Chapter 1: Before You Begin
Conventions Used in This Manual
To help you learn how to use your GR8, the manual uses these symbols and typographical conventions:
Convention
!
CAUTION
UP ARROW
CAPITAL LETTERS
BACK

Registering Your GR8

Before using the GR8, we recommend that you register it
online to activate your warranty. Registration will also make
it faster and easier for you to obtain technical support and
service. The GR8 has two serial numbers: one for the
control module and another for the charger
their locations, see the illustration on page 14.

assembling the GR8

The GR8 is shipped with the control module, mounting
bracket, and charger cables
assembly, follow these steps:

Attaching the Control Module

1. The hardware to attach the control module's mounting
bracket to the GR8 is installed on the top of the charger.
There are three bolts with one flat washer, one lock wash-
er, and one hex nut per bolt. Remove the washers and hex
nuts, and set them aside.
Midtronics Inc. 7000 Monroe Street
The safety symbol indicates instructions for avoiding hazardous conditions and personal injury.
The word CAUTION indicates instructions for avoiding equipment damage.
The wrench symbol indicates procedural notes and helpful information.
The text for keypad buttons are in bold capital letters.
The text for screen options are in regular capital letters.
The text for soft keys are in Arial Black capital letters.
engine. For
packed separately. For easy
One of three
preinstalled
bolts for the
control module
mounting
bracket.
Willowbrook, IL 60527
Description
To register, log on at www.midtronics.com/warranty.html
and have your serial numbers ready. If your charger needs
repair, call Midtronics Customer Service 1.800.776.1995.
Servicing the charger yourself may void your warranty.
Refer to the appendix on what is covered by the warranty.
2. Center the three holes in mounting bracket over the bolts,
and lower the bracket onto the charger. Reinstall the hard-
ware in this order: the flat washer first, the lock washer
next, and the hex nut last. Tighten the nuts securely.
10
• •
GR8 1100
One of four preinstalled bolts
on the bracket for mounting the
control module.
