Simplicity 616RT Parts Manual page 9

Engine Mount, Belts & Wheels Group
REF NO. PART NO.
1 1917372
2 1917356
3 1960044
4 1716784
5 1921978
6 960164
7 1716780
8 1935048
9 1716773
9 1716775
10 1716782
11 1716781
12 1960151
13 1716779
14 1716777
15 928372
16 1716778
17 905850
18 1716769
19 1716770
20 1921515
21 1960470
22 1716753
23 1721528
24 1922127
25 1716752
26 1716756
27 1721527
28 *
29 1716758
30 905121
31 1716757
32 1716761
33 1716760
34 1721523
35 1716766
36 1716762
37 1716764
Footnotes:
* See your local Briggs & Stratton distributor for Parts & Service.
The above parts group applies to the following Mfg. Nos.:
1693704 616RT, 6HP Rear Tine Tiller
TP-400-2488-00-RT-S
QTY.
2 NUT, Hex 5/16" - 18
10 LOCKWASHER, Spring 5/16"
2 WASHER, 5/16"
1 COVER, Belt
2 CAPSCREW, 5/16"- 18 x 2" G5
1 WASHER, 5/8"
2 CAPSCREW, Hex Flange Head, 5/16"- 18 x 3/4"
10 NUT, Hex Flange 5/16"- 18 Two, Way Lock
1 WHEEL & TIRE ASSEMBLY, Tiller LH
1 WHEEL & TIRE ASSEMBLY, Tiller RH
2 CAPSCREW, Hex Socket Head, 1/4"- 20 x 2-5/32"
2 SPRING
2 WASHER, 1/4"
2 RING, Snap
2 KNOB, Wheel Lock Out
2 NUT, Hex Keps 1/4" - 20
1 KNOB, Lock Out Set of Two
2 KEY, Parrallel
1 PULLEY, Transmission
2 WASHER
2 CAPSCREW, 5/16"- 24 x 3/4" G5
4 CAPSCREW, Hex Socket Head, 5/16"- 18 x 11/4" G8
1 BRACKET, Engine Mount LH
1 BUMPER, Guard
8 CAPSCREW, 5/16"- 18 x 1 3/4" G5
1 BRACKET, Engine Mount RH
1 CAPSCREW, 5/16"- 24 x 1/2"
1 GUIDE, Belt Forward
1 ENGINE, 6HP Briggs & Stratton - Engine Model 120492, Engine Type 0119-
E1
1 SCREW, Set 1/4"- 20 x 1/4"
1 KEY, Woodruff
1 PULLEY, Engine, Reverse
1 PULLEY
1 CAPSCREW, Hex Head, 5/16"- 24 x 1-1/2"
1 V-BELT, Reverse
1 V-BELT, Forward
1 SPACER, Engine Pulley
1 PULLEY, Engine, Forward
DESCRIPTION
7
