Simplicity 616RT Parts Manual page 11

Shifting Mechanism Group
REF NO. PART NO.
1 1721531
2 1719063
3 1935048
4 1721509
5 1716732
6 1716801
7 1921977
8 1716702
9 1716703
10 1716804
11 1924940
12 1716803
13 1916950
14 1716728
15 1716704
16 1921978
17 1721507
18 1721508
19 1716802
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693704 616RT, 6HP Rear Tine Tiller
TP-400-2488-00-RT-S
QTY.
2 CAPSCREW, 5MM x .8 x 16MM RT
2 C-CLAMP
9 NUT, Hex Flagne 5/16"- 18 Two, Way Lock
1 BRACKET, Cable Mount
2 NUT, Hex Nylok
2 BAR, Shift Mounting
6 CAPSCREW, 5/16"- 18 x 1-1/4" G5
2 PIN, Link Forward/Reverse
1 PIN, Cotter
1 ARM, Forward Idler
3 WASHER, 3/8"
1 PULLEY, Forward Idler
2 NUT, HEX 3/8"- 16
2 YOKE, Cable
2 BUSHING, Pivot,
2 CAPSCREW, 5/16"- 18 x 2" G5
1 PULLEY, Reverse
1 ARM, Idler Reverse
1 SPRING, Idler Arm
DESCRIPTION
5/16"
9
