Hirschmann RS20 User Manual

Redundancy configuration industrial ethernet switch
Hide thumbs Also See for RS20:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Programming Manual, User Manual
User Manual
Redundancy Configuration
Industrial ETHERNET Switch
RS20
Redundanz L2B
Technische Unterstützung
Release 5.0 04/09
HAC-Support@hirschmann.de

Advertisement

Table of Contents
loading

Related Manuals for Hirschmann RS20

Summary of Contents for Hirschmann RS20

  • Page 1 User Manual Redundancy Configuration Industrial ETHERNET Switch RS20 Redundanz L2B Technische Unterstützung Release 5.0 04/09 HAC-Support@hirschmann.de...
  • Page 2 This publication has been created by Hirschmann Automation and Control GmbH according to the best of our knowledge. Hirschmann reserves the right to change the con- tents of this manual without prior notice. Hirschmann can give no guarantee in respect of the correctness or accuracy of the details in this publication.

  • Page 3: Table Of Contents

    Content Content Content About this Manual Introduction Overview of Redundancy Procedure Ring Redundancy Example of HIPER-Ring 2.1.1 Setting up and configuring the HIPER-Ring Example of MRP-Ring Readers’ comments Index Further support Redundanz L3P+ Release 5.0 04/09...
  • Page 4 Content Redundanz L3P+ Release 5.0 04/09...

  • Page 5: About This Manual

    About this Manual About this Manual The “Redundancy Configuration” user manual contains all the information you need to select a suitable redundancy procedure and configure it. The “Basic Configuration” user manual contains all the information you need to start operating the device. It takes you step by step from the first startup operation through to the basic settings for operation in your environment.

  • Page 6: Key

    The designations used in this manual have the following meanings: List Work step Subheading Link Indicates a cross-reference with a stored link Note: A note emphasizes an important fact or draws your attention to a dependency. ASCII representation in user interface Courier Execution in the Web-based Interface user interface Execution in the Command Line Interface user interface...
  • Page 7 A random computer Configuration Computer Server PLC - Programmable logic controller I/O - Robot Redundanz L2B Release 5.0 04/09...
  • Page 8 Redundanz L2B Release 5.0 04/09...

  • Page 9: Introduction

    Introduction 1 Introduction The device contains a range of redundancy functions: HIPER-Ring MRP-Ring Redundanz L2B Release 5.0 04/09...

  • Page 10: Overview Of Redundancy Procedure

    Introduction 1.1 Overview of Redundancy Procedure 1.1 Overview of Redundancy Procedure Redundancy Network topology Switching time procedure HIPER-Ring Ring typically 80 ms, up to < 500 ms - practically indepen- dently of the number of devices MRP-Ring Ring typically 80 ms, up to < 500 ms - practically indepen- dently of the number of devices Table 1: Comparison of the redundancy procedures Redundanz L2B...

  • Page 11: Ring Redundancy

    Ring Redundancy 2 Ring Redundancy The concept of ring redundancy allows the construction of high-availability, ring-shaped network structures. With the help of the RM (Ring Manager) function, the two ends of a backbone in a line structure can be closed to a redundant ring. The ring manager keeps the redundant line open as long as the line structure is intact.
  • Page 12 Within a HIPER-Ring, you can use any combination of the following devices: – RS1 – RS2-./. – RS2-16M – RS2-4R – RS20, RS30, RS40 – RSR20, RSR30 – OCTOPUS – MICE – MS20, MS30 – Power MICE – MACH 100 –...

  • Page 13: Example Of Hiper-Ring

    Ring Redundancy 2.1 Example of HIPER-Ring 2.1 Example of HIPER-Ring A network contains a backbone in a line structure with 3 devices. To increase the redundancy reliability of the backbone, you have decided to convert the line structure to a HIPER-Ring. You use ports 1 and 2 in module 1 of the devices to connect the lines.
  • Page 14 Ring Redundancy 2.1 Example of HIPER-Ring Note: Configure all the devices of the HIPER-Ring individually. Before you connect the redundant line, you must complete the configuration of all the devices of the HIPER-Ring. You thus avoid loops during the configuration phase.

  • Page 15: Setting Up And Configuring The Hiper-Ring

    Ring Redundancy 2.1 Example of HIPER-Ring 2.1.1 Setting up and configuring the HIPER-Ring Set up the network to meet your requirements. You configure all 6 ports so that the transmission speed and the duplex settings of the lines correspond to the following table: Bit rate 100 Mbit/s 1000 Mbit/s...
  • Page 16 Ring Redundancy 2.1 Example of HIPER-Ring Figure 4: Ring Redundancy dialog Click on “Set” to temporarily save the entry in the configuration. Note: Deactivate the Spanning Tree protocol on the ports connected to the HIPER-Ring because Spanning Tree and Ring Redundancy affect each oth- er.

  • Page 17: Example Of Mrp-Ring

    Ring Redundancy 2.2 Example of MRP-Ring 2.2 Example of MRP-Ring A network contains a backbone in a line structure with 3 devices. To increase the redundancy reliability of the backbone, you have decided to convert the line structure to a ring redundancy. In contrast to the previous example, devices from different manufacturers are being used which do not all support the HIPER-Ring protocol.
  • Page 18 Ring Redundancy 2.2 Example of MRP-Ring Note: You cannot configure devices with L2B software as ring managers. You can exlusively use these devices as members of the redundant ring. Note: Configure all the devices of the MRP-Ring individually. Before you connect the redundant line, you must complete the configuration of all the de- vices of the MRP-Ring.
  • Page 19 Ring Redundancy 2.2 Example of MRP-Ring Figure 6: Ring Redundancy dialog Click on “Set” to temporarily save the entry in the configuration. The displays in the “Information” frame mean – “Redundancy existing”: One of the lines affected by the function can fail, whereby the redundant line will then take over the function of the failed line.
  • Page 20 Ring Redundancy 2.2 Example of MRP-Ring Redundanz L2B Release 5.0 04/09...

  • Page 21: A Readers' Comments

    Readers’ comments A Readers’ comments What is your opinion of this manual? We are always striving to provide as comprehensive a description of our product as possible, as well as important information that will ensure trouble-free operation. Your comments and suggestions help us to further improve the quality of our documentation.
  • Page 22 Zip code / City: E-mail: Date / Signature: Dear User, Please fill out and return this page as a fax to the number +49 (0)7127/14-1600 or Hirschmann Automation and Control GmbH Department AED Stuttgarter Str. 45-51 72654 Neckartenzlingen Redundanz L2B Release 5.0 04/09...

  • Page 23: B Index

    Index B Index Advanced Mode Configuration error 16, 19 Configuring the HIPER-Ring HIPER-Ring HiVision Network Management Software Redundancy Redundancy existing 16, 19 Redundancy functions Redundancy Manager Redundant Redundant coupling Ring Ring Manager Ring structure Symbol Technical questions Training courses Redundanz L3P+ Release 5.0 04/09...
  • Page 24 Index Redundanz L3P+ Release 5.0 04/09...

  • Page 25: C Further Support

    Further support C Further support Technical questions and training courses In the event of technical queries, please contact your local Hirschmann distributor or Hirschmann office. You can find the addresses of our distributors on the Internet: www.hirschmann-ac.codrm. Our support line is also at your disposal: Tel.
