CIE-H10G User Manual Ver. 1.0
8-Port Remote I/O Controller
CIE-H10G User Manual
Version 1.0
Sollae Systems Co., Ltd.
https://www.ezTCP.com
- 0 -
https://www.eztcp.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CIE-H10G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sollae Systems CIE-H10G

  • Page 1 CIE-H10G User Manual Ver. 1.0 8-Port Remote I/O Controller CIE-H10G User Manual Version 1.0 Sollae Systems Co., Ltd. https://www.ezTCP.com - 0 - https://www.eztcp.com...
  • Page 2 CIE-H10G User Manual Ver. 1.0 This symbol, found on your product or on its packaging, indicates that this product should not be treated as household waste when you wish to dispose of it. Instead, it should be handed over to an applicable collection point for the recycling of electrical and electronic equipment.
  • Page 3: Table Of Contents

    CIE-H10G User Manual Ver. 1.0 Contents Contents ............................- 2 - Overview ..........................- 6 - Overview ................................- 6 - Main Features ..............................- 6 - Application Examples ..........................- 7 - Specification ..............................- 8 - 1.4.1 H/W specification ........................... - 8 - 1.4.2...
  • Page 4 CIE-H10G User Manual Ver. 1.0 4.4.2 Factory Reset ............................- 25 - ISP mode ................................ - 25 - 4.5.1 Configuring Parameters ........................- 25 - 4.5.2 Changing Firmware ..........................- 25 - I/O Control ..........................- 26 - MODBUS/TCP ............................... - 26 - 5.1.1...
  • Page 5 CIE-H10G User Manual Ver. 1.0 7.1.1 Firmware ..............................- 37 - 7.1.2 Processes ..............................- 37 - Changing a Web page ..........................- 38 - 7.2.1 Processes ..............................- 38 - Status Monitoring............................- 39 - 7.3.1 Using TELNET ............................- 39 - 7.3.2...
  • Page 6 CIE-H10G User Manual Ver. 1.0 11.2 Exemption from Liability ......................... - 59 - 11.2.1 English version ............................- 59 - 11.2.2 French version ............................- 60 - History ........................... - 62 - - 5 - https://www.eztcp.com...
  • Page 7: Overview

    CIE-H10G provides the functionality of remotely monitoring sensors such as temperature, humidity, and pressure, as well as controlling power supplies remotely. CIE-H10G detects ON/OFF by receiving digital output from sensors and controls output ports through remote requests. It supports Modbus/TCP, HTTP, and macro functions for input/output control.
  • Page 8: Application Examples

    CIE-H10G User Manual Ver. 1.0 1.3 Application Examples ⚫ 1:1 Connection with a remote host (HMI) Figure 1-1 1:1 Connection with a remote host (HMI) ⚫ 1:N Connection with a remote host (Web) Figure 1-2 1:N Connection with a remote host (Web) ⚫...
  • Page 9: Specification

    CIE-H10G User Manual Ver. 1.0 1.4 Specification 1.4.1 H/W specification Input Power DC 5V (±10%) Power Current Consumption 450mA typical Size 153mm x 126mm x 32mm Weight Approximately 475g Digital Input 8 ports with photocouplers Digital Output 8 ports with relays...
  • Page 10: Interface

    1.5 Interface 1.5.1 Input Ports Each input port of the CIE-H10G is insulated through a photocoupler and detects ON/OFF through a level of DC voltage. Each port automatically detects polarity. Figure 1-4 a circuit of the input port The voltage specification of the input port is as follows:...
  • Page 11 CIE-H10G User Manual Ver. 1.0 ⚫ Types for giving input The input type of CIE-H10G is a wet contact. That means the signal has to two lines with a potential difference to input High. To change the input type to a dry contact, you need to use a Dry Contact Adapter (DCA) or configure an additional circuit.
  • Page 12: Output Ports

