User Manual
Remote I/O Controller
Quick Installation & Simple Test Guide
(CIE - H12)
If you subscribe to RSS, you can get all the latest information conveniently.
Please click
mark at our website.(http://www.eztcp.com)
Thank you for purchasing our CIE-H12. Before you use the product, refer to
this document for basic configuration and simple test.
- CONTENTS OF THIS DOCUMENT(H/W, S/W, FORM OF PRODUCTS) WOULD BE CHANGED WITHOUT ANY NOTICE.
- THIS PRODUCT COULD BE POSSIBLE TO BE UNAVAILABLE OR LIMITED UNDER INAPPROPRIATE NEWTORK CONDI-
TION.
- IF ACCIDENTS OR LOSS MAY OCCUR USING THIS PRODUCT, SOLLAE SYSTEMS WILL NOT BE LIABLE FOR ANY
COMPENSATION.
SOLLAE SYSTEMS
1
구성품
Components
5V Power Adapter
CIE-H12 Body
(Optional)
2 x DIN-rail
Bracket
mounter
(Optional)
(Optional)
Features
ISP Button
LAN Cable
CD
(Optional)
(Optional)
LAN Port
DC Jack
INPUT/OUTPUT Ports
INPUT-LED
OUTPUT-LED
