Sollae Systems CIE-H12 User Manual

1port remote i/o controller (dry / wet contact support)
Hide thumbs Also See for CIE-H12:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
1port Remote I/O Controller
(dry / wet contact support)
CIE-H12 User's Manual
Version 1.3
Sollae Systems Co., Ltd.
http://www.sollae.co.kr

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CIE-H12 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sollae Systems CIE-H12

Summary of Contents for Sollae Systems CIE-H12

  • Page 1 1port Remote I/O Controller (dry / wet contact support) CIE-H12 User’s Manual Version 1.3 Sollae Systems Co., Ltd. http://www.sollae.co.kr...
  • Page 2 CIE-H12 User’s Manual Ver. 1.3 To all residents of the European Union Important environmental information about this product This symbol on this unit or the package indicates that disposal of this unit after its lifecycle could harm the environment. Do not dispose of the unit as unsorted municipal waste;...

  • Page 3: Table Of Contents

    CIE-H12 User’s Manual Ver. 1.3 Contents Contents ............................- 2 - Introduction ..........................- 5 - 1.1 Introduction ................................- 5 - 1.2 Application Examples ............................- 6 - 1.3 Components ................................. - 7 - 1.4 Specification ................................. - 7 - 1.4.1 H/W specification .............................
  • Page 4 CIE-H12 User’s Manual Ver. 1.3 Methods for I/O control ....................- 24 - 5.1 MODBUS/TCP ..............................- 24 - 5.1.1 Related Parameters ..........................- 24 - 5.1.2 Modbus/TCP Slave Mode ........................- 25 - 5.1.3 Modbus/TCP Master Mode ....................... - 25 - 5.1.4 TCP Connection Modes ........................
  • Page 5 CIE-H12 User’s Manual Ver. 1.3 Technical Support, Warranty, and Precaution ..............- 46 - 9.1 Technical Support ............................- 46 - 9.2 Warranty ................................- 46 - 9.2.1 Refund ................................. - 46 - 9.2.2 Free Repair Services ..........................- 46 - 9.2.3 Charged Repair Services........................

  • Page 6: Introduction

    HTTP, Modbus/TCP and Macro mode can be used for these functions. The CIE-H12 has two input ports and one output port. One of the input ports is a dry- contact type and the other one is wet-contact. Thus, you are allowed to use it under both types of systems.

  • Page 7: Application Examples

    CIE-H12 User’s Manual Ver. 1.3 Application Examples  remote I/O device server Figure 1-1 remote I/O device server  Internet Switch Figure 1-2 internet switch  Macro mode Figure 1-3 macro mode Sollae Systems Co., Ltd. - 6 - http://www.sollae.co.kr...

  • Page 8: Components

    CIE-H12 User’s Manual Ver. 1.3 Components  The CIE-H12‟s body  5V Power Adapter Specification 1.4.1 H/W specification Input Power 5V (±10%) Power Current Consumption 305mA typical Size 96mm x 57mm x 24mm Weight Approximately 68g ARM7 Core Memory ROM: 256K bytes Flash Memory, RAM: 64K bytes SRAM...

  • Page 9: Interface

    Interface 1.5.1 Input Ports The CIE-H12 has two input ports and the each has different type with the other. The one is a “DRY CONTACT” type and the other one is a “WET CONTACT.” Figure 1-4 input ports (the front view) In the front panel, the DRY IN(0) port is the dry contact type and the WET IN(1) port is the wet contact type.
  • Page 10 CIE-H12 User’s Manual Ver. 1.3  The voltage input type (Wet contact) Figure 1-6 the wet contact input port You can give a DC voltage to input signal to this port. This port is isolated by photo- couplers and you don‟t have to care about the polarity. The circuit diagram of the input port is shown in the figure below.

  • Page 11: Output Ports

    As shown on the above table, the relay has the capacity to “switch” 5 A – AC250V. However,  the CIE-H12 is most appropriate for switching devices in lower voltage conditions than that. Sollae Systems Co., Ltd. - 10 -...

