Simplicity 1694161 Parts Manual

Simplicity 1694161 Parts Manual

6hp series rear tine tillers
Hide thumbs Also See for 1694161:

Advertisement

Quick Links

See also: Operator's Manual
Rear Tine Tillers
6HP Product
Mfg. No. Description
1694161
6016 RT, 6HP Tiller
1694908
6016 RT, 6HP Tiller
Parts Manual
6HP Series
Part No.:
1730319
11/2005
Rev.
TP 400-2625-01-RT-S

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1694161 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Simplicity 1694161

Summary of Contents for Simplicity 1694161

  • Page 1 Rear Tine Tillers 6HP Product Mfg. No. Description 1694161 6016 RT, 6HP Tiller 1694908 6016 RT, 6HP Tiller Parts Manual 6HP Series Part No.: 1730319 11/2005 Rev. TP 400-2625-01-RT-S...

  • Page 3: Table Of Contents

    Handle Bar Group ... Hood, Drag Stake & Tine Group ... Engine, Belts & Wheels Group ... Transmission Group ... 10 Wheel & Tiller Shaft Group ... Decal Group ... Torque Specification Chart ... Inside Back Cover Table Of Contents...

  • Page 4: Handle Bar Group

    NOTE: Unless noted otherwise, use the standard hardware torque specification chart. The above parts group applies to the following Mfg. Nos.: 1694161 - 6016 RT 1694908 - 6016 RT TP 400-2625-01-RT-S © Copyright 2005 Simplicity Manufacturing, Inc. All Rights Reserved.
  • Page 5 NUT, Hex Flange Tow Way Lock, 5/16-18 1921332 BOLT, Hex Flange Head, 5/16-18 x 3/4 Footnotes The above parts group applies to the following Mfg. Nos.: 1694161 - 6016 RT 1694908 - 6016 RT © Copyright 2005 Simplicity Manufacturing, Inc. All Rights Reserved. TP 400-2625-01-RT-S...

  • Page 6: Hood, Drag Stake & Tine Group

    NOTE: Unless noted otherwise, use the standard hardware torque specification chart. The above parts group applies to the following Mfg. Nos.: 1694161 - 6016 RT 1694908 - 6016 RT TP 400-2625-01-RT-S © Copyright 2005 Simplicity Manufacturing, Inc. All Rights Reserved.
  • Page 7 TINE ASSEMBLY, RH 1716701 BOLT, Hex Flange Head, 5/16-18 x 1/2 Footnotes The above parts group applies to the following Mfg. Nos.: 1694161 - 6016 RT 1694908 - 6016 RT © Copyright 2005 Simplicity Manufacturing, Inc. All Rights Reserved. TP 400-2625-01-RT-S...

  • Page 8: Engine, Belts & Wheels Group

    NOTE: Unless noted otherwise, use the standard hardware torque specification chart. The above parts group applies to the following Mfg. Nos.: 1694161 - 6016 RT 1694908 - 6016 RT TP 400-2625-01-RT-S © Copyright 2005 Simplicity Manufacturing, Inc. All Rights Reserved.
  • Page 9 Note** The bumper quard is not standard, order the bumper guard (Ref# 37), 4 nuts (Ref# 22) and 4 capscrews (Ref# 35). The above parts group applies to the following Mfg. Nos.: 1694161 - 6016 RT 1694908 - 6016 RT © Copyright 2005 Simplicity Manufacturing, Inc. All Rights Reserved. TP 400-2625-01-RT-S...

  • Page 10: Transmission Group

    NOTE: Unless noted otherwise, use the standard hardware torque specification chart. The above parts group applies to the following Mfg. Nos.: 1694161 - 6016 RT 1694908 - 6016 RT TP 400-2625-01-RT-S © Copyright 2005 Simplicity Manufacturing, Inc. All Rights Reserved.
  • Page 11 GASKET KIT, Oil Seal ( Includes Ref. 7, 8, 9, and 11) 1723699 TRANSMISSION ASSEMBLY, Complete, w/Lockouts Footnotes The above parts group applies to the following Mfg. Nos.: 1694161 - 6016 RT 1694908 - 6016 RT © Copyright 2005 Simplicity Manufacturing, Inc. All Rights Reserved. TP 400-2625-01-RT-S...

  • Page 12: Wheel & Tiller Shaft Group

    NOTE: Unless noted otherwise, use the standard hardware torque specification chart. The above parts group applies to the following Mfg. Nos.: 1694161 - 6016 RT 1694908 - 6016 RT TP 400-2625-01-RT-S © Copyright 2005 Simplicity Manufacturing, Inc. All Rights Reserved.
  • Page 13 1716811 SHAFT ASSEMBLY, Wheels w/Lock Pin 1716823 GEAR, Worm Shaft Footnotes The above parts group applies to the following Mfg. Nos.: 1694161 - 6016 RT 1694908 - 6016 RT © Copyright 2005 Simplicity Manufacturing, Inc. All Rights Reserved. TP 400-2625-01-RT-S...

  • Page 14: Decal Group

    NOTE: Unless noted otherwise, use the standard hardware torque specification chart. The above parts group applies to the following Mfg. Nos.: 1694161 - 6016 RT 1694908 - 6016 RT TP 400-2625-01-RT-S © Copyright 2005 Simplicity Manufacturing, Inc. All Rights Reserved.
  • Page 15 DECAL, Danger, Tine Hood Label 1723523 DECAL, 6016 RT 1716800 DECAL, Warning, Belt Cover Footnotes The above parts group applies to the following Mfg. Nos.: 1694161 - 6016 RT 1694908 - 6016 RT © Copyright 2005 Simplicity Manufacturing, Inc. All Rights Reserved. TP 400-2625-01-RT-S...

  • Page 17: Torque Specification Chart

    Hardware Identification & Torque Specifications Common Hardware Types Hex Head Capscrew Carriage Bolt Standard Hardware Sizing When a washer or nut is identified as 1/2”, this is the Nominal size , meaning the inside diameter is 1/2 inch; if a second number is present it represent the threads per inch When bolt or capscrew is identified as 1/2 - 16 x 2”, this means the Nominal size , or body diameter is 1/2 inch;...
  • Page 18 MANUFACTURING, INC. 500 N. Spring Street / PO Box 997 Port Washington, WI 53074-0997 USA www.simplicitymfg.com © Copyright 2005 Simplicity Manufacturing, Inc. All Rights Reserved. Printed In USA.

This manual is also suitable for:

169490817303196hp series6016 rt
