Table of Contents
Advertisement
Quick Links
GB
Contents
1
General Description ........................................................................................ 13
2
Standard Configuration and Working Principle............................................ 13
2.1
Major Components ...............................................................................................13
2.2
Platform Assembly ...............................................................................................14
2.3
Working Principle .................................................................................................14
3
Specifications .................................................................................................. 15
3.1
Load Cell ...............................................................................................................15
4
Inspection and Site Selection......................................................................... 15
4.1
Inspection..............................................................................................................15
4.2
Site Selection ........................................................................................................16
5
Installation ....................................................................................................... 16
5.1
Locate ....................................................................................................................16
5.2
Installation Procedure ..........................................................................................16
6
Ramp Installation ............................................................................................ 19
7
System Connection ......................................................................................... 19
8
Technical Data ................................................................................................. 20
12
KERN NTEP/NTNN
Version 1.0 02/2007
Installation Information
Drive-through-scale
NTEP/NTNN-IA-defsi-0710
Advertisement
Table of Contents
Related Manuals for KERN NTEP Series
Summary of Contents for KERN NTEP Series
-
Page 1: Table Of Contents
KERN NTEP/NTNN Version 1.0 02/2007 Installation Information Drive-through-scale Contents General Description ..................13 Standard Configuration and Working Principle..........13 Major Components ....................13 Platform Assembly ....................14 Working Principle ....................14 Specifications ....................15 Load Cell .......................15 Inspection and Site Selection................. 15 Inspection......................15 Site Selection ......................16... -
Page 2: General Description
1 General Description Thank you for choosing our NTEP/NTNN series floor scale. The scale consist of new design ultra-low profile steel platform, four high precision shearing beam load cells. NTEP/NTNN floor scales have the features of high accuracy, quick weighing and re- liable weighing performance. -
Page 3: Platform Assembly
2.2 Platform Assembly The scales have a channel reinforced platform with two angle steel welding on two sides of platform. The junction box is mounted on the angle steel. The covers on the angle steel can be removed to gain access to the junction box. Threaded holes are provided on two sides of platform. -
Page 4: Specifications
3 Specifications 3.1 Load Cell SBC or SBH shearing beam load cells are provided in all NTEP/NTNN floor scales with integral 6-conductor, shielded cables (see the table below). The load cell sus- pension utilizes a rocker pin positioned between the cell and a fixed receiver in the limit support (see Figure 5-3). -
Page 5: Site Selection
4.2 Site Selection Many problems associated with floor scale installations are caused by improper site conditions. Before installing the scale, check the proposed location for the following conditions: • The area where the scale will be located should be level to within 4mm from the highest to the lowest corner. - Page 6 5.2.1 Place Scale Install eyebolts in the threaded holes provided on two sides of platform. Ensure that the eyebolts are snug and fully threaded into the holes before lifting. Utilize the lifting eyebolts when lifting the platform (see Figure 5-1). Figure 5-1 Scale Lifting 5.2.2 Pre-install Scale...
- Page 7 The weighing platform must be aligned with the use of a water balance. All foot screws must equally touch the floor. 5.2.5 Reinstall Platform 1. Clear all debris from the scale area. Ensure that all four load pin receivers in the limit support are clean and free of foreign material.
-
Page 8: Ramp Installation
5.2.6 Route Instrument Cable 1. A loose coil of instrument cable should be stashed inside the angle steel, on either side of the junction box assembly. 2. Route the instrument cable under the slot provided in the cover, stopping at the indicator location. -
Page 9: Technical Data
8 Technical Data NTEP NTEP NTNN NTNN KERN 600K200M 1.5T0.5M 600K200M 1.5T0.5M Readability 200 g 500 g 200 g 500 g Weighing range 600 kg 1500 kg 600 kg 1500 kg Verification value 200 g 500 g 200 g 500 g...
