- Page 1 Quick Start Guide i.MX 7ULP Evaluation Kit Based on the i.MX 7ULP Applications Processor...
- Page 2 Quick Start Guide GET TO KNOW THE EVALUATION KIT BASED ON THE i.MX 7ULP APPLICATIONS PROCESSOR MIPI-DSI SD card Power Connector slot switch HDMI connector Touchscreen Audio Jack Connector DC Jack Speaker connector USB HSIC WiFi/BT Arduino connector Micro-SD Slot...
- Page 3 ABOUT THE EVALUATION KIT BASED ON i.MX 7ULP The Evaluation Kit (EVK) based on the Hardware design files, tools and board i.MX 7ULP introduces developers to support packages (BSPs) for Linux ® the i.MX 7ULP applications processor. and Android are available at ®...
- Page 4 Quick Start Guide FEATURES The following features are available with the EVK based on the i.MX 7ULP applications processor: • i.MX 7ULP applications processor with • Sensors including: Cortex -A7 core and ARM ® ® ® - Accelerometer / Magnetometer...
-
Page 5: How To Get Started
USB Cable USB cable (micro-B to Android BSP images that are standard-A) available to program on to the MicroSD card Micro-SD card Bootable Linux image Table 1: Contents of the i.MX 7ULP Evaluation Kit Table 2: Download Software and Tools Contents... -
Page 6: Setting Up The System
Quick Start Guide SETTING UP THE SYSTEM Insert MicroSD Open the terminal window (i.e., Hyper Terminal or TeraTerm) and apply the Card following configuration: Insert the MicroSD card into socket J1 on • Baud rate: 115200 the SOM board (700-29163). •... -
Page 7: Boot Process
www.nxp.com BOOT PROCESS FOR LINUX IMAGE Boot Process • Change SW1 on the SOM board (700- 29163) to ON, OFF, OFF, ON (from bits 4-1) to boot from the MicroSD card, as shown in Figure 2. After the board images are programmed and the boot switches are correctly configured, the system is ready to run. -
Page 8: Dip Switch Configuration
Table 3 shows the switch configuration of boot mode for i.MX 7ULP EVK. Dual boot is chosen as default. BOOT MODE Dual boot Single boot Low power boot Download Table 3: i.MX 7ULP EVK DIP switch configuration (SW1 on SOM) -
Page 9: Button Functions
Evaluation kit RESET button • Button press will reset the system and begin a boot sequence. SW2 ON BB Evaluation kit switch • VOL+ SW3 ON BB Evaluation kit switch • VOL- Table 4: i.MX 7ULP EVK board button operations... - Page 10 Quick Start Guide The following information is provided per Article 10.8 of the Radio Equipment Directive 2014/53/EU: (a) Frequency bands in which the equipment operates. (b) The maximum RF power transmitted. (b) Max RF Technology (a) Freq Ranges (EU) Transmitted Power WLAN 2.4GHz 2412 MHz –...
- Page 11 www.nxp.com This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
-
Page 12: Warranty
SUPPORT Get Started Visit www.nxp.com/support for a list of phone numbers within your region. Download installation software and documentation WARRANTY under “Jump Start Your Design” Visit www.nxp.com/warranty for at www.nxp.com/iMX7ULPEVK. complete warranty information. www.nxp.com NXP and the NXP logo are trademarks of NXP B.V. All other product or service names are the property of their respective owners.
