Figure 2
IntelliPad parts guide; front view
a
b
(a) Electrical Box
(b) Wire
(c) Dust Shield
(d) IntelliPad Unit
(e) Source Select Keys
(f) Function Control Keys
(g) Device Screws (4 supplied)
(h) Source Select Key Decora-
Style Insert
Note: The above figure illustrates how the IntelliPad would be installed by itself. However,
because of its modular Decora-style design, the IntelliPad can be combined in a three or four-
gang configuration with additional wall-mount control devices.
P
R O G R A M M A B L E
c
f
e
d
(i) Function Control Key Decora-
Style Insert
(j) Decora Two-Gang Faceplate
(not supplied)
(k) Faceplate Screws
(not supplied)
I R K
S
E Y P A D
Y S T E M
g
i
h
j
k
