Assembly Instructions - Perfect Multi-Gym Elite User Manual

READ and follow all instructions provided before assembling or installing this product.
Failure to properly assemble or install this product could result in damage to property
and/or personal injury. Do not install this product unless you are able to assemble and
install it properly. After installing this product, check to make sure it has been properly
installed and can support your full weight before beginning exercise. This product is
designed for installation on up-to-building-code, wood-frame doorways, 29" to 35" (73.5
– 89 cm) wide and for use by individuals weighing no more than 300 lbs/136 kg. ANY other
use or misuse may result in property damage and/or personal injury. If your anticipated
installation location or use does not meet these criteria, you may return the product for up
to 30 days from date of purchase.
LAY OUT THE PARTS of your Perfect
familiarize yourself with the parts for easier assembly.
STEP 1
A) Attach the LEFT and RIGHT Crossbar Assemblies together by first sliding the LEFT
Crossbar Assembly onto the RIGHT Crossbar Assembly
NOTE: the LEFT Bar Assembly is keyed to the RIGHT Crossbar Assembly with an
"L-shaped" channel.
B) Hand-fasten the two bar assemblies together by turning the LEFT Bar Assembly
counter clock-wise.
A
Left Crossbar Assembly
B

Assembly Instructions

Multi-Gym
®
L-shaped Channel
Crossbar
Elite as shown on page 6 and
®
Right Crossbar Assembly
6
Front