    CIE-H10G User Manual Ver. 1.0 1.5.2 Output Ports The output ports of CIE-H10G are interfaced to relays (NO : Normal Open) as shown below. Figure 1-5 a circuit of the output port The operations of an output port are as follows:...
  • Page 13: Rs232 Port (Db9M)

    CIE-H10G User Manual Ver. 1.0 1.5.3 RS232 Port (DB9M) CIE-H10G has an RS232 port supporting from 300 bps to 230,400 bps. This port is for connecting users’ serial devices to Ethernet (TCP/IP) including the “Serialized Modbus/TCP”. Figure 1-6 RS232 port ⚫...
  • Page 14: Ethernet Interface

    Single idle bit is automatically added after every stop bit by the MCU function. 1.5.4 Ethernet Interface The Ethernet port of CIE-H10G is support 10M/100Mbps and users can use both 1:1 cable and crossover cable. There is a built in RJ45 connector for interfacing Ethernet and its specifications are as follows: Figure 1-7 Ethernet connector ⚫...
  • Page 15: Power

    CIE-H10G User Manual Ver. 1.0 1.5.5 Power CIE-H10G can be powered by DC 5V source via power jack. The specifications of the power jack are as follows: Figure 1-8 power jack - 14 - https://www.eztcp.com...
  • Page 16: System Led

    CIE-H10G User Manual Ver. 1.0 1.5.6 System LED CIE-H10G has 21 LEDs to indicate the current system status. Each LED represents the following status: mode name color LED status description Power is supplied Connected with network LINK Green When sending/receiving network...
  • Page 17: Installation And Test

    Figure 2-1 Installation 2.1.1 Setting Network Aera This step is for setting both CIE-H10G and your PC to be located on the same network to establish a TCP connection. ⚫ Setting of the PC Set the IP address to the Ethernet adapter of the PC connected to the product as follows.
  • Page 18 CIE-H10G User Manual Ver. 1.0 ⚫ Setting of CIE-H10G CIE-H10G uses ezManager as it’s a configuration program. The Simple Test is performed with the environmental variables of CIE-H10G set to their default values. The main environmental variables and their default values of CIE-H10G...
  • Page 19: Simple Test

    This is a test for monitoring and controlling with Modbus/TCP. This test uses the Modbus/TCP program in ezManager. Figure 2-3 Modbus/TCP test program ① Search the connected CIE-H10G with [Search All] button. ② Select a MAC address of searched product on the [search result]. ③ Click the [Tools] - [Modbus/TCP] button.
  • Page 20 Figure 2-4 Modbus/TCP test ① Input the IP address of CIE-H10G ② Input the local port for Modbus/TCP of CIE-H10G ③ Connect by pressing [Connect] button ④ Under the connection, check if the Di LEDs are turned on or off with signal input ⑤...
  • Page 21: Http Test With A Web Browser

    CIE-H10G User Manual Ver. 1.0 2.2.2 HTTP Test with a WEB browser This is for testing the operation of Input and output ports of CIE-H10G via HTTP. The test was implemented on a WEB browser. Figure 2-5 HTTP test ① Input the IP address of your CIE-H10G on the address field (default: 10.1.0.1).
  • Page 22: Configuration

    Configuration via LAN ⚫ Checklists Make sure of the connection between your PC and CIE-H10G via Ethernet. If they are in the same network, [MAC Address search] button can be used. Otherwise, only [IP Address search] is allowed to use.
  • Page 23: Configuration Via Serial

    Configuration via Serial ⚫ Checklists Make sure of the connection between your PC and CIE-H10G using a RS232 cross cable. CIE-H10G has to be operating in the [Serial Configuration] mode. You make CIE-H10G operate in the serial configuration mode by pressing the ISP- button less than 1 second.
  • Page 24: Operation Modes

    CIE-H10G User Manual Ver. 1.0 4 Operation Modes 4.1 Operation Modes Each of three operation modes are designed for specific purposes, and those are as follows: ⚫ Normal mode This mode is for normal data communication. Configuring parameters is also available in this mode.
  • Page 25: Normal Mode

