CIE-H12G User Manual Ver. 1.1
Remote I/O Controller
CIE-H12G User Manual
Version 1.1
Sollae Systems Co., Ltd.
https://www.ezTCP.com
- 0 -
https://www.eztcp.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CIE-H12G and is the answer not in the manual?

Questions and answers

Summary of Contents for Sollae Systems CIE-H12G

  • Page 1 CIE-H12G User Manual Ver. 1.1 Remote I/O Controller CIE-H12G User Manual Version 1.1 Sollae Systems Co., Ltd. https://www.ezTCP.com - 0 - https://www.eztcp.com...
  • Page 2 CIE-H12G User Manual Ver. 1.1 This symbol, found on your product or on its packaging, indicates that this product should not be treated as household waste when you wish to dispose of it. Instead, it should be handed over to an applicable collection point for the recycling of electrical and electronic equipment.
  • Page 3: Table Of Contents

    CIE-H12G User Manual Ver. 1.1 Contents Contents ............................- 2 - Overview ..........................- 5 - Overview ................................- 5 - Main Features ..............................- 5 - Application Examples ..........................- 6 - Specification ..............................- 7 - 1.4.1 H/W specification ........................... - 7 - 1.4.2...
  • Page 4 CIE-H12G User Manual Ver. 1.1 4.5.2 Changing Firmware ..........................- 20 - I/O Control ..........................- 21 - MODBUS/TCP ............................... - 21 - 5.1.1 Related Parameters ..........................- 21 - 5.1.2 Modbus/TCP Slave Mode ........................ - 22 - 5.1.3 Modbus/TCP Master Mode ......................- 22 - 5.1.4...
  • Page 5 CIE-H12G User Manual Ver. 1.1 7.2.3 Delay ................................- 38 - 7.2.4 Master function for configuring Internet switches .............. - 39 - Self-Test in Trouble ......................- 40 - Searching problem with ezManager ....................- 40 - Connection Problem over Modbus/TCP ..................- 41 - Communication Problem over Modbus/TCP .................
  • Page 6: Overview

    CIE-H12G provides the functionality of remotely monitoring sensors such as temperature, humidity, and pressure, as well as controlling power supplies remotely. CIE-H12G detects ON/OFF by receiving digital output from sensors and controls an output port through remote requests. It supports Modbus/TCP, HTTP, and macro functions for input/output control.
  • Page 7: Application Examples

    CIE-H12G User Manual Ver. 1.1 1.3 Application Examples ⚫ 1:1 Connection with a remote host (HMI) Figure 1-1 1:1 Connection with a remote host (HMI) ⚫ 1:N Connection with a remote host (Web) Figure 1-2 1:N Connection with a remote host (Web) ⚫...
  • Page 8: Specification

    CIE-H12G User Manual Ver. 1.1 1.4 Specification 1.4.1 H/W specification Input Power DC 5V (±10%) Power Current Consumption 160mA typical Size 96mm x 57mm x 24mm Weight Approximately 68g 2 Digital input ports Digital Input (Dry contact / wet contact)
  • Page 9: Interface

    CIE-H12G User Manual Ver. 1.1 1.5 Interface 1.5.1 Input Ports CIE-H12A has two input ports and the each has different type with the other. The one is a “DRY CONTACT” type and the other one is a “WET CONTACT.” ⚫ DRY IN: a non-voltage contact type The DRY IN port is an input port with a non-voltage contact type.
  • Page 10 CIE-H12G User Manual Ver. 1.1 ⚫ WET IN: a wet volage contact type Figure 1-5 the WET IN port The WET IN port is an input port with a wet voltage contact method. The port is insulated through a photocoupler and detects ON/OFF through DC voltage input.
  • Page 11: An Output Port

    An Output Port Figure 1-7 an output port An output port of CIE-H12G is interfaced to a NO (Normal Open) type relay. Figure 1-8 a circuit diagram of the output port The operations of an output port are as follows:...
  • Page 12: Ethernet Interface

