SMC8506T via a connection to a console terminal or PC using
a terminal emulation program Also shown in the diagram
below are two fans for cooling the unit.
Optional Modules
There are two optional modules; a 2-port 1000BASE-T and a 2-port 100BASE-FX.
These are shown, in that order, in the figure below.
2port Copper Giga (SMC8500GT)
Resetting your Gigabit Switch
At the left side of front panel, the reset switch is designed for
reconfiguring the switch without having to turn the unit off
and on.
CONSOLE RS232
19200,N,8,1
Rear panel of SMC8506T
2port Fiber Giga.(SMC8500SX)
100-240VAC 50-60Hz
