Replacing Belts or Brush Rolls (cont.)
5
Now, if the Flat Pump Belt
was broken, place a new
Flat Pump Belt around
the red area of the large
pulley. Then use your
thumb to stretch it toward
the back of the machine
and transfer it onto the
metal axle.
6
Spin either brush. If they both
spin, continue to Step 7.
If only one spins, the opposite belt
is broken and you must remove
both brushes and replace the Small
Cogged Brush Belt.
Place the new belt around both brush
gears and slide them onto the thin
metal axles.
8
9
Return the Brush Cover.
Return the Belt/Brush
Make sure that the
Access Plate to the end of
brushes are aligned and
the Brush Rolls by securing
the cover is secure.
with the 3 screws.
16
www.BISSELL.ca
7
To replace the Cogged Large Pump
Belt, make sure your deep cleaner
is completely reclined. Begin by
wrapping the Cogged Large Pump
Belt around the small metal-toothed
pulley. While wrapped around the
pulley, stretch and wrap around the
nearest brush gear.
10
Turn the machine
to lay on its back.
Lastly, slide the Belt
Access Door back into
place. You should hear
it "click" into place.
