EZ Switch 1000
u 4 10/100/1000 RJ-45 Ports
u Store-and-Forward mode with wire-speed filtering
and forwarding
u Auto MDI/MDIX on 1000BaseT ports
u Half- and full-duplex flow control
u "Smart Function" features:
Console port to manage configuration changes
n
Port-based VLAN and L2 Trunking with link
n
fail-over
u
Priority Queues on each port
n
Desktop and rack mountable
u
Plug and play for ease of installation, maintenance and
u
use
User Guide
SMC8504T
Advertisement
Table of Contents
Related Manuals for SMC Networks 8504T
Summary of Contents for SMC Networks 8504T
-
Page 1: User Guide
EZ Switch 1000 u 4 10/100/1000 RJ-45 Ports u Store-and-Forward mode with wire-speed filtering and forwarding u Auto MDI/MDIX on 1000BaseT ports u Half- and full-duplex flow control u "Smart Function" features: Console port to manage configuration changes Port-based VLAN and L2 Trunking with link fail-over Priority Queues on each port Desktop and rack mountable... -
Page 2: Limited Lifetime Warranty
Life of that Product, which is defined as the period of time during which the product is an 'Active' SMC product. A product is considered to be ‘Active’ while it is listed on the current SMC price list. As new technologies emerge, older technologies become obsolete and SMC will, at its discretion, replace an older product in its product line with one that incorporates these newer technologies. - Page 3 SMC is not responsible for any custom software or firmware, configuration information, or memory data of Customer contained in, stored on, or integrated with any products returned to SMC pursuant to any warranty. Products returned to SMC should have any customer-installed accessory or add-on components, such as expansion modules, removed prior to returning the product for replacement.
- Page 4 FROM STATE TO STATE. NOTHING IN THIS WARRANTY SHALL BE TAKEN TO AFFECT YOUR STATUTORY RIGHTS. * SMC will provide warranty service for one year following discontinuance from the active SMC price list. Under the limited lifetime warranty, internal and external power supplies, fans, and cables are covered by a standard one-year warranty from date of purchase.
- Page 5 Network users and applications continue to demand bandwidth intensive software programs, graphically dense materials and desire faster speeds to the desktop. SMC EZ Switch 1000 meets that demand with its 4 port standards-based gigabit switch. This 1U rack mount or desktop switch seamlessly integrates with the rest of the network through its auto-negotiating, non-blocking design.
-
Page 6: Features And Benefits
EZ S 1000 BOUT THE WITCH SMC8504T The EZ Switch 1000 (SMC8504T) is an 4-port Giga Ethernet Switch. Its 4 10/100/1000BASE-TX ports deliver dedicated 10/100/1000Mbps links to each attached LAN segment – all with conventional cabling and adapters. Auto-Negotiation is used to select the optional transmission speed and communication mode for each connection. -
Page 7: Equipment Checklist
EZ Switch 1000 SMC8504T Appropriate AC power cable RS 232 console port cable Rack mount bracket set SMC Warranty Registration Card This User Guide Selecting a Site Be sure to follow the site selection guidelines below when choosing a location:... - Page 8 Applying Power: Plug one end of the power cable into the power receptacle at the back of the switch, and the other end into an appropriate electrical outlet. Check the Power LED to be sure it is on. Note: It is not necessary to power off the switch before connecting or disconnecting any UTP cables, as these actions will not disrupt the operation of other devices attached to the switch.
-
Page 9: Hyper Terminal
Main Menu Launch the new terminal you just set up, and then, turn on the switch. See the following message for successful connection: SMC 8504T (4-port gigabit) [ver: x.xx] [ 0 ] Speed/ Duplex Setting [ 1 ] Address Learn... -
Page 10: Address Learning
Select: >> 1 Flow Control Enable flow control? (Y/N) After finish flow control selection “Please Wait” and configure another port or exit 3. Address Learning Aging Control A port’s MAC address register is cleared on power-up, or hardware reset. If this item is enabled, the dynamically learned SA will be learned if it is not refreshed in less than the aging time. -
Page 11: Uplink Port Setting
function) when one or more of the link in a trunk group fails. Select: >> 4 Which Trunk [ 0 ] Trunk 0 (Disable) [ 1 ] Trunk 1 (Disable) [ E ] Exit Select: >> Trunk port setting table Trunk Number Port Number Trunk 0, member >>... -
Page 12: View Configuration
[ E ] Exit Select: >> 8. View Configuration Display configuration of trunk, uplink and VLAN Select: >>7 [ Current TRUNK ] Disable [ Current UpLink ] Disable [ Current VLAN ] Group 1 >> 1234 Press any key to continue.. 9. - Page 13 EZ S 1000 S WITCH PECIFICATIONS Model SMC8504T Ports 4 RJ-45 ports 10/100Mbps, Twisted-pair, optional straight-through or crossover 1000Mbps, 4 pairs, optional straight-through or crossover Network Interface RJ-45: 100ohm, UTP/ STP cable 10/100Base – EIA/ TIA Categories 3 or 5 cable 1000Base –...
-
Page 14: Cable Specifications
Maximum Current 0.2A ¢N 110 VAC 0.1A ¢N 240 VAC Standards ANSI/ IEEE 802.3 ANSI/ IEEE 802.3u ANSI/ IEEE 802.3ab ANSI/ IEEE 802.3z EMC/ Safety Compliances CE Mark Emissions FCC Class A Safety CSA/UL (C22.2.950, UL 1950) Limited Warranty Lifetime ABLE PECIFICATIONS Cable Type and Connector... -
Page 15: Connectivity Guidelines
3 (Rx+) 1 (Tx+) 6 (Rx-) 6 (Rx-) 6 (Rx-) 2 (Tx-) Note: This EZ-8504T can support Auto MDI/ MDI-X. ONNECTIVITY UIDELINES Crossover/ Straight-Through Wiring Requirements If the port on the And the port on the Then use … cable EZ Switch 1000 is…... -
Page 16: Rear Panel
Rear Panel The AC power receptacle is located on the rear panel of the switch 100-240VAC 50-60Hz Console RS-232 19200,N,8,1... -
Page 17: Troubleshooting
ROUBLESHOOTING 1. Symptom Power LED does not light after power on. Probable Causes Power outlet or power cord may be defective. Possible Solutions Check for loose connections Check the power outlet by using it for another device. Replace the power cord. 2. - Page 18 FOR TECHNICAL SUPPORT, CALL: From U.S.A. and Canada (24 hours, 7 days a week) (800) SMC-4-YOU; (949) 707-2400; (949) 707-2460 (Fax) From Europe (8:00 AM - 5:30 PM UK Greenwich Mean Time) 44 (0) 1188 748740; 44 (0) 1189 748741 (Fax)
