inTRODUCTiOn TO yOUR
nEW EMULsiFiER-MixER
Blixer 5 Plus • Blixer
®
Blixer 6 • Blixer
®
ROBOT-COUPE has developed a new concept in
Blixer
appliance: the ® .
Blixer
The ® combines the features of two well-
known appliances: the cutter and the blender-mixer.
Blixer
The ® is perfectly geared to professional
needs. It can perform any number of tasks which
you will soon discover as you use it.
Blixer
The ® will make it easy to prepare mixed
liquid or semi-liquid, raw or cooked meals.
Blixer
The ® replace the blender which does not give
entire satisfaction because of its incapacity to pro-
cess solid foods.
Thanks to its simple design, all components requiring
frequent handling for maintenance or cleaning are
easily fitted or removed.
To make things easier for you, this manual gives a
breakdown of all the various fitting operations.
This manual contains important information designed
to help the user get the most out of their device.
We therefore recommend that you read it care-
fully before using your machine.
sWiTCHing On
THE MACHinE
• ADViCE On ELECTRiCAL COnnnECTiOns
Before plugging in, check that your power supply
corresponds to that indicated on the machine's
identification plate.
This appliance must be plugged into an
5 V.V.
®
earthed socket (risk of electrocution).
6 V.V.
®
Three phase
Blixer
The ®
motor ratings :
This machine is supplied with a cable to which you
simply attach the appropriate electrical plug or
isolator for your system. The cable has four wires,
one earth wire, plus three phases wires.
if you have a 4-pin plug:
1) Connect the green and yellow earth wire to the
earth pin.
2) Connect the three other wires to the remaining
pins.
if you have more than 4 pins in the plug, please
note the ROBOT-COUPE does not require a neutral
wire.
switch on the empty machine, making sure that
the blade is rotating properly in an anti-clockwise
direction.
If the blade turns in a clockwise direction, swap
over two wires.
Swap either : the
W A R n i n g
Blixer 5 Plus • Blixer 6
® ®
5 Plus is available with the following
230 - 400 V / 50 Hz / 3
400 V / 50 Hz / 3
220 V / 60 Hz / 3
380 V / 60 Hz / 3
gREEn yELLOW is the earth,
DO nOT DisCOnnECT
➊ ➋
and the
➊ ➌
the and the
➋ ➌
or the and the
Blixer
single phase ® 5 Plus
Blixer
The ® 5 Plus is available with motor ratings :
230 V / 50 Hz / 1
220 V / 60 Hz / 1
The machine comes with a single phase plug
connected to a power cord.
Blixer Blixer
single phase ® 5 V.V. •
Blixer Blixer
The ® 5 V.V. and ® 6 V.V. are available
with motor ratings + variable speed :
230 V / 50-60 Hz / 1
The standardized plug must be calibrated to a
minimum of 13 amps and preferably 20 amps, if
the appliance is used intensively.

• COnTROL PAnEL

Red switch = Off switch
Green switch = On switch
Blixer Blixer
Three phase ® 5 Plus,
Blixer
® 6 V.V. : Pulse control.
Blixer Blixer
Three phase ® 5 Plus •
Speed selector = 1,500 or 3,000 rpm.
Blixer
Single phase ® 5 Plus : One speed 3,000 rpm
Blixer Blixer
® 5 V.V. and ® 6 V.V. : Speed variation
from 300 to 3,500 rpm.
1) With the motor base
facing you, position the
cutter bowl on the motor
base.
® 6 V.V.
® 5 V.V. and
® 6 :

AssEMBLy

7
