Chapter 2: Overview
Front of GR8
The controls to the GR8 are accessible on the front of the
charger: the control module (user interface) and the ON/OFF
switch.
Midtronics Inc.
7000 Monroe Street
Chapter 2: Overview
Willowbrook, IL 60527
Backlit graphical display and keypad
for data entry.
Turns power on and off to the GR8.
For future upgrades via an SD card.
The slot contains a plastic filler card for
protection.
Lights in conjunction with beeping alarm
to indicate transitions and warnings.
12
•
•
GR8 1100
Control module
ON/OFF switch
SD card slot
STATUS light
www.midtronics.com