  • Page 12: Ethernet Interface

    CIE-H12 User’s Manual Ver. 1.3 1.5.3 Ethernet Interface An RJ45 connector is for the network interface of the CIE-H12. You can use a UTP cable. It automatically senses 10Mbits or 100Mbits Ethernet. It also provides auto MDI/MDIX function that can automatically sense 1:1 cable or cross over cable.

  • Page 13: System Led

    There is an ISP switch located on the side of the product. This button is for changing the mode to the ISP mode. If the button is pressed over a second or the power is supplied when you are pressing the button, the CIE-H12 will be operated as ISP mode. Figure 1-12 ISP switch In the ISP the password and access restriction could be restored or reset.

  • Page 14: Installation And Test

    Figure 2-1 the connection between H12 and a PC 2.1.1 Setting Network Aera This step is for setting both the CIE-H12 and your PC to be located the same network. If only they are, the TCP connection between them can be established.  Setting of the PC Add or change the IP address of the network adapter on your PC.
  • Page 15 MS Windows and this is comfortable to use because it doesn‟t need installation process. First, search your CIE-H12 via network. All the values of parameters are set to the default values in the factory. To apply it to your system, proper values should be set via ezManager.

  • Page 16: Test Operation

    Test operation 2.2.1 Modbus/TCP Test This is for checking the operation of Input and output ports of the CIE-H12 via Modbus/TCP. In this instruction, offered Modbus/TCP test program was used. Run ezManager. Then, you can show the window like the figure below.
  • Page 17  Modbus/TCP test Figure 2-4 Modbus/TCP test ① Input the IP address of the CIE-H12 ② Input the local port for Modbus/TCP of the CIE-H12 In a local area network, ① and ② steps can be omitted.  ③ Try to connect by pressing [Connect] button ④...

  • Page 18: Http Test Wih A Web Browser

    2.2.2 HTTP Test wih a WEB browser This is for testing the operation of Input and output ports of the CIE-H12 via HTTP. The test was implemented with a WEB browser. You can use WEB browsers such as MS Internet Explorer, Google Chrome and Mozilla Firefox.

  • Page 19: Configuration

    Configuration via LAN  Checklists Make sure of the connection between your PC and the CIE-H12 via Ethernet. If they are in the same network, [MAC Address search] button can be used. If they aren‟t, only [IP Address search] is allowed to use.

  • Page 20: Assigning The Ip Address Automatically

    CIE-H12 User’s Manual Ver. 1.3 Assigning the IP address automatically 3.2.1 Obtain an IP automatically (DHCP) In the network environment which a DHCP server is operated, settings such as the IP address, subnet mask, gateway, and the name servers can be automatically designated using DHCP protocol.

  • Page 21: Obtain An Ip Automatically (Pppoe)

    PPPoE is used in most ADSL and VDSL networks. To use PPPoE function, PPPoE function should be enabled and PPPoE ID and PPPoE password should be configured. The local IP address of the CIE-H12 is assigned automatically in PPPoE environment. In this case, you can set the address of DNS server manually or automatically.

  • Page 22: Notify Ip Change

    3.2.3 Notify IP Change The CIE-H12 can be a TCP server even though it is assigned the IP address automatically. Using [Notify IP Change] function, it sends its IP address with the host name to the specific server. There are 3 types (DDNS, TCP and UDP) of functions provided.

  • Page 23: Operation Modes

    CIE-H12 User’s Manual Ver. 1.3 Operation Modes What is the Operation Mode? Each of two operation modes are designed for specific purposes, and those are as follows:  Normal mode This mode is for normal data communication and has 5 different communication modes.

  • Page 24: Comparison Of The Each Mode

     control types Table 4-2 digital I/O control types Types Description Control and monitor the I/O of the CIE-H12 via Modbus/TCP. Modbus/TCP It supports both master and slave mode. Users can automatically control the output ports by setting MACRO Macro using some basic formula of Boolean Algebra.

