RECOVERY INSTRUCTIONS
•
Put a jumper on the first and second pins shown on the left side of the Ethernet port as shown
below:
•
Wait for 1 to 2 minutes for the Run LED to start flashing.
NOTE: See Run LED location below:
LED Locations for Standard (Left) and LonWorks (Right) ProtoCessors
•
When the Run LED starts flashing, remove the jumper.
•
The unit IP Address will be set to 192.168.2.100.
•
Open a browser window on a PC connected to the local network and download the
config/firmware/img files for the application.
ProtoNode with Jumper Set for Recovery
Page 3 of 4
