Simplicity 616RT Parts Manual page 7

Hood, Drag Stake & Tine Group
REF NO. PART NO.
1 1716700
2 1716745
3 1716743
4 1716742
5 1921958
6 1721515
7 1935048
8 1921210
9 1716739
10 1716741
10 1716749
11 1916950
12 1921971
13 1916965
14 1921333
15 1716737
16 1716701
17 1721511
9,15 1716751
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693704 616RT, 6HP Rear Tine Tiller
TP-400-2488-00-RT-S
QTY.
1 GRIP, Handle, Black
1 LEVER, Drag Stake, Walk-Behind Tiller
1 KNOB, T Handle, Drag Stake
1 PIN, DETENT, 5/16"- 18 x 1"
2 CAPSCREW, 1/4"- 20 x 1/2" G5
1 HOOD
2 NUT, Hex Flange 5/16"- 18 Two, Way Lock
16 CAPSCREW, 3/8"- 16 x 1" G5
8 TINE BLADE, Left Side
2 HOLDER, Tine Blade LH+RH
1 REPLACEMENT KIT, Tine Blade Holder
18 NUT, Hex 3/8"- 16NC
2 CAPSCREW, 3/8"- 16 x 1-3/4" G5
16 LOCKWASHER, Spring 3/8"
2 CAPSCREW, 5/16"- 18 x 1" G5
8 TINE BLADE, Right Side
2 CAPSCREW, Hex Flange Head, 5/16"- 18 x 1/2"
1 BRACKET, Depth Regulator RT
1 REPLACEMENT KIT, Tine Blade
DESCRIPTION
5
