MULTIQUIP Whiteman Series Operation And Parts Manual page 25

NOTICE
When going up or down a slope, always travel in the
forward direction (Figure 24).
Figure 24. Slope Travel Direction
TUB (BUCKET) DUMPING
The hydraulic dump can be controlled by the hand (dump
control lever) or foot (dump pedal).
1. To activate the hydraulic dump, press down on the
dump pedal (Figure 25) or move the dump control lever
forward. The tub will move to the vertical position as
long as pressure is continuously applied to the dump
pedal or the dump control lever is held in the forward
position.
WBH16/WBH16E POWER BUGGY (S/N 110401 & UP)• OPERATION AND PARTS MANUAL — REV. #1 (06/18/15) — PAGE 25
NOTICE
DO NOT activate dump mechanism (tub/bucket) if
buggy is facing down hill. The possibility exist of the
buggy tipping over causing equipment damage and
severe bodily harm.
NOTICE
Releasing either one (dump control lever or pedal)
before dump is completed, will cause the tub to return
to the horizontal position.
Figure 25. Dump Pedal
2. To return the tub to its horizontal position, simply
release the dump control lever or remove your foot
from the dump pedal.
OPERATION