    CIE-H10G User Manual Ver. 1.0 4.3 Normal Mode In the normal mode, there are four types of I/O control methods and four types of communication modes as a serial-Ethernet converter. ⚫ I/O control methods Methods Descriptions Modbus/TCP Monitor/Control the I/O ports via Modbus/TCP...
  • Page 26: Serial Configuration Mode

    This is a mode for setting environmental variables via the serial port. If it is not possible to set the CIE-H10G through network connection, you can use the serial port to change the settings. You can set the environmental values through the "Serial"...
  • Page 27: O Control

    CIE-H10G User Manual Ver. 1.0 5 I/O Control MODBUS/TCP CIE-H10G supports Modbus/TCP as the default protocol for I/O control. 5.1.1 Related Parameters Parameter Description Modbus/TCP Using Modbus/TCP for controlling I/O ports of CIE-H10G. Slave The slave responses by queries from the Master...
  • Page 28: Modbus/Tcp Slave Mode

    According to the standard Modbus/TCP, users can use a Modbus/TCP manager to control and monitor their I/O devices. You can set CIE-H10G to the [Slave] item to [Slave] mode. The [Passive] connection is recommended in this mode and the [Peer Port] should be 502.
  • Page 29: Write Pulse

    By using the FC105, you can give the signal of pulse type to the output ports. This means the output signal is kept during the specific time configured by users. 5.1.7 Communication with HMI In case of communication HMI with CIE-H10G, please refer to the address table below. ⚫ Examples of HMI address references Address...
  • Page 30: Serialized Modbus/Tcp

    CIE-H10G User Manual Ver. 1.0 5.2 Serialized Modbus/TCP In this mode, CIE-H10G sends and receives Modbus/TCP data via the serial port. By using this mode, you can monitor and control the I/O ports of CIE-H10G through the RS232 port. ...
  • Page 31: Operands

    CIE-H10G User Manual Ver. 1.0 5.3.2 Operands Operands used in macro mode are each input port. Each input port is designated with i0 ~ i7 symbol based on their sequence. Since operands are case-insensitive, they can also be written as I0 ~ I7.
  • Page 32: Web (Http)

    The CIE-H10G provides changing a web page function. Users can modify or create new web pages for the CIE-H10G, instead of using the default web page, as long as they know simple script syntax. Our website provides various web page samples in different formats to use in creating user’s own web page.
  • Page 33: Serial-Ethernet Conversion

    6 Serial-Ethernet Conversion 6.1 TCP Server In this mode, CIE-H10G functions as a TCP server. You can use this mode when the remote host is a TCP client. CIE-H10G listens to a TCP connection from remote host. Once a host tries to connect to CIE-H10G and the module responses that request.
  • Page 34: Tcp Client

    CIE-H10G User Manual Ver. 1.0 6.2 TCP Client In this mode, CIE-H10G functions as a TCP client. You can use this mode when the remote host is a TCP server. CIE-H10G sends request segments to a remote host with [Peer Address] and [Peer Port]. Once a host is listening and works correctly, the connection will be established.
  • Page 35 CIE-H10G tries to terminate established TCP connection. ⚫ TCP Server This check option enables the TCP server / client mode. In this mode, CIE-H10G can be operated as a TCP server or client without changing its setting. ⚫ DNS IP Address [DNS IP Address] needs when you use host name instead of the IP address.
  • Page 36: At Command

    CIE-H10G User Manual Ver. 1.0 6.3 AT Command AT command is a mode which users’ control CIE-H10G with AT command like controlling modem. In this mode, active and passive TCP connections are available. And users are allowed to configure some environmental parameters with extended commands.
  • Page 37: Udp

    [Block Size (Byte)] means the size of a block in UDP mode. Its unit is byte. The size of bytes come into the serial port, CIE-H10G sends them as one block to the network. The maximum value could be 1460 bytes.
  • Page 38: Management

