OUTDOOR UNIT
No. Description
12 Air outlet grille
13 Outdoor unit rating label
14 Terminal block cover
15 Gas valve
16 Liquid valve

DISPLAY PANEL

Iqool 9/12/18
No. Display
1 POWER
2 SLEEP
3 Temp. / Error code
4 TIMER
5 RUN
Function
Illuminated when power is on
Illuminated in sleep mode
Shows the temperature / error code
Illuminated when timer is activated
Illuminated when unit is turned on
7
Iqool24
