Simplicity 616RT Parts Manual page 19

Hiller/Furrower Attachment
REF NO. PART NO.
1 1686802
2 *
3 *
4 *
5 *
6 *
7 *
8 *
9 *
9 *
10 *
11 *
12 *
Footnotes:
* No servicable parts - components shown for reference only.
The above parts group applies to the following Mfg. Nos.:
1692878 Hiller/Furrower Attachment
1693704 616RT, 6HP Rear Tine Tiller
TP-400-2488-00-RT-S
QTY.
1 HILLER/FURROWER, Complete
1 BOLT, Socket Head, 3/8"- 16 x 1-1/4"
1 BRACKET
1 NUT, Hex, 3/8"- 16
2 NUT, Nyloc, 3/8" - 16
1 BLADE, Furrower
2 CARRIAGE BOLT, 3/8"- 16 x 1-1/2"
4 CARRIAGE BOLT, 5/16"- 18 x 3/4"
1 HILLER WING, Left
1 HILLER WING, Right (Not Shown)
4 WASHER, Flat, 5/16"
4 LOCKWASHER, External Tooth, 5/16"
4 WING NUT, 5/16"- 18
DESCRIPTION
17