  • Page 25: Methods For I/O Control

    CIE-H12 User’s Manual Ver. 1.3 Methods for I/O control MODBUS/TCP The CIE-H12 supports Modbus/TCP. By using this protocol, it remotely monitors and controls I/O devices. To use this method, your application should support this protocol. 5.1.1 Related Parameters Table 5-1 Modbus/TCP related parameters...

  • Page 26: Modbus/Tcp Slave Mode

    According to the standard Modbus/TCP you can use a Modbus/TCP manager to control and monitor their I/O devices. Like this standard, you can set the CIE-H12 to the [Slave] item to [Slave] mode. The [Passive] connection would be better than the [Active] in this mode and the [Peer Port] should be 502.

  • Page 27: Tcp Connection Modes

    5.1.5 Initial Output Value The initial value of the CIE-H12‟s output port can be configured. Depending on the value of [Initial State] at the boot time, output ports are set to ON or OFF. 5.1.6 Write Pulse By using the function code 105, you can give the signal of pulse type to the output ports.

  • Page 28: Macro Mode

    CIE-H12 User’s Manual Ver. 1.3 Macro Mode This mode let users set the values of the output ports with simple macros. The CIE-H12 reflects the values according to the macro expressions which are configured by users in advance. It will be useful when users set the output values automatically from combinations of inputs.

  • Page 29: An Example Of Equations

    CIE-H12 User’s Manual Ver. 1.3 5.2.3 An Example of Equations Here are two examples. In the expressions, spaces between the two operands will be ignored. Table 5-5 an example of equation Do0 ex. 1 i0 + i1 Perform bit OR i0 and i1 Do0 ex.

  • Page 30: Monitoring And Controlling On Web (Http)

    If the CIE-H12 has a password set, a window for authentication will be popped up. Figure 5-1 authentication with password ① the CIE-H12 does not care the [User name]. (You don‟t have to fill the box) ② [Password] should be the same with password which is set through the ezManager.

  • Page 31: Uploading Users" Webpage

    I/O ports with your webpage made by yourself.  Upgrading HTML files CIE-H12 has a default webpage when it is manufactured in the factory. For advanced users, we have been offering some examples (sample web pages) based on various technologies such as CSS and J query.

  • Page 32: System Management

    6.1.1 Firmware Firmware is a type of software for operation of the CIE-H12. If there are needs for adding function or fixing bugs, the firmware will be modified and released. We recommend that users keep use the latest released firmware.
  • Page 33 CIE-H12 User’s Manual Ver. 1.3  Checking firmware file and Sending Figure 6-2 sending firmware file ① Check if the name and path of the firmware file are correct ② Click the [Send] button ③ Confirm the completed message Sollae Systems Co., Ltd.

  • Page 34: Changing Homepage

    ② Click the [Change F/W / HTML] button to run TFTP client ③ Select the [Change HTML] radio button ④ Input the IP address of the CIE-H12 to the [Local IP Address] text box ⑤ Press the [Open Firmware / HTML] button and choose the HTML file Sollae Systems Co., Ltd.
  • Page 35 CIE-H12 User’s Manual Ver. 1.3  Checking firmware file and Sending Figure 6-4 sending firmware file ① Check if the name and path of the html file including all images are correct ② Click the [Send] button ③ Confirm the completed message Sollae Systems Co., Ltd.

  • Page 36: Status Monitoring

    Status Monitoring 6.3.1 Using TELNET Once the [TELNET] option is activated, users can remotely log in to the CIE-H12. If a password is set, users should input the password. After then, messages from the CIE-H12 appear like the figure below.
  • Page 37 CIE-H12 User’s Manual Ver. 1.3  st uptime “st uptime” command shows amount of time since H12 has booted up. Figure 6-7 “ST UPTIME” command  sc “sc” command is used when users close a session. [OP1] means the name of session, and [OP2] should be “CLOSE”.