    Ethernet and its specifications are as follows: Figure 1-9 Ethernet connector 1.5.4 Power CIE-H12G can be powered by DC 5V source via power jack. The specifications of the power jack are as follows: Figure 1-10 power jack - 11 -...
  • Page 13: System Led

    CIE-H12G User Manual Ver. 1.1 1.5.5 System LED CIE-H12G has 4 LEDs to indicate the current system status. Each LED represents the following status: place name color LED status description blinks in assigned an IP address every second blinks 4...
  • Page 14: Installation And Test

    Figure 2-1 Installation 2.1.1 Setting Network Aera This step is for setting both CIE-H12G and your PC to be located on the same network to establish a TCP connection. ⚫ Setting of the PC Set the IP address to the Ethernet adapter of the PC connected to the product as follows.
  • Page 15 CIE-H12G User Manual Ver. 1.1 ⚫ Setting of CIE-H12G CIE-H12G uses ezManager as it’s a configuration program. The Simple Test is performed with the environmental variables of CIE-H12G set to their default values. The main environmental variables and their default values of CIE-H12G...
  • Page 16: Simple Test

    This is a test for monitoring and controlling with Modbus/TCP. This test uses the Modbus/TCP program in ezManager. Figure 2-3 Modbus/TCP test program ① Search the connected CIE-H12G with [Search All] button. ② Select a MAC address of searched product on the [search result]. ③ Click the [Tools] - [Modbus/TCP] button.
  • Page 17 Figure 2-4 Modbus/TCP test ① Input the IP address of CIE-H12G ② Input the local port for Modbus/TCP of CIE-H12G ③ Connect by pressing [Connect] button ④ Under the connection, check if the Di LEDs are turned on or off with signal input ⑤...
  • Page 18: Http Test With A Web Browser

    CIE-H12G User Manual Ver. 1.1 2.2.2 HTTP Test with a WEB browser This is for testing the operation of the I/O ports of CIE-H12G via HTTP. The test was implemented on a WEB browser. Figure 2-5 HTTP test ① Input the IP address of your CIE-H12G on the address field (default: 10.1.0.1).
  • Page 19: Configuration

    Configuration via LAN ⚫ Checklists Make sure of the connection between your PC and CIE-H12G via Ethernet. If they are in the same network, [MAC Address search] button can be used. Otherwise, only [IP Address search] is allowed to use.
  • Page 20: Operation Modes

    This mode is for normal data communication. Configuring parameters is also available in this mode. ⚫ Serial configuration mode CIE-H12G does not provide configuration function in serial setting mode. ⚫ ISP mode This mode is for changing firmware. In addition, you can set environmental parameters even though the security options are activated.
  • Page 21: Normal Mode

    CIE-H12G User Manual Ver. 1.1 4.3 Normal Mode In the normal mode, there are three types of I/O control methods. ⚫ I/O control methods Methods Descriptions Modbus/TCP Monitor/Control the I/O ports via Modbus/TCP Macro Control the Output ports via Macro function...
  • Page 22: O Control

    CIE-H12G User Manual Ver. 1.1 5 I/O Control MODBUS/TCP CIE-H12G supports Modbus/TCP as the default protocol for I/O control. 5.1.1 Related Parameters Parameter Description Modbus/TCP Using Modbus/TCP for controlling I/O ports of CIE-H12G. Slave The slave responses by queries from the Master...
  • Page 23: Modbus/Tcp Slave Mode

    According to the standard Modbus/TCP, users can use a Modbus/TCP manager to control and monitor their I/O devices. You can set CIE-H12G to the [Slave] item to [Slave] mode. The [Passive] connection is recommended in this mode and the [Peer Port] should be 502.
  • Page 24: Write Pulse

