F. istr. 38650_5213 9-07-2007 14:04 Pagina 1
CALEFFI
www.caleffi.com
Thermostatic Mixing Valves
Installation, commissioning and servicing instructions
AS 4032.1
WMKA 02466
Product Range
Item code 521312TM:
Item code 521319TM:
Safety
The Caleffi 5213TM series thermostatic mixing valve can give stable operation provided it is
installed, commissioned and maintained as per the recommendation outlined in this manual.
This valve cannot be considered as an alternative to adequate duty of care during its use and
operation.
General
The Caleffi 5213TM series is a high performance
thermostatic mixing valve and has been specifically
designed
and
requirements of "AS 4032.1 Thermostatic Mixing
Valves-Materials, Design and Performance
requirements".
In certain sections of our society, there is a need to
protect the most vulnerable from the danger of
scalding caused by hot water. Hence, the need for
thermostatic mixing valves.
The Caleffi 5213TMTM series provides water at a
safe and usable temperature in situation where the
control of the temperature of the water discharging
from a terminal fitting is of the utmost importance,
i.e. within hospitals, schools, nursing homes, etc.
The valve is designed to prevent the flow of water
discharging from the mixed water outlet in the event
of the failure of hot or cold supply.
The valve is complete with strainer and check valve
at both hot and cold inlets.
with strainers and check valves at the inlets 15 mm (1/2")
male,compression end connection for copper pipe.
with strainers and check valves at the inlets 20 mm (3/4")
male,compression end connection for copper pipe.
1
38650
5213TM series
manufactured
to
meet
the

Advertisement

loading
Need help?

Need help?

Do you have a question about the 5213TM series and is the answer not in the manual?

Questions and answers

Summary of Contents for CALEFFI 5213TM series

  • Page 1 Safety The Caleffi 5213TM series thermostatic mixing valve can give stable operation provided it is installed, commissioned and maintained as per the recommendation outlined in this manual. This valve cannot be considered as an alternative to adequate duty of care during its use and...
  • Page 2 F. istr. 38650_5213 9-07-2007 14:04 Pagina 2 Technical Data Materials: - Valve body: DZR alloy UNI EN 12165 CW602N - Regulating spindle: DZR alloy UNI EN 12165 CW602N - Internal shutter: - Sealing elements: EPDM - Cover: Set Temperature: must be commissioned on site to archive desired temperature Temperature control: ±2°C Minimum cold inlet temperature:...
  • Page 3 In the event of a failure of a the hot or cold supply, the piston will shut off, stopping water discharging from the mixed water outlet. The Caleffi valve requires a minimum temperature differential from hot inlet to mixed water outlet of 10°C to ensure the correct operation of the thermal shut off feature.
  • Page 4 20 mm Kv= 1,7 (m Flow rate The Caleffi 5213TM series is a thermostatic mixing valve suitable for a point of use application or for a limited number of outlets (maximum 3). For this reason the flow rate that is passing through the valve is the same as that of the final outlet, e.g.
  • Page 5 F. istr. 38650_5213 9-07-2007 14:04 Pagina 5 Exploded diagram PROTECTIVE HEAD TEMPERATURE SPINDLE LOCKING NUT UPPER BODY 'O' RING SEAL THERMOSTATIC ELEMENT FLOW CONVEYOR UNDER SPRING VALVE BODY SEAL UNION NUT INSERT CHECK VALVE TAIL PIECE BODY INSERT STRAINER...
  • Page 6 Prior to the installation of the Caleffi 5213TM series valve the system must be checked to ensure that the system operating conditions fall whithin the recommended operating range of the valve, i.e.
  • Page 7 The Caleffi 5213TM series provides water at a safe and usable temperature in situation where the control of the temperature of the water discharging from an outlet is of the utmost Importance i.e.
  • Page 8 Measure and record the temperature of the water discharging from the largest and smallest volume draw off points. d) Perform the thermal shut-off test. Isolate the cold water supply to the Caleffi valve and monitor the mixed water temperature. The outlet flow should quickly cease flowing.
  • Page 9 F. istr. 38650_5213 9-07-2007 14:04 Pagina 9 Temperature adjustment Remove the cap Direction of temperature adjustment Temperature adjustment Lock adjustment spindle with locking nut...
  • Page 10 With reference to the exploded diagram: 1) On the Caleffi 5213TM series valves, the inlet filters (12) on both the hot and cold water supplies can be removed for cleaning by unscrewing the inlet union nuts and carefully pulling apart the connecting pipework.
  • Page 11 F. istr. 38650_5213 9-07-2007 14:04 Pagina 11 Fault finding Under normal operating conditions the Caleffi 5213TM series thermostatic mixing valve will provide a very high level of performance. However, in some circumstances, where our maintenance plan is not followed, the following problems may arise.
  • Page 12 Approvals SAI global approval The Caleffi 5213TM series thermostatic mixing valves are approved by SAI Global as satisfactory to the requirements of AS 4032.1 : 2005 and it has the Licence N° 2466. NSW approval The Caleffi 5213TM series thermostatic mixing valves are approved by the relevant authorities for use in health care buildings.
  • Page 13 Children and neonates: 38°C to 40.5°C Safety cut off 43.5°C in case of Cold Water Failure Applications 1) The Caleffi 5213TM series are suitable for use with either mains pressure or gravity feed potable water supplies. 2) The system design, installation, commissioning and servicing must comply with the requirements specified in AS/NZS 3666, SAA/SNZ H332 and local legislation.
  • Page 14 F. istr. 38650_5213 9-07-2007 14:04 Pagina 14 Operating Limits I) For the manufacturer’s limits in terms of flow rates, pressures and temperature, refer to the manual code ..II) For optimum performance, dynamic supply pressures should be nominally balanced to within 10% of the lowest inlet pressure.
  • Page 15 F. istr. 38650_5213 9-07-2007 14:04 Pagina 15...
  • Page 16 F. istr. 38650_5213 9-07-2007 14:04 Pagina 16...
  • Page 17 F. istr. 38650_5213 9-07-2007 14:04 Pagina 17...
  • Page 18 F. istr. 38650_5213 9-07-2007 14:04 Pagina 18...
  • Page 19 F. istr. 38650_5213 9-07-2007 14:04 Pagina 19...
  • Page 20 30/205 Port Hacking Road Miranda NSW 2228 Tel. (02) 8543.5111 Fax (02) 8543.5122 E-mail: info@allvalve.com.au CALEFFI S.S. 229 · Km 26,5 · I-28010 Fontaneto d’Agogna (NO) · Tel. Int. +39 322 8491 R.A. · Fax +39 322 863723 Http://www.caleffi.com · E-mail:info@caleffi.it...
