SMC Networks SMC8504T Specifications

Switches/Hubs
Network users and applications continue to increase
the use of bandwidth intensive software programs,
graphically dense materials and desire faster speeds to
the desktop. SMC EZ Switch 10/100/1000 meets that
demand with its 4 port standards-based gigabit
switch. This 1U rack mount or desktop switch seam-
lessly integrates with the rest of the network through
its auto-negotiating, non-blocking design. Featuring
advanced technologies such as VLAN, Priority Queing,
Trunking and Failover, the SMC8504T is the most cost
effect method for brining speed and service to the
desktop.
Overview
Features
• Full and Half duplex on all 10/100 ports with
Full-duplex mode for 1000Mbps
• 32k MAC Address Table
• Store-and-Forward mode with wire-speed
filtering and forwarding
• Auto MDI/MDIX on 1000BaseT ports
• Store-and-forward switching ensures error-
free transmission
• Half- and full-duplex flow control
• Smart function compatible for:
-Support on console port for switch
configuration change
-Support per port Port-based VLAN and L2
Trunking with link fail-over
-Support four Priority queues on each port
• Plug and play
• Built-in wiring crossovers on all ports
3 8 T e s l a
• "At-a-glance" LEDs for port and system
Irvine, CA 92618
status monitoring
• Desktop and rack mountable
1-800-SMC-4YOU
w w w. s m c. c o m
EZ Switch
4-port Unmanaged Layer 2 + Gigabit Switch
Benefits
• Store-and-Forward and wire-speed filtering and
forwarding rates ensures error free transmission of data
packets within the network
• ANSI/ IEEE compliance ensures compatibility with
standards-based hubs, switches and cards from any
vendor
• Half- and full-duplex flow control prevents packets from
being dropped under heavy loading
• Smart function compatible for advanced networking
procedures within the network to ensure priority settings
can still be maintained
• Plug and play for ease of installation, maintenance
and use.
• Built-in wiring crossovers on all ports allow connections
to servers and workstations to be made with straight-
through cabling
• "At-a-glance" LEDs for port and system status monitoring
• Desktop and rack mountable allowing flexibility within
your network design
10/100/1000
TM
Model Number::
Network Administrators will find the SMC8504T an
easy solution to integrate into a network as technolo-
gy migrates toward gigabit. It's Store-and-Forward
architecture combined with 32k MAC Address Table
ensures data integrity as the network is optimized to
run at full wire speeds.
Gigabit Ethernet is the perfect solution to bottlenecks
at the core of the network that are the inevitable result
of data-intensive applications and the proliferation of
new users. SMC's EZ Switch 10/100/1000 provides a
seamless migration to higher-speed networking while
solving bandwidth issues.
SMC8504T
Compatible
• IEEE 802.3 Ethernet
• IEEE 802.3u Fast Ethernet
• IEEE 802.3z Gigabit Ethernet
• IEEE 802.3x Flow Control
