Failed. 7. If the display shows Check Standard Passed, the check standard measurement is within the accepted limits set by the administrative user. -
Page 7: Change Measurement Options
Change measurement options Methods are groups of default or user-defined settings relevant to specific applications. If the meter is set to the default method and the Modify Current Settings option is chosen, a prompt for a new name is shown after the changes are entered. The settings are saved with this name to distinguish them from the default method settings, which cannot be changed. - Page 8 4. Select Calibration Options and update the settings: Option Description Buffer Set Sets the temperature compensated buffer set used for calibration— • Color Coded—4.01, 7.00, 10.01 (default) • IUPAC—4.01, 7.00, 10.01, 12.45 • DIN—4.65, 9.23 • IUPAC—4.01, 6.86, 10.01, 12.45 •...
-
Page 9: Change Check Standard Options
Table 2 Custom buffer set Buffer set values Option Description Std1 1.09pH—25 °C Pre-set temperature compensated buffer values. Note: Selected standards must differ by a minimum of 2 pH units. For example, if 1.09 pH is Std2 1.68pH—25 °C chosen for the first standard, the second standard must differ by at least 2 pH. Standards that do Std3 not meet this minimum will appear gray on the screen and will not be selectable. -
Page 10: Maintenance
1. Rinse the probe with deionized water and blot dry with a lint-free cloth. 2. Soak the glass bulb for 12 to 16 hours in Hach Electrode Cleaning Solution. 3. Rinse or soak the probe for 1 minute in deionized water. -
Page 11: Troubleshooting
Note: The probe can be stored in a sample for up to 2 hours if the sample pH is not high. 1. Put the filling-hole cap in the filling hole (refer to Figure 1 on page 2). 2. Rinse the probe with deionized water. Dry the probe with a lint-free cloth. 3. - Page 12 Message or symptom Possible cause Action Slow stabilization time Tape not removed from the filling- Remove the tape that is over the filling hole. hole Contaminated glass sensor Clean the probe (refer to Clean the probe on page 10). Contaminated filling solution Drain and replace the filling solution with fresh solution.
- Page 13 Message or symptom Possible cause Action Out of limits Check standard value is outside of Make sure that the standard is within the limits of the limits set in the current method current method. Create another method that expands the acceptable limits.
- Page 14 Fax (970) 669-2932 Fax +49 (0) 2 11 52 88-210 Tel. +41 22 594 6400 orders@hach.com info@hach-lange.de Fax +41 22 594 6499 www.hach.com www.hach-lange.de © Hach Company/Hach Lange GmbH, 2010, 2013. All rights reserved. Printed in U.S.A. 05/2013, Edition 2...