  • Page 38: Checking Status By Ezmanager

    CIE-H12 User’s Manual Ver. 1.3 6.3.2 Checking status by ezManager Status of the CIE-H12 can be monitored by [Status] button on ezManager. By using the [Refresh Every 1 Second] option in the status window, the status is automatically updated in every second.
  • Page 39  Password This text box is activated when the CIE-H12 has a password. If users want to close the TCP connection, this password has to be correctly filled.  Refresh Every 1 Second.

  • Page 40: Debugging Message

    CIE-H12 User’s Manual Ver. 1.3 6.3.3 Debugging Message By using [Debugging] option, users can receive debugging messages from the CIE-H12 on the network. When you are facing a problem about the TCP connection or data communication, please  use this function and send us the stored file. We can use it for finding out the reason of your problem.
  • Page 41 Figure 6-11 debugging message window ① Pull down menu for selecting a network adapter ② Place for showing received debugging messages from the CIE-H12 over the network ③ Auto update to display the latest captured file on the screen of ②...

  • Page 42: Additional Functions

    The maximum length is 8 bytes of Alphabet or number. When you want to revoke all of these restrictions, change the mode of the CIE-H12 to the  ISP mode. All restrictions are removable and communication with ezManager is revoked in the ISP mode.

  • Page 43: Valid Time

    The CIE-H12 gives output values to the output ports after the amount of time has set in the [Delay]. If users set the value of [Delay] to 0, the CIE-H12 gives the output value to the output port immediately. The unit used for the [Delay] is 1ms. However, because the accuracy is only guaranteed in 10ms, the designated values are rounded down in units of 10ms.

  • Page 44: Self-Test In Trouble

    CIE-H12 User’s Manual Ver. 1.3 Self-Test in Trouble When users are in trouble with the CIE-H12, make sure of the following steps first. Searching problem with ezManager  Confirming types of configuration utility The CIE-H12 can be configured by ezManager.

  • Page 45: Connection Problem Over Modbus/Tcp

    Under this circumstance, users should ask the person in charge of their network to release ports which will be used. (Ex: TCP 502, UDP 50005)  Operation Mode A TCP connection is not possible when the CIE-H12 is operating in the ISP or Serial Configuration mode.  Connection Mode To make a TCP connection, both a server (passive mode) and a client (active mode) should exist.

  • Page 46: Communication Problem Over Modbus/Tcp

    CIE-H12 User’s Manual Ver. 1.3 Communication Problem over Modbus/TCP  Checking Modbus/TCP parameters Check all the related parameters that [Unit ID], [Input Port Base Address], [Output Port Base Address], [Poll Interval] and [Notify Input change].  Checking which mode is using In case of MACRO or serialized Modbus/TCP, you can control the outputs of the CIE- H12.

  • Page 47: Technical Support, Warranty, And Precaution

    Technical Support, Warranty, and Precaution Technical Support If you have any question regarding operation of the product, visit Customer Support FAQ corner and the message board on Sollae Systems‟ web site or send us an email at the following address:  E-mail: support@eztcp.com...

  • Page 48: Precaution

    CIE-H12 User’s Manual Ver. 1.3 Precaution  Sollae Systems is not responsible for product failures occurring due to user ‟s alternation of the product.  Specifications of the product are subject to change without prior notice for performance improvement.  Sollae Systems does not guarantee successful operation of the product if the product was used under conditions deviating from the product specifications.

  • Page 49: History

    CIE-H12 User’s Manual Ver. 1.3 10 History Data Version Comments Author 2011.08.01 ○ Initial release Roy LEE 2011.08.02 ○ Product‟s picture has been replaced. Roy LEE 2011.08.04 ○ Gap of the output port has been corrected. Roy LEE 2011.12.22 ○ Descriptions of DynDNS service has been changed.