    7.1 Changing Firmware 7.1.1 Firmware Firmware is a type of software for operation of CIE-H10G. If there are needs for adding function or fixing bugs, the firmware is modified and released. We recommend that users keep use the latest released firmware.
  • Page 39: Changing A Web Page

    CIE-H10G User Manual Ver. 1.0 7.2 Changing a Web page CIE-H10G comes with a default web page stored when it leaves the factory. Follow the steps below to change the web page to a another one. 7.2.1 Processes ⚫ Creating a web page / Downloading a sample web page Create a new web page or download a sample web page on our web site.
  • Page 40: Status Monitoring

    If the [TELNET] function in the [Option] tab of ezManager is enabled, users can log in to the CIE-H10G via Telnet. The login password used is the password set in the product, and if no password is set, the default password is 'sollae'.
  • Page 41 CIE-H10G User Manual Ver. 1.0 ⚫ st net This command shows session information of IPv4 network. CIE-H10G Management Console v1.0A Sollae Systems lsh>st net proto name local address peer address sendq state ----- ------ -------------------------- ----------------- ----- ---------- 10.1.0.1( 10.11.0.67(50904) 219 ESTABLISHED TCP http7 0.0.0.0(...
  • Page 42 CIE-H10G User Manual Ver. 1.0 ⚫ st uptime This command shows your device’s uptime. lsh>st uptime 00:05:19.16 up 0 days lsh> Figure 7-7 st uptime ⚫ sc This command closes a session. [OP1] represents the name of session and [OP2] represents the action.
  • Page 43: Using Ezmanager

    CIE-H10G User Manual Ver. 1.0 7.3.2 Using ezManager Status of CIE-H10G can be monitored by [Status] button on ezManager. By using the [Refresh Every 1 Second] option in the status window, the status is automatically updated in every second. Figure 7-12 Status window of ezManager ⚫...
  • Page 44 CIE-H10G User Manual Ver. 1.0 ⚫ TCP STATE TCP status of each port is shown this section. Message Description LISTEN listening TCP connection CLOSE TCP connection is closed SYN_SENT Send “SYN” segment to make TCP connection ESTABLISHED When TCP connection is established...
  • Page 45 When right click on a session, a small pop-up window is created. ⚫ Password This text box is activated when CIE-H10G has a password. If users want to close TCP connection with right click of mouse on the session, this password has to be correctly filled.
  • Page 46 CIE-H10G User Manual Ver. 1.0 ⚫ Refresh Every 1 Second. If this option is checked, ezManager send query in every second. ⚫ IP address Conflict Detection By clicking this button, you can find devices which have the same IP address to yours on the network.
  • Page 47: Factory Reset

    CIE-H10G User Manual Ver. 1.0 7.4 Factory Reset Performing factory reset restores all setting values except for a password to the factory default. How to perform the factory reset is as follows. ⚫ Entering to Serial configuration mode Press the ISP button shortly (less than 1 second) and release it. STS, RXD and TXD LED blink simultaneously in this state.
  • Page 48: Additional Functions

    CIE-H10G User Manual Ver. 1.0 8 Additional Functions 8.1 General 8.1.1 ezTCP Firewall On the [Option] tab of ezManager, users can set restriction of access function with filtering MAC and IP address. ⚫ Allowed MAC Address If this option has a value of MAC address, the device which has the MAC address is only permitted to access.
  • Page 49: Setting Password

    The maximum length is 8 bytes of Alphabet or number.  When you want to revoke all of these restrictions, operate CIE-H10G as ISP mode. In the mode, all restrictions are removable and communication with ezManager is revoked.
  • Page 50: I/O Control

    8.2.2 Valid Time CIE-H10G recognizes a signal on its input port as a valid signal only if it is maintained for the duration of the Valid Time. If the signal on the input port is not maintained for the time set in this item, it will be ignored. The unit is 1ms.
  • Page 51: Master Function For Configuring Internet Switches

