Each Port - SMC Networks TigerSwitch Management Manual

C
ONFIGURING THE
CLI – This command displays global STA settings, followed by settings for

each port.

Console#show spanning-tree
Spanning-tree information
---------------------------------------------------------------
Spanning tree mode
Spanning tree enable/disable
Priority
Bridge Hello Time (sec.)
Bridge Max Age (sec.)
Bridge Forward Delay (sec.)
Root Hello Time (sec.)
Root Max Age (sec.)
Root Forward Delay (sec.)
Designated Root
Current root port
Current root cost
Number of topology changes
Last topology changes time (sec.):13380
Transmission limit
Path Cost Method
.
.
.
Note: The current root port and current root cost display as zero when
this device is not connected to the network.
3-130
S
WITCH
:RSTP
:enabled
:32768
:2
:20
:15
:2
:20
:15
:32768.0.0000ABCD0000
:1
:200000
:1
:3
:long
4-196