    By using the FC105, you can give the signal of pulse type to the output port. This means the output signal is kept during the specific time configured by users. 5.1.7 Communication with HMI In case of communication HMI with CIE-H12G, please refer to the address table below. ⚫ Examples of HMI address references Address...
  • Page 25: Macro Mode

    This mode lets users set the values of the output port with simple macros. Since CIE-H12G reflects the values according to the macro expressions which are configured by users in advance, it is useful to make a specific device operate automatically using signals from various sensors.
  • Page 26: Operands

    CIE-H12G User Manual Ver. 1.1 5.2.2 Operands Operands used in macro mode are each input port. Each input port is designated with i0 ~ i3 symbol based on their sequence. Since operands are case-insensitive, they can also be written as I0 ~ I3.
  • Page 27: Web (Http)

    The CIE-H12G provides changing a web page function. Users can modify or create new web pages for the CIE-H12G, instead of using the default web page, as long as they know simple script syntax. Our website provides various web page samples in different formats to use in creating user’s own web page.
  • Page 28: Management

    6.1 Changing Firmware 6.1.1 Firmware Firmware is a type of software for operation of CIE-H12G. If there are needs for adding function or fixing bugs, the firmware is modified and released. We recommend that users keep use the latest released firmware.
  • Page 29: Changing A Web Page

    CIE-H12G User Manual Ver. 1.1 6.2 Changing a Web page CIE-H12G comes with a default web page stored when it leaves the factory. Follow the steps below to change the web page to a another one. 6.2.1 Processes ⚫ Creating a web page / Downloading a sample web page Create a new web page or download a sample web page on our web site.
  • Page 30: Status Monitoring

    If the [TELNET] function in the [Option] tab of ezManager is enabled, users can log in to the CIE-H12G via Telnet. The login password used is the password set in the product, and if no password is set, the default password is 'sollae'.
  • Page 31 CIE-H12G User Manual Ver. 1.1 ⚫ st net6 This command shows session information of IPv6 network. lsh>st net6 proto name local/peer address sendq state ------ ----- ------------------------------------- ------ ---------------- TCP6 fe80::230:f9ff:fe12:1002( ESTABLISHED fe80::f965:11c7:ea03:9987(55717) lsh> Figure 6-5 st net6 ⚫ st uptime This command shows your device’s uptime.
  • Page 32: Using Ezmanager

    CIE-H12G User Manual Ver. 1.1 6.3.2 Using ezManager Status of CIE-H12G can be monitored by [Status] button on ezManager. By using the [Refresh Every 1 Second] option in the status window, the status is automatically updated in every second. Figure 6-9 Status window of ezManager ⚫...
  • Page 33 CIE-H12G User Manual Ver. 1.1 ⚫ TCP STATE TCP status of each port is shown this section. Message Description LISTEN listening TCP connection CLOSE TCP connection is closed SYN_SENT Send “SYN” segment to make TCP connection ESTABLISHED When TCP connection is established...
  • Page 34 When right click on a session, a small pop-up window is created. ⚫ Password This text box is activated when CIE-H12G has a password. If users want to close TCP connection with right click of mouse on the session, this password has to be correctly filled.
  • Page 35 CIE-H12G User Manual Ver. 1.1 ⚫ Refresh Every 1 Second. If this option is checked, ezManager send query in every second. ⚫ IP address Conflict Detection By clicking this button, you can find devices which have the same IP address to yours on the network.
  • Page 36: Factory Reset

    CIE-H12G User Manual Ver. 1.1 6.4 Factory Reset Performing factory reset restores all setting values except for a password to the factory default. How to perform the factory reset is as follows. ⚫ Entering to Serial configuration mode Press the ISP button shortly (less than 1 second) and release it. STS, RXD and TXD LED blink simultaneously in this state.
  • Page 37: Additional Functions

