Simplicity 616RT Parts Manual page 15

Wheel and Tiller Shaft Group
REF NO. PART NO.
1 1716793
2 1716825
2 1716826
2 1716827
2 1716828
2 1716829
3 1716810
4 1716824
5 1716816
6 1716815
6 1716817
6 1716818
6 1716819
6 1716820
7 1716830
8 1716791
9 1716809
10 1716821
11 1716797
12 1716814
13 1716812
14 1716813
15 1716823
16 1716822
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693704 616RT, 6HP Rear Tine Tiller
TP-400-2488-00-RT-S
QTY.
1 CAP, Rear Bearing
1 SHIM SET, Rear Bearing Cap
1 SHIM, 0.062 Thickness x 1-3/4" (As Required)
1 SHIM, 0.030 Thickness x 1-3/4" (As Required)
1 SHIM, 0.015 Thickness x 1-3/4" (As Required)
1 SHIM, 0.010 Thickness x 1-3/4" (As Required)
2 BEARING, Tapered ( Cone & Race )
4 SPACER, 1" x 1-1/4" x 1/16"
4 BUSHING
4 SHIM SET, Axle Spacer
1 SHIM, 0.062 Thickness x 1-3/8"
1 SHIM, 0.030 Thickness x 1-3/8"
1 SHIM, 0.015 Thickness x 1-3/8"
1 SHIM, 0.010 Thickness x 1-3/8"
4 RING, Snap Internal Retainer
4 SEAL, Housing
1 SHAFT, Main Drive
2 RING, Snap External Retainer
1 SEAL, Oil Drive Shaft
1 GEAR, Worm Wheel Shaft
1 SHAFT ASSEMBLY, Wheel w/Lock Pin
2 KEY, Parrallel Plane
1 GEAR, Worm Shaft
1 SHAFT ASSEMBLY
DESCRIPTION
13
