Simplicity 616RT Parts Manual page 5

Handle Bar Group
REF NO. PART NO.
1 1716699
2 1716721
3 1721516
4 1716718
5 1716722
6 1716732
7 1716723
8 1933896
9 1716720
10 1716709
11 1935048
12 920438
13 1719037
14 1716708
15 1716707
16 1716714
17 1716715
18 1716855
19 1716716
20 1923141
21 1716710
22 1716719
23 1716706
24 1716717
25 1716712
26 1716711
27 1716713
28 1716705
29 1931339
30 1716731
31 1921978
32 1716704
33 1716703
34 1716725
35 1716729
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693704 616RT, 6HP Rear Tine Tiller
TP-400-2488-00-RT-S
QTY.
2 HANDLE GRIP, Drive Control Lever
1 LEVER, Drive Control Walk-Behind Tiller
2 GRIP, Handle Black
1 HANDLE BAR ASSEMBLY
1 BRACKET, Drive Control Lever, RH
4 NUT, Hex Nylock
1 BRACKET, Drive Control Lever, LH
2 NUT, Hex Nylock
1 SPRING, Froward Cable Adjustment
2 CLAMP, Handle Bar Tilt
7 NUT, Hex Flange 5/16"- 18
4 NUT, Hex Jam 5/16"
2 CABLE ASSEMBLY
1 KNOB, Handle Bar Tilt Lever
1 LEVER, Handle Bar Tilt
1 STOP, Handle Bar Tilt Lever
1 CAPSCREW, Hex Head, 8MM x16MM
1 FITTING, Lube
2 CAPSCREW, Hex Head, 10MM x 30MM
2 CAPSCREW, 5/16"- 18 x 2-3/4" G5
1 SPRING, Handle Bar Swivel
1 MOUNT, Handle Bar Stem, LH
1 MOUNT, Handle Bar Stem, RH
2 NUT, Hex Nylok 10MM
1 LEVER, Handle Bar Swivel Walk-Behind Tiller
1 KNOB, Handle Bar Swivel Lever
1 STEM, Handle Bar
2 FRICTION PAD, Tilt
4 CARRIAGE BOLT, 5/16"- 18 x 2" G5
4 CAPSCREW, Hex Head, 5MM X .8MM X 10MM
1 CAPSCREW, 5/16" - 18 x 2" G5
1 BUSHING, Pivot 5/16"
1 PIN, Cotter
1 HANDLE, Reverse
1 LINK, Reverse
