• sCRAPER ARM
The scraper arm is equipped with rubber pieces
which are wearing parts. They should be re-
placed occasionally to always ensure an optimum
efficiency of the scraper arm.
These pieces are easy to dismantle and to
reassemble.
Rubber pieces to
scrape the lid.
Rubber piece to scrape
the bowl
• MOTOR sEAL
The motor seal on the shaft should be lubricated
regularly using a food safe lubricant.
In order to keep the motor completely watertight,
it is advisable to check the motor seal regularly for
wear and tear and replace if necessary.
The motor seal can be easily replaced without
having to remove the motor, so we strongly advise
you to ensure that is in good condition.
10
27/03/2017
TECHniCAL sPECiFiCATiOns
• WEigHT
Net
Blixer 5 Plus 21 kg
®
Blixer 5 V.V. 22 kg
®
Blixer 6 23 kg
®
Blixer 6 V.V. 24 kg
®
• DiMEnsiOns (in mm)
®
BLixER 5 Plus
A = 480
B = 340
C = 280
D = 265
®
BLixER 5 V.V.
A = 480
B = 340
C = 280
D = 265
• WORKing HEigHT
We recommend that you position the machine on a
stable worktop so that the upper edge of the large
feed hopper is at a height of between 1.20 m and
1.30 m.
• nOisE LEVEL
The equivalent continuous sound level when the
machine is operating on no-load is less than 70 db
(A).
• ELECTRiCAL DATA
Blixer 5 Plus three-phase machine
®
Motor
Gross
24 kg
230-400 V/50 Hz
25 kg
25 kg
240 V/50Hz
26 kg
120 V/60Hz
220 V/60Hz
®
BLixER 6
A = 520
B = 340
Blixer 5 Plus single-phase machine
®
C = 280
D = 265
Motor
®
BLixER 6 V.V.
A = 520
B = 340
230 V/50 Hz
C = 280
D = 265
Blixer 5 V.V. single-phase machine
®
Motor
230 V/50-60 Hz
Blixer ® 6 three-phase machine
Motor
230-400 V/50 Hz
240 V/50Hz
Speed 1 Speed 2 Intensity
(rpm) (rpm) (Amp)
230 V=4.0
1,500
400 V=2.5
230 V=7.0
3,000
400 V=4.0
1,500
2.7
3.4
3,000
1,800
4.7
6,5
3,600
1,800
2.5
3.4
3,600
Speed Intensity
(rpm) (Amp)
3,000 8.5
Speed Intensity
(rpm) (Amp)
300 to 3,500 12
Speed 1 Speed 2 Intensity
(rpm) (rpm) (Amp)
230 V=4.0
1,500
400 V=2.5
230 V=7.0
3,000
400 V=4.0
1,500
2.7
3.4
3,000