    CIE-H12G User Manual Ver. 1.1 7 Additional Functions 7.1 General 7.1.1 ezTCP Firewall On the [Option] tab of ezManager, users can set restriction of access function with filtering MAC and IP address. ⚫ Allowed MAC Address If this option has a value of MAC address, the device which has the MAC address is only permitted to access.
  • Page 38: Setting Password

    The maximum length is 8 bytes of Alphabet or number.  When you want to revoke all of these restrictions, operate CIE-H12G as ISP mode. In the mode, all restrictions are removable and communication with ezManager is revoked.
  • Page 39: I/O Control

    7.2.2 Valid Time CIE-H12G recognizes a signal on its input port as a valid signal only if it is maintained for the duration of the Valid Time. If the signal on the input port is not maintained for the time set in this item, it will be ignored. The unit is 1ms.
  • Page 40: Master Function For Configuring Internet Switches

    CIE-H12G User Manual Ver. 1.1 7.2.4 Master function for configuring Internet switches CIE-H12G provides master functionality for configuring an Internet switch. An Internet switch is a configuration method that connects devices to devices via Modbus/TCP, transmitting digital inputs to digital outputs. In this configuration, one side must be set as a master and the other as a slave.
  • Page 41: Self-Test In Trouble

    CIE-H12G User Manual Ver. 1.1 8 Self-Test in Trouble When users are in trouble with using CIE-H12G, make sure of the following steps first. 8.1 Searching problem with ezManager ⚫ Confirming types of configuration utility CIE-H12G can be configured by ezManager.
  • Page 42: Connection Problem Over Modbus/Tcp

    Under this circumstance, users should ask the person in charge of their network to release ports which will be used. (Ex: TCP 502, UDP 50005) ⚫ Operation Mode A TCP connection is not possible when CIE-H12G is operating in the ISP or Serial Configuration mode. ⚫ Connection Mode To make a TCP connection, both a server (passive mode) and a client (active mode) should exist.
  • Page 43: Communication Problem Over Modbus/Tcp

    Check all the related parameters that [Unit ID], [Input Port Base Address], [Output Port Base Address], [Poll Interval] and [Notify Input change]. ⚫ Checking which mode is using In case of MACRO, you can control the outputs of CIE-H12G. Turn the mode off if those modes are using. ...
  • Page 44: Technical Support And Warranty

    9 Technical Support and Warranty Technical Support If you have any question regarding operation of the product, visit Customer Support FAQ corner and the message board on Sollae Systems’ web site or send us an email at the following address: ⚫ E-mail: support@eztcp.com ⚫...
  • Page 45: Precaution And Exemption From Liability

    ⚫ Specifications of the product are subject to change without prior notice for performance improvement. ⚫ Sollae Systems does not guarantee successful operation of the product if the product was used under conditions deviating from the product specifications. ⚫ Reverse engineering of firmware and applications provided by Sollae Systems is prohibited.
  • Page 46: Exemption From Liability

    (including, without limitation, damages for loss of profit, operating cost for commercial interruption, loss of information, or any other financial loss) from the use or inability to use the CIE-H12G even if Sollae Systems Co., Ltd. Or its distributors have been informed of such damages.
  • Page 47: French Version

    à leur propriétaire et Fabricant respectif. ⚫ Conditions d’utilisations et limite de responsabilité En aucun cas Sollae Systems Co., Ltd. ou un de ses distributeurs ne pourra être tenu responsable de dommages quels qu'ils soient (intégrant, mais sans limitation, dommages...
  • Page 48 CIE-H12G sans que la responsabilité de Sollae Systems Co., Ltd. et de ses distributeurs ne puissent être mise en cause, ni que le boîtier CIE-H12G puisse être échangé au titre de la garantie.
  • Page 49: History

    CIE-H12G User Manual Ver. 1.1 11 History Date Version Comments Author 2023.03.20. ○ Created Roy LEE 2023.04.03. ○ Corrected some errors and improved some expressions Roy LEE - 48 - https://www.eztcp.com...
