Summary of Contents for Unical Alkon 09 R 18
- Page 1 ALKON R 18 - C 18 R 24 - C 24 USER’S OPERATING INSTRUCTIONS 00333177 -1 edition - 06/2009...
-
Page 2: Correct Use Of The Appliance
Any other use of this appliance will be considered improper. UNICAL declines any responsibility for any damages or injuries caused by an improper use; in this case the risk is completely at the user’s responsibility. In order to use the appliance according to the scopes it was designed for it is essential to carefully follow the instructions indicated in this guide. -
Page 3: General Information
UNICAL; UNICAL recommends drawing up a service contract. Bad or irregular servicing could compromise the safe operation of the appliance, and could cause injury to persons, animals or damage to property for which UNICAL shall not be held liable. Alterations to parts connected to the appliance... -
Page 4: Operating Instructions
User’s operating instructions 6 - OPERATING INSTRUCTIONS 6.1 - CONTROL PANEL °C ® A = Manometer B = Summer/Winter switch + Heating temperature controller C = D.H.W. temperature controller D = Push button for RESET/CALIBRATION/DIAGNOSTICS E = Display F = Symbol indicating a heating request G = Symbol indicating a D.H.W. - Page 5 User’s operating instructions Thermometer Indication of burner in operation It shows the boiler or the DHW temperature. This symbol indicates the burner is in operation. The symbol is shown when the boiler receives a If, on the display, the symbol heat request for C.H.
- Page 6 User’s operating instructions C.H. mode (Winter mode) 6.2 - CHECK LIST BEFORE COMMISSIONING THE BOILER In order to have the boiler operating for C.H. purposes, the pointer of the knob (B) has to be positioned between 1 (minimum Before commissioning the appliance it is recommended to temperature) (maximum check the following points:...
-
Page 7: Filling Valve
If the cut-off device operates repeatedly (a operation. maximum of 3 times), causing boiler shu- He has to address him self to an UNICAL tdown, do not try to relight the boiler your- authorized after sale service. self. Contact your nearest Unical authorized... - Page 8 - info@unical-ag.com The Unical declines every responsibility for the possible inaccuracies if owed to errors of transcript or press. Also reserves the right to bring those changes that it will hold necessary to it own products or profits, without jeopardizing its...
