Econ 7343 Installation & Operation Manual

Installation & Operation Manual
Content
1. ERIKS operating companies
2. Product description
3. Requirements for maintenance staff
4. Transport and storage
5. Function
6. Application
7. Installation
8. Maintenance
9. Service and repair
10. Troubleshooting
11. Removal
1. ERIKS operating companies
ECON wafer type ball valves are being delivered by several ERIKS operating companies on a
worldwide basis. In this manual these will be referred to as 'ERIKS', the individual terms of
delivery of the ERIKS operating company having executed the order are applicable.
2. Product description
The ECON wafer type ball valves are designed according to EN 1983 and should be used in
accordance with EN 1092 pressure-temperature rating and the information in our latest catalogue
or on our website www.eriks.com
the identification of the valve easier and contains:
- size (DN in mm or inch)
- pressure class
- body and bonnet material marking
- ECON logo
- heat numbers
- tag plate
3. Requirements for maintenance staff
The staff assigned to assembly, operating and maintenance tasks should be qualified to carry out
such jobs and in any circumstance, ensure personal safety
4. Transport and storage
Transport and storage should always be carried out with the ball complete closed and the valves
should be protected against external forces, influence and destruction of the painting layer as well.
The purpose of the painting layer is to protect the valve against rust, during transport and storage.
The valves should be stored in an unpolluted space and should also be protected against all
atmospheric circumstances. There should be taken care of the temperature and humidity in the
room, in order to prevent condensate formation.
5. Function
ECON ball valves are designed to stop the flow of a medium. The valve is closed by turning the
lever clockwise; please don't use tools to increase the torque on the lever. It is recommended to
use the ball valve in a complete open or closed position. An intermediate position must be avoided
as much as possible, to protect the seats.
6. Application
The ECON ball valves are used in industrial applications with clean gasses and liquids. The valves
are designed for standard operating conditions. For the use in extreme conditions e.g. highly
corrosive media, it is recommended to mention this at the ordering stage, to verify whether the
valve is suitable. The installation designer is responsible for the valve selection, suitable for the
working conditions. The valves are unsuitable, without written permission of an ERIKS company,
to apply for hazardous media as referred into Regulation (EC) No 1272/2008.
ECON ball valves Fig. 7343, 7383
Rev. 0
Ball valves are marked according to EN 19. The marking makes
