Preparation - General information
Before connecting the battery or switching the main power supply on, unplug the in-
–
ternal siren for the time of the installation (small plug with cable, directly on the left
lower side of the display).
If the internal buzzer starts beeping: Press
–
To exit the system at any time: Press and hold the button
–
Reset back to factory setting:
Reset all pins and numbers: Press
–
Reset all individually changed parameters: Press
–

Language setting

1. Press simultaneously
Ctrl
the "Local Mode" opens.
2. Scroll with the buttons
tion "Language" and press
3. Scroll with the buttons
guage you prefer and press
4. To exit press and hold the button

Start programming

Programming the system (steps 2 -10) is
only possible in installer mode. To get into
installer mode the system must be disarmed!
1. Press user code "147258"
the displays shows: "CLIENT:USER".
2. Press installer code "258369"
the displays shows: "ISTALLER:USERS".

Clock setting

1. Set time: press
2. Set weekday: press
(Sunday = 1, Monday = 2...etc.)
3. Set date: press
4. Activate automatic daylight saving (default
Europe GMT+1): press
Detectors
Learn the wireless detectors (max.16), be-
fore installing, to the panel. Default settings:
- Zones 1 and 2 are delayed for entry route.
- Zones 3 - 8 are set for normal zones.
- Zones 9 - 16 are set for Stay zones.
We recommend using:
- Zone 1: magnet contact from the entry
door.
- Zone 2: first motion detector for the surveil-
lance of the entry area (control panel).
1. For zone 1: press
Siemens Building Technologies
Fire Safety & Security Products
/ to the posi-
to select.
/ to the lan-
to save.
.
26 1 " "
HHMM
26 2 " "
DAY
26 3 " "
DDMMYY
26 4 1
164 1
to silence it.
200 9 .
200 10
the keypad will start beeping to indicate
that learn mode has been activated.
2. Press the tamper contact on the detector
or remove the magnet from the door
contact
it will send a transmission signal. The
panel will confirm if a detector is found
with the message "Found".
3. Press to confirm.
4. Repeat actions 1 - 3 to follow up for the
zones 2 - 16 (use the navigation button
to switch to the next zone).
If a detector could not be learned it is either
already learned to the panel, or the transmis-
sion signal was not received - try again.
Already learned detectors can be checked in
"Find Detector" mode: press
Entry delay time
The entry delay time is set by default to 20
sec. To change the time (0-9999 seconds)
per zone:
1. Zone 1: press
2. Zone 2: press
Exit delay time
The exit delay time is set by default to 30
sec. To change the time (0 - 255 seconds)
per area:
Area A: press 60

Remote control

Learn a remote control (max. 16) to the
system starting with user number 21 - 25.
Default setting:
User 21: ARM
User 23: STAY
User 25: FREE
1. Remote control 1: press
.
.
166
144 1 "seconds"
144 2 "seconds"
1 "seconds"
User 22: DISARM
User 24:
simultaneously ) PANIC/SOS
(
18 21
EN
x
01.2008