    CIE-H10G User Manual Ver. 1.0 8.2.4 Master function for configuring Internet switches CIE-H10G provides master functionality for configuring an Internet switch. An Internet switch is a configuration method that connects devices to devices via Modbus/TCP, transmitting digital inputs to digital outputs. In this configuration, one side must be set as a master and the other as a slave.
  • Page 52: Serial-Ethernet Conversion

    8.3 Serial-Ethernet Conversion 8.3.1 Sending MAC Address [Sending MAC Address] is a function that CIE-H10G sends its MAC address to the remote host right after the connection is established. By using this function, a server can identify multiple devices with the information.
  • Page 53: Disable Tcp Transmission Delay

    CIE-H10G User Manual Ver. 1.0 8.3.3 Disable TCP Transmission Delay The TCP Transmission delay function is a feature that delays TCP segment transmission for about 40ms for congestion control. This option determines whether the TCP transmission delay function is enabled or not. Enabling this option allows TCP segments to be transmitted quickly without delay.
  • Page 54: Separator

    This is the item to set the delimiter to distinguish the frame of serial received data. CIE-H10G generates TCP segments (or UDP packets) based on the separated frame unit and sends them to TCP (or UDP). The size of one frame cannot exceed 512 bytes.
  • Page 55: Self-Test In Trouble

    CIE-H10G User Manual Ver. 1.0 9 Self-Test in Trouble When users are in trouble with using CIE-H10G, make sure of the following steps first. 9.1 Searching problem with ezManager ⚫ Confirming types of configuration utility CIE-H10G can be configured by ezManager.
  • Page 56: Connection Problem Over Modbus/Tcp

    Under this circumstance, users should ask the person in charge of their network to release ports which will be used. (Ex: TCP 502, UDP 50005) ⚫ Operation Mode A TCP connection is not possible when CIE-H10G is operating in the ISP or Serial Configuration mode. ⚫ Connection Mode To make a TCP connection, both a server (passive mode) and a client (active mode) should exist.
  • Page 57: Communication Problem Over Modbus/Tcp

    CIE-H10G User Manual Ver. 1.0 9.3 Communication Problem over Modbus/TCP ⚫ Checking Modbus/TCP parameters Check all the related parameters that [Unit ID], [Input Port Base Address], [Output Port Base Address], [Poll Interval] and [Notify Input change]. ⚫ Checking which mode is using In case of MACRO or serialized Modbus/TCP, you can control the outputs of CIE- H10G.
  • Page 58: Technical Support And Warranty

    10 Technical Support and Warranty 10.1 Technical Support If you have any question regarding operation of the product, visit Customer Support FAQ corner and the message board on Sollae Systems’ web site or send us an email at the following address: ⚫ E-mail: support@eztcp.com ⚫...
  • Page 59: Precaution And Exemption From Liability

    ⚫ Specifications of the product are subject to change without prior notice for performance improvement. ⚫ Sollae Systems does not guarantee successful operation of the product if the product was used under conditions deviating from the product specifications. ⚫ Reverse engineering of firmware and applications provided by Sollae Systems is prohibited.
  • Page 60: Exemption From Liability

    (including, without limitation, damages for loss of profit, operating cost for commercial interruption, loss of information, or any other financial loss) from the use or inability to use the CIE-H10G even if Sollae Systems Co., Ltd. Or its distributors have been informed of such damages.
  • Page 61: French Version

    à leur propriétaire et Fabricant respectif. ⚫ Conditions d’utilisations et limite de responsabilité En aucun cas Sollae Systems Co., Ltd. ou un de ses distributeurs ne pourra être tenu responsable de dommages quels qu'ils soient (intégrant, mais sans limitation, dommages...
  • Page 62 CIE-H10G sans que la responsabilité de Sollae Systems Co., Ltd. et de ses distributeurs ne puissent être mise en cause, ni que le boîtier CIE-H10G puisse être échangé au titre de la garantie.
  • Page 63: History

    CIE-H10G User Manual Ver. 1.0 12 History Date Version Comments Author 2023.03.20. ○ Created Roy LEE - 62 - https://www.eztcp.com...
